3.2 Dimension

GT1 2.5~10KW SERIES GRID-TIED INVERTER HAS TWO EXTERNAL DIMENSIONS.
GT1 2.5~6.0KW SERIES GRID-TIED INVERTER ：
368mm
GT1 7~10KW SERIES GRID-TIED INVERTER ：
465mm
6
150mm
180mm
3.3 Terminals of the inverter
A B
ON
OFF
PV1+ PV2+
DC Switch
PV1- PV2-
A B
ON
PV1+ PV2+ PV3+
OFF
DC Switch
PV1- PV2- PV3-
DC switch
A A A A
PV connection
B
Wi-Fi p o r t
C
COM port (Meter)
D
Grid output port
E
Earth port
F
C D E F
COM
Wi-Fi
Grid
C E
F
D
L N PE
CT+ CT-
485A 485B
COM
Wi-Fi
Grid
7
