  • Page 1 MULTIFUNCTIONAL STATION 4 OWNER’S MANUAL WEBSITE MANUAL...
  • Page 2 MULTI 4 STATION (FUNCTION ABCEF) Serial Function Serial Function Standard Horizontal and Parallel Bars Set High Low Pull Set Unilateral Fly Set Chest Fly Set Seated Chest Press Set Leg Press Set 1: Because Function B is one of the Standard Function. So Function B can only be assembled atⅠ(Do NOT install at Ⅱ、Ⅲ、Ⅳ) 2: Function CDEFG are option function.
  • Page 3 Function A explosive view...
  • Page 4 Function B explosive view...
  • Page 5 Function C explosive view...
  • Page 6 Function D explosive view...
  • Page 7 Function E explosive view...
  • Page 8 Function F explosive view (OPTIONAL FUNCTION)
  • Page 9 Function G explosive view (OPTIONAL FUNCTION)
  • Page 10 Function A Part List Serial Item Quantity Serial Item Quantity Bottom Seat Combo Flat Washer D10*D20*2 Above Seat Combo Flat Washer φ12*φ6*1.2 Cover Combo Stopper 80*40*2 Cover Water Bottle Shelf Tube Carsh Pad Hexagon bolt Supporting Tube Combo Hexagon bolt Hexagon bolt Cross Screw M6*15 Flat Washer D8*D16*2...
  • Page 11 Hexagon bolt M8*20 Rubber obver Nylon nut M12 Dip plastic handle set φ9*φ16*160 High cover nut M12 Dip plastic handle set φ24*φ31*140 Nylon nut M10 Magnetic bolt Hexagon nut M16 Seat Aluminum cover Stopper 80*40*2.5 Handle ring Stopper 70*30*2.5 Flat Washer D12*D24*2 Seat sleeve Flat Washer D10*D20*2 High pull down rope...
  • Page 12 Hexagon screw M8*16 Rubber foot support Hexagon screw M5*4 Nylon sleeve Bolt tube nut Pulley cover Rope fix sleeve Nylon flange sleeve Nylon nut M12 Dip plastic handle set φ24*φ31*105 High cover nut M12 Dip plastic handle set φ24*φ31*140 Hexagon nut M16 Magnetic bolt Hexagon nut M10 Crash sleeve...
  • Page 13 Hexagon bolt M10*16 Square stopper 50*50*2.5 Hexagon bolt M8*55 Square stopper 25*25*2 Hexagon bolt M8*20 Adjustable foot support Cross screw M4*10 Rubber foot support Hexagon screw M10*125 Nylon sleeve Hexagon screw M10*30 Pulley cover Hexagon screw M5*4 Nylon flange sleeve Bolt tube nut Dip plastic handle set Bearing...
  • Page 14 Function F Part List (OPTIONAL FUNCTION) Serial Item Quantity Serial Item Quantity Upper tube Slider Bottom tube Pressure spring Adjustable tube Bolt Slip tube Aluminum cap Guide plate Handle ring Pulley bracket Bolt tube nut Top cap tube Pull rod Foot pedal tube Axis Sleeve Hexagon bolt M12*80...
  • Page 15 Backrest adjusting tube Hexagon nut M16 Top cap tube Pulley Dip plastic handle set Nylon nut M12 Hexagon bolt M12*32 Aluminum cap Hexagon bolt M10*30 Hexagon bolt M12*55 Stopper Flat Washer D10*D20*2 Aluminum sleeve High cover nut M12 End cap Stopper Bearing 6204 Hexagon bolt M12*45...
  • Page 16 Function A...
  • Page 17 Function B...
  • Page 18 Function C...
  • Page 19 Function F (OPTIONAL FUNCTION) Function G (OPTIONAL FUNCTION) Function E Function D...
  • Page 20 Function E...
  • Page 21 NOTE: It is well suggested that two or more people to assemble this machine to avoid any possible injury. Remove all the security tape and wrapping before the installation. Please refer the individual steps for the installation and pay attention to the preinstalled hardware. Function F...
  • Page 22 Function G...
  • Page 23 Function A ： ： Step 1 （ （ this step has direction distinction ， ， please follow the diagram ） ） 1. Attach the Supporting Tube Combo (A14) to Bottom Seat Combo（A1）and Above Seat Combo (A2) with Hexagon bolt (A15), Flat washers (A16) as shown.
