LED CHARGE INDICATOR

Alternator/Solar LED
Short flash GREEN
Long flash GREEN

UNIT OPERATION

When an iTECHDCDC charger is connected, all LED indicators will light up – this
is normal operation. The charger is initialising and will take up to 2 minutes to
start charging.
The iTECHDCDC charger will go into standby mode if the input voltages are
below the turn off voltage (please note your iTECHDCDC charger will continue to
charge the auxiliary battery for up to 2 minutes before going into standby). This is
indicated by the charge input and battery type indicator LEDs blinking momentarily
at the same time. Once charging voltages have risen above the cut in voltage, it will
take up to 2 minutes for the charger to "wake" and begin to charge.
The iTECHDCDC charger will start to charge from solar input if the panel supply
voltage is above 16V and outputting at least 25W (1.5 Amps).
Input
12V standard alternator
24V standard alternator
12V smart alternator
12V smart alternator
6
Battery Type LED
Solid GREEN
Solid GREEN
iTECHDCDC25/40 Operation
Turn On
>13.2V
>26.2V
>12V
>24V
Charging Stage
Bulk or Absorption
Float
Turn Off
<12.8V
<25.6V
<11.8V
<23.6V
