QUICK START GUIDE
Step 1.
Connect the auxiliary battery to the iTECHDCDC charger output via a fuse.
Step 2
Connect the cranking battery to the iTECHDCDC charger input via a fuse.
Step 3.
Connect the solar panels to the iTECHDCDC charger solar input via a fuse.
Step 4.
Connect the ignition wire to an ignition-controlled power source.
Step 5.
Start the vehicle and verify that your iTECHDCDC charger is outputting power.
You will know the iTECHDCDC is outputting power when the battery type LED is
solid, and the alternator/solar LED is flashing.
Source
Model
Charger Input
Charger Output
Solar Input
Ignition
2 2
Fuse Size
DCDC25
40A
40A
40A
3A
DCDC40
60A
60A
60A
3A