  • Page 24 Function A ： ： Step 2 (note: Function B is one of the Standard Function, CDEFG functions, guests can choose three packed function to section A base on guests’ requirement. Function B can Ⅰ Ⅰ Ⅲ Ⅲ Ⅳ Ⅳ only be installed At , CDEFG can be installed at as optional function) : Ⅱ...
  • Page 25 Function A ： ： Section E Weight block: NONE Section F Weight block: Attach Slide bar (F29) to bottom seat (A1), then put in follow parts in the right order: Crash pad (F42). Top tube (F7), Weight block (F28), Rod (F35) onto (F29). Then attach (F29) to Upper seat (A2) with Hexagon bolt (F16) and Flat washer (F24) .
  • Page 26 Function A ： ： Step 3 (NOTE: If choose function C; if not, pass this step) Attach Connect rope (C73) to Pull rod (C55), as showing blow. Attach Alloy sleeves (C42), Pulley (C58) to Upper seat (A2) with Hexagon bolt (C15), Flat Washer (C37) and Nylon nut (C28) Attach Alloy sleeves (C42), Pulley (C58) to Bottom seat (A1) with Hexagon bolt (C15), Flat Washer (C37) and Nylon nut (C28)
  • Page 27 Function A ： ： Step 3 (NOTE: If choose function D; if not, pass this step) Attach rope (D72) to Pull rod (D53), as showing blow. Attach Alloy sleeves (D41), Pulley (D56) to Upper seat (A2) with Hexagon bolt (D14), Flat Washer (D43) and Nylon nut (D32) Attach Alloy sleeves (D41), Pulley (D56) to Bottom seat (A1) with Hexagon bolt (D14), Flat Washer (D43) and Nylon nut (D32)
  • Page 28 Function A ： ： Step 3 (NOTE: If choose function F; if not, pass this step) Attach rope ( F49) to Pull rod (F35), as showing blow. Attach Alloy sleeves (F27), Pulley (F44) to Upper seat (A2) with Hexagon bolt (F12), Flat Washer (F23) and Nylon nut (F20) Attach Alloy sleeves (F27), Pulley (F44) to Bottom seat (A1) with Hexagon bolt (F12), Flat Washer (F23) and Nylon nut (F20)
  • Page 29 Function A ： ： Step 3 (NOTE: If choose function G; if not, pass this step) Attach rope ( G47) to Pull rod (G52), as showing blow. Attach Alloy sleeves (G38), Pulley (G37) to Upper seat (A2) with Hexagon bolt (G32), Flat Washer (G33) and Nylon nut (G38) Attach Alloy sleeves (G38), Pulley (G37) to Bottom seat (A1) with Hexagon bolt (G32), Flat Washer (G33) and Nylon nut (G38)
  • Page 30 Function A ： ： Step 4 (NOTE: This step does not differentiate functions; the installations are all the same.) Attach Cover (A3) to Upper and Bottom seat (A1 and A2) with Hexagon bolt (A6), Flat Washer (A9), make Hexagon bolt (A6) unlocked temporarily. Attach Cover (A4) to Upper and Bottom seat (A1 and A2) with Hexagon bolt (A6), Flat Washer (A9), make Hexagon bolt (A6) unlocked temporarily.
  • Page 31 Function A ： ： Step 5 (NOTE: This step does not differentiate functions; the installations are all the same.) Attach Shelf tube (A5) to Cover (A3) Attach Water bottle (A12) to Shelf tube (A5) with cross screw ( A8)
  • Page 32 Function B ： ： Step 1: Attach Main base frame (B2) to Main Seat frame (B1) Attach Foot pedal tube(B11) to Main Seat frame (B1) Attach Cant Beam frame (B3) to Main base frame (B2) with Square bolt (B19), Connect plate(B8), Flat washer (B30) and Nylon nut(B25)
  • Page 33 Function B ： ： Step 2: Attach Foam outer cap (B51), Foam (B49) and Foam inner cap (B52) to Leg Adjusting frame (B4) with Hexagon bolt (B22), Flat Washer (B31). Back-out Hexagon bolt (B16), take out Bolt (B41). Attach Leg Adjusting frame (B4) to Main Seat frame (B1), then tighten Hexagon bolt (B16) after.
