SPX10S4 • SPX10D4 • SPX12S4 • SPX12D4
USER MANUAL
Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
DB Research L.L.P.
302 Hanmore Industrial Parkway Harlingen, TX 78550
Phone (877) 787-0101 : Fax (956) 421-4513 : support@dbdrive.net : www.DBDrive.net
TM
Advertisement
Related Manuals for DB Drive Speed SPX12S4
Summary of Contents for DB Drive Speed SPX12S4
-
Page 1: User Manual
SPX10S4 • SPX10D4 • SPX12S4 • SPX12D4 USER MANUAL Installation Instructions | Owners Manual Due to continuous improvement of the product, specifications are subject to change without notice. DB Research L.L.P. 302 Hanmore Industrial Parkway Harlingen, TX 78550 Phone (877) 787-0101 : Fax (956) 421-4513 : support@dbdrive.net : www.DBDrive.net... - Page 2 Congratulations on your purchase of a DB Drive state-of-the-art subwoofer. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your DB Drive subwoofer in a new system, you are certain to notice immediate performance benefits.
- Page 3 PRODUCT SPECIFICATIONS TS SPECS SPX10S4 SPX10D4 SPX12S4 SPX12D4 FS......40.8 Hz....41.5 Hz....25.5 Hz....28.7 Hz Re........3.2Ω......6.4Ω......3.2Ω......6.4Ω Qms......8.66......9.80......8.45.......8.16 Qes....... 1.00......1.13......0.95.......1.09 Qts........ 0.90......1.01......0.85.......0.96 Rms....... 2.6 kg/s....2.4 kg/s....2.1 kg/s....2.5 kg/s Cms....0.18 mm/N....0.16 mm/N...0.35 mm/N...0.28mm/N Mms......86.5 gr.....91.8 gr....111.8 gr....111.1 gr BL......8.4 N/A ....11.6 N/A....7.8 N/A....10.9 N/A SPL......
- Page 4 RECOMMENDED ENCLOSURES Sealed Ported SPX10S4 10.43in / 265mm Woofer Cut-out: 9.06 in. (230 mm.) Mounting Depth: 4.76 in. (121 mm.) Recommended Sealed Box: 1.2 cu ft. Recommended Vented Box: 1.4 cu ft. • Vent Area: 3” round vent or 7.06 square inches •...
