Summary of Contents for DB Drive EUPHORIA EW7 8D4
- Page 1 EUPHORIA : Subwoofers EW7 8D4 EW7 10D2 / EW7 10D4 EW7 12D2 / EW7 12D4 EW7 15D4 USER MANUAL...
-
Page 2: Product Specifications
Congratulations on your purchase of a DB Drive state-of-the-art subwoofer. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether TS Specs adding to an existing system or including your DB Drive subwoofer in a new system, you are EW7 8D4 EW7 10D2 EW7 10D4 certain to notice immediate performance benefits. - Page 3 MECHANICAL MEASUREMENTS CALCULATING ENCLOSURES It is difficult to give exact box dimensions that are universal for all cars and trucks. It is for this EW7 8D4 EW7 10D2 / EW7 10D4 reason that you must be able to calculate the space in which you have available in order to achieve the proper air volume required.
-
Page 4: Recommended Enclosures
RECOMMENDED ENCLOSURES RECOMMENDED ENCLOSURES EW7 8D4 EW7 10D4 / 10D2 Sealed Box Range .54 - .15 cuft Sealed Box Range 1.1 - 1.3 cuft Recomended Sealed Box .54 cuft Recomended Sealed Box 1.14 cuft External Box Dimentions 10” W x 10” H x 9” D External Box Dimentions 16.5 ”... - Page 5 RECOMMENDED ENCLOSURES RECOMMENDED ENCLOSURES EW7 15D4 EW7 12D4 / 12D2 Sealed Box Range 1.25 - 1.75 cuft Sealed Box Range 2.5 - 3.5 cuft Recomended Sealed Box 2.7 cuft Recomended Sealed Box 1.5 cuft External Box Dimentions 14” H x 19.5” W x 13” D External Box Dimentions 21”...
-
Page 6: Wiring Diagrams
WIRING DIAGRAMS NOTES 8 Ohm 2 Ohm 4 Ohm 1 Ohm 2.6 Ohm 6 Ohm... -
Page 7: Limited Warranty
(1) year. This warranty applies to the original purchase only. DB Drive will either repair or replace (as its option) any unit that has been found to be defective and under warranty provided the defect occurs within the one (1) year warranty period.