  • Page 34 Function B ： ： Step 3: Attach Main Seat frame (B1) to Bottom seat (A1) with Hexagon bolt (B14), Flat Washer (B29) and Nylon nut (B23) Attach Cant Beam frame (B3) to Upper seat (A2) with Hexagon bolt (B14), Flat Washer (B29) and Nylon nut (B23)
  • Page 35 Function B ： ： Step 4: Install Rope (B61) as showing blow Attach Alloy Sleeve (B37) and Pulley (B43) to Cant Beam frame (B3) with Hexagon bolt (B13), Flat Washer (B29) and Nylon nut (B23) Attach Pulley cover (B46), Alloy Sleeve (B37) and Pulley (B43) to Cant Beam frame (B3) with Hexagon bolt (B12), Flat Washer (B29) and High cap nut (B24) Attach Pulley cover (B46), Alloy Sleeve (B37) and Pulley (B43) to U Shape clevis (B7) with Hexagon bolt (B12), Flat Washer (B29) and High cap nut (B24)
  • Page 36 Function B ： ： Step 5: Install Rope (B62) as showing blow, then attach (B62) to Main base frame (B2) with Hexagon bolt (B15), Flat Washer (B30) and Nylon nut (B25) Attach Alloy Sleeve (B37) and Pulley (B43) to Main base frame (B2) with Hexagon bolt (B13), Flat Washer (B29) and Nylon nut (B23) Attach Pulley cover (B46), Alloy Sleeve (B37) and Pulley (B43) to U Shape clevis (B7) with Hexagon bolt (B12), Flat Washer (B29) and High cap nut (B24)
  • Page 37 Function B ： ： Step 6: Attach Long Handle (B5) to High pull down rope (B61) with Hook (B35) Attach Short Handle (B6) to Low row rope (B62) with Hook (B35)
  • Page 38 Function C ： ： Step 1: Attach Seat (C56) to Seat post (C8) with Hexagon bolt (C21), Flat Washer (C39) Attach Backrest (B57) to Backrest post (C7) with Hexagon bolt (C21), Flat Washer (C39) Back-out Hexagon bolt (C17), take out Bolt (C54). Attach Seat post (C8) to Upper frame (C1), then tighten Hexagon bolt (C17) after.
  • Page 39 Function C ： ： Step 2: Attach Upper fly arm (C4), Right Guide cam (C2), Left Guide cam (C3) to Upper frame (C1) in the right order, and screw on Collar block (C12) with Hexagon screw (C24) on Upper frame (C1). (NOTE: Pull up Bolt (C44) and match the hole site on Right Guide cam (C2) and Left Guide cam (C3) when install Upper fly arm (C4)) Attach Left Butterfly arm (C5) and Right Butterfly arm (C6) to Upper fly arm (C4) with Hexagon screw (C18), End cap(C46), minor axis (C45).
  • Page 40 Function C ： ： Step 3: Attach Rope (C72) to Left Guide cam (C3) with Rope fix sleeve (C27), then install the other side of (C72) as showing blow. Attach Rope (C72) to Right Guide cam (C2) with Rope fix sleeve (C27) after. Attach pulley cover (C63), Alloy Sleeve (C42) and Pulley(C58) to Upper frame (C1) with Hexagon bolt (C14), Flat washer (C37), high cap nut (C29).
  • Page 41 Function C ： ： Step 4: Attach Upper frame (C1) to Bottom seat (A1) with Hexagon bolt (C16), Flat washer (C37), Nylon nut (C28). Attach Upper frame (C1) to Upper seat (A2) with Hexagon bolt (C16), Flat washer (C37), Nylon nut (C28). Install Rope (C73) as showing blow.
  • Page 42 Function D ： ： Step 1: Attach Connect tube (D1) to Seat tube (D2) with Hexagon bolt (D17), Flat washer (D43), Nylon nut (D32). Attach Front base Frame (D3) to Seat tube (D2) with Hexagon bolt (D19), Flat washer (D42), Nylon nut (D34).
  • Page 43 Function D ： ： Step 2: Take off the screw on Bearing (D31), Attach Bearing (D31) to both side of connecting tube (D5), then attach (D31) on Seat tube (D2) with Hexagon bolt (D16), Flat washer (D43), Nylon nut (D32). Tighten the screw after.
