Recommended Enclosures
Please Note: Our suggested box volumes are given as internal air requirements
Sealed Enclosure
Box Volume 1.25cu.ft.
* Box is given as internal air volume including driver displacement.
Ported Enclosure
Box Volume 1.5 cu.ft.
Box Tuning 38Hz
Port Diameter 4in.
Port Length 16in.
* Box is given as internal air volume including port and driver displacement.
SW12D2 / SW12D4
Chasis Width 12.25in. / 31.11 cm
Mounting Depth 5.37in. / 13.63 cm
Overall Height 5.88in. / 14.90 cm
Cutout Diameter 10.87in. / 27.60 cm
SW12D2 / SW12D4
12" Subwoofer
Installation Instructions / Owner's Manual
DB Research L.L.P.
302 Hanmore Industrial Parkway // Harlingen, TX 78550
ph: 877.787.0101 // fx: 956.421.4513 // www.dbdrive.net
®
Advertisement
Related Manuals for DB Drive Speed Series Subwoofer SW12D2
Summary of Contents for DB Drive Speed Series Subwoofer SW12D2
-
Page 1: Recommended Enclosures
Recommended Enclosures Please Note: Our suggested box volumes are given as internal air requirements Sealed Enclosure Box Volume 1.25cu.ft. * Box is given as internal air volume including driver displacement. Ported Enclosure Box Volume 1.5 cu.ft. Box Tuning 38Hz Port Diameter 4in. Port Length 16in. - Page 2 NTRODUCTION Congratulations on your purchase of a DB Drive state-of-the-art subwoofer compo- nent. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including a DB Drive subwoofer in a new system, you are certain to notice immediate performance benefits.
