- Page 1 SUBWOOFER MODELS: SPF10D4 / SPF12D4 USER MANUAL Installation Instructions | Owners Manual Due to continuous improvement of the product, specifications are subject to change without notice.
- Page 2 Congratulations on your purchase of a DB Drive state-of-the-art subwoofer. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your DB Drive subwoofer in a new system, you are certain to notice immediate performance benefits.
-
Page 3: Product Features
PRODUCT FEATURES • 2.5” (63mm) 4 Layer Dual 4 Ohm VC w/ • Ultra Thin Stamped Steel Frame Design Aluminum Former • Blue Zinc Finished Top and Bottom Plates • IMPP Cone with Foam Surround • Mixed C Fiber Spider •... -
Page 4: Product Dimensions
PRODUCT DIMENSIONS Frame Diameter Mounting Depth Cutout Diameter SPF10D4 SPF12D4 Frame Diameter 10.43 in. / 265 mm 12.43 in. / 315 mm Mounting Depth 3.5 in. / 89 mm 3.5 in. / 89 mm Cutout Diameter 9.05 in. / 230 mm 11.18 in. - Page 5 RECOMMENDED ENCLOSURE Sealed Enclosure: ENCLOSURE SPF10D4 SPF12D4 Cutout Diameter: 9.05 in. / 230 mm 11.18 in. / 284 mm Mounting Depth: 3.5 in. / 89 mm 3.5 in. / 89 mm Sealed Box Volume: .45 cuft. .55 cuft. Maximum Power: 1000 Watts 1000 Watts Nominal Power:...
- Page 6 DVC WIRING CONFIGURATIONS You can change the wiring configuration of your speakers (Series, Parallel and Series / Parallel) to match the impedance loads that maximizes the power output of you amplifier. Wiring the same woofer or multiple woofers in these three different wiring configurations will result in different impedance loads.
- Page 7 4Ω DVC WIRING CONFIGURATIONS 1 X 4Ω DVC 2 X 4Ω DVC 2 X 4Ω DVC SUBWOOFER SUBWOOFER SUBWOOFER 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 2Ω 1Ω 3 X 4Ω DVC 4 X 4Ω DVC SUBWOOFER SUBWOOFER 4Ω...
-
Page 8: Limited Warranty
(1) year. This warranty applies to the original purchase only. DB Drive™ will either repair or replace (as its option) any unit that has been found to be defective and under warranty provided the defect occurs within the one (1) year warranty period.