  • Page 44 Function D ： ： Step 3: Attach Pedal Connecting tube (D11) to Front Connecting tube (D4) and Rear Connecting tube (D5) with Hexagon bolt (D12), Flat washer (D43), Nylon nut (D32). Attach Foot pedal (D6) to Pedal Connecting tube (D11) with Hexagon bolt (D20), Flat washer (D42), Nylon nut (D34).
  • Page 45 Function D ： ： Step 4: Attach Right handle tube (D7) and Left handle tube (D8) to Seat tube (D2) with Hexagon bolt (D18), Flat washer (D42), Nylon nut (D34).
  • Page 46 Function D ： ： Step 5: Attach Seat (D54) to Seat tube (D2) with Hexagon bolt (D24), Flat washer (D45). Attach Backrest (D55) to Backrest tube (D9) with Hexagon bolt (D25), Flat washer (D45) Back-out Hexagon bolt (D22), take out Bolt (D51). Attach Backrest tube (D9) to Seat tube (D2), then tighten Hexagon bolt (D22) after.
  • Page 47 Function D ： ： Step 6: Attach Seat (D73) to Upper seat (A2). Attach Connecting tube (D1) to Bottom seat (A1) with Hexagon bolt (D17), Flat washer (D43), Nylon nut (D32). Install Rope (D72) as showing blow. Attach Rope (D72) to Rear Connecting tube (D5) with Hexagon bolt (D21), Flat washer (D42), Nylon nut (D34).
  • Page 48 Function E ： ： Step 1: Attach Middle tube (E4) to Left and Right tube (E1 and E2) with Hexagon bolt (E9), Flat Washer (E17), Arc splicing (E6), Nylon nut (E15), make Hexagon bolt (E9) unlocked temporarily. Attach Upper tube (E5) to Left and Right tube (E1 and E2) with Hexagon bolt (E9), Flat Washer (E17), Arc splicing (E6), Nylon nut (E15), make Hexagon bolt (E9) unlocked temporarily.
  • Page 49 Function E ： ： Step 2: Attach Bottom tube (E3) to Left and Right tube (E1 and E2) with Hexagon bolt (E8), Flat washer (E17) Tighten Hexagon bolt (E9). Attach Backrest (E28) to Middle tube (E4) with Hexagon bolt (E11), Flat washer (E19).
  • Page 50 Function E ： ： Step 3: Attach Handguard (E23) to Left and Right tube (E1 and E2) with Hexagon bolt (E10), Flat washer (E19)
  • Page 51 Function E ： ： Step 4: Attach Bottom tube (E3) to Bottom seat (A1) with Hexagon bolt (E7), Flat washer (E18), Nylon nut (E14). Attach Upper tube (E5) to Upper seat (A2) with Hexagon bolt (E7), Flat washer (E18), Nylon nut (E14). Tighten Hexagon bolt (A6) on Cover (A3 and A4).
  • Page 52 Function F(OPTIONAL FUNCTION) ： ： Step 1: Attach Foot pedal tube (F8) to Bottom tube (F2) with Hexagon bolt (F15), Flat washer (F24). Function F(OPTIONAL FUNCTION) ： ： Step 2: Adjust Adjustable tube (F3) to Slip tube (F4), around Position A will be fine.
  • Page 53 Function F(OPTIONAL FUNCTION) ： ： Step 3: Attach Slip tube (F4) to Bottom tube (F2) with Hexagon bolt (F9), Flat washer (F23). Nylon nut (F20), make Hexagon bolt (F9) unlocked temporarily.
  • Page 54 Function F(OPTIONAL FUNCTION) ： ： Step 4: Attach Upper tube (F1) to Slip tube (F4) with Hexagon bolt (F9), Flat washer (F23). Nylon nut (F20), make Hexagon bolt (F9) unlocked temporarily.
  • Page 55 Function F(OPTIONAL FUNCTION) ： ： Step 5: Attach Upper tube (F1) and Bottom Tube (F2) to Bottom seat (A1) with Hexagon bolt (F13), Flat washer (F23). Nylon nut (F20), tighten all the screws and bolts.
