- Page 1 SMART CHEST/SHOULDER PRESS 20810 OWNER’S MANUAL WEBSITE...
- Page 2 Introduction Installation Indication As shown in the diagram: 1. Stand base 2. Base communication terminal 3. Stand communication terminal 4. M8*10 internal hexagon socket button head screw 5. Display stand Step 1: First, insert the base communication terminal (2) into the stand communication terminal (3) as shown in the diagram.
- Page 3 As shown in the diagram: As shown in the diagram: 1: Cross recessed pan head screw M4*8 2: Display back cover 1: Cable 2: Connecting pipe 3: Cross recessed pan head screw M3*6 4: Stand communication terminal 3: M12 flat washer 4: M12 spring washer 5: Cross recessed pan head screw M4*16 6: Control communication terminal...
- Page 4 10.The power plug must be reliably grounded, and try to avoid using other electrical appliances on the same power supply line. Please do not use a damaged or wet power Operating Instructions cord or plug. The power cord is dedicated. If damaged, it must be replaced by the manufacturer, service center or personnel with relevant professional qualifications to Preparation before use: avoid injury.
- Page 5 Mode Description: LED Light Description : We provide four resistance modes for the product, namely Standard Mode, Eccentric Mode, Isokinetic Mode, and Elastic Mode. Please refer to the following instructions for State Remark Color specific modes: Gradient effect Powered on, resistance not activated Blue (dark to light, light to dark) Mode...
-
Page 6: Installation Precautions
Installation Precautions Specification 1. When removing the packaging on the surface of the packaging equipment, be careful not to scratch the surface of the machine with a knife. There must be enough personnel Model 20810 when moving equipment to prevent equipment from colliding or personal injury caused by insufficient personnel. -
Page 7: Assembly Step
Assembly Step 1 Assembly Step 2 Step Description Specification Step Description Specification Spring washer Φ20*Φ10.5*2 Main frame M10*25 Rotating frame Main frame Short shaft Connect frame Circlip for shaft φ25 Rear ground frame Front ground fame Inner Hexagon Socket Head Bolt M10*25 Inner Hexagon Socket Head Bolt M10*80... - Page 8 Assembly Step 3 Assembly Step 4 Step Description Specification Step Description Specification Adjusting frame Rotating frame Connect shaft Adjusting frame Washer Short shaft Hexagon socket countersunk head screws M8*20 Gas spring Inner Hexagon Socket Head Bolt M10*25 Spring washer Extra big washer Φ34*Φ11*3...
- Page 9 Assembly Step 5 Assembly Step 6 Step Description Specification Step Description Specification Spring washer Main frame Back pad frame Main frame Support frame Connect frame Rotation frame Rear ground frame Transfer shaft Front ground fame Hexagon socket countersunk head screws M10*25 Inner Hexagon Socket Head Bolt Φ40*Φ26*1.5...
- Page 10 Assembly Step 7 Assembly Step 8 Step Description Specification Step Description Specification Spring washer Back pad frame Flat washer Seat pad adjusting frame Back pad frame Limiting post screw Seat pad adjusting frame Spring washer Hexagon socket countersunk head screws M10*25 Back pad Seat pad...
-
Page 11: Cable Routing Diagram
Assembly Step 9 Cable Routing Diagram Correct Mistake Correct Mistake Cable Cable limiting Post limiting Post Cable Cable limiting Post limiting Post Cable limiting Post Cable limiting Post... - Page 12 Maintenance Attentions Daily Maintenance: 1.Clean the seat pad,back pad and cushion with warm water and soft cloth in order to avoid the sweat erosion to these component . 2.Clean the frame with warm water and soft cloth 3.Cleaning chrome plated parts:wipe them with alcohol moistened soft cloth Monthly Maintenance: 1.Check transmission cable .Check the tightness and abrasion of the cable (disrepair of the surface,bend ,distortion and so on).