  • Page 56 Function F(OPTIONAL FUNCTION) ： ： Step 6: Install Rope (F49) as showing blow. Attach Rope (F49) to Pulley bracket (F6) , tighten Flange nut (F52) after. Install Rope (F48) through Guide plate (F5) as showing blow. Install Rope (F48) through Rope rubber cap (F55) and attach to Hexagon rope block (F54) and screw up with Hexagon bolt (F56), then attach Hexagon rope block (F54) to Rope rubber cap (F55) Attach pulley cover (F39), Alloy Sleeve (F27) and Pulley (F44) to Bottom tube (F2) with Hexagon bolt (F10), Flat washer (F23), high cap nut (F21).
  • Page 57 Function F(OPTIONAL FUNCTION) ： ： Step 7: Attach pulley cover (F39), Alloy Sleeve (F27) and Pulley (F44) to Upper tube (F1) with Hexagon bolt (F10), Flat washer (F23), high cap nut (F21). Attach pulley cover (F39), Alloy Sleeve (F27) and Pulley (F44) to Upper tube (F1) with Hexagon bolt (F10), Flat washer (F23), Nylon nut (F20).
  • Page 58 Function F(OPTIONAL FUNCTION) ： ： Step 8: Attach Alloy Sleeve (F27) and Pulley (F44) to Guide plate (F5) with Hexagon bolt (F11), Flat washer (F23), Nylon nut (F20).
  • Page 59 Function F(OPTIONAL FUNCTION) ： ： Step 9: Install handle bar 1 (F37) on Rope lock (F48).
  • Page 60 Function G(OPTIONAL FUNCTION) ： ： Step 1: Attach Connecting tube (G6) to Seat tube (G3) with Hexagon bolt (G39), Flat washer (G33), Nylon nut (G38). Attach Bottom tube (G2) to Seat tube (G3) with Hexagon bolt (G27), Flat washer (G41). Attach Top tube (G7) to Bottom tube (G2) and Connecting tube (G6) with Hexagon bolt (G39), Flat washer (G33), Nylon nut (G38).
  • Page 61 Function G(OPTIONAL FUNCTION) ： ： Step 2: Attach Seat (G30) to Seat adjusting tube (G5) with Hexagon bolt (G29), Flat washer (G21). Back-out Hexagon bolt (G27), take out Bolt (G26). Attach Seat adjusting tube (G5) to Seat tube (G3), then tighten Hexagon bolt (G27) after.
  • Page 62 Function G(OPTIONAL FUNCTION) ： ： Step 3: Attach Upper tube (G1) to Bottom tube (G2) with Hexagon bolt (G39), Flat washer (G33), Nylon nut (G38) Attach Backrest (G31) to Backrest tube (G8) with Hexagon bolt (G29), Flat washer (G21) Back-out Hexagon bolt (G27), take out Bolt (G26). Attach Backrest tube (G8) to Upper tube (G1 ), then tighten Hexagon bolt (G27) after.
  • Page 63 Function G(OPTIONAL FUNCTION) ： ： Step 4: Attach Upper tube (G1), Seat tube (G3) to Upper seat (A2) and Bottom seat (A1) with Hexagon bolt (G39), Flat washer (G33), Nylon nut (G38). Install Rope (G47) as showing blow. Then attach Bearing (G45) to Arm tube(G4) with Hexagon bolt (G44), Flat washer (G33), Nylon nut (G38).
  • Page 64 WARNING! Consult your physician before starting with any exercise program. He can advise on the kind of training and which impact is suitable. WARNING! This Multi 4 Station is not suitable for therapeutic or medical purpose. WARNING! Over exercising may result in serious injury or death. If you experience dizziness, nausea, chest pain, or any other abnormal symptoms STOP EXERCISING IMMEDIATELY AND CONSULT A PHYSICIAN WITHOUT DELAY.

  • Page 65: Warranty

    WARRANTY DKN-Technology warrants this product to be free from defects in material at the time of the product’s tender of delivery. This ‘Carry-in’ Limited Warranty applies for a period of two (2) years, beginning on the date mentioned on your product invoice or proof of purchase of product issue by DKN-Technology. This Limited Warranty is not transferable and does not cover normal wear and tear (including, but not limited to, damage and wear to batteries, springs, bearings, running mats, hydraulic systems, ropes, belts, pulleys, power shocks, drive belts and other non-durable parts, etc...).
