USER GUIDE
iTECHDCDC60
INTELLIGENT BATTERY CHARGER
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the iTECHDCDC60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iTechworld iTECHDCDC60

  • Page 1 USER GUIDE iTECHDCDC60 INTELLIGENT BATTERY CHARGER...
  • Page 2 Step 2 Connect the Cranking Battery to the iTECHDCDC60 Input via an 80-amp fuse. Step 3. Connect the Solar Panels to the iTECHDCDC60 Solar Input via an 80-amp fuse. Step 4. Connect the ignition wire to an ignition-controlled power source.
  • Page 3: Table Of Contents

    CONTENTS Product Overview Key Features Display Panel Battery Charging Profile LED Charge Indicator Unit Operation Fault Resolution Installation Install Location Selection of Cable Size Wiring Typical Setup Fuse Specifications Specifications Safety Precautions Contact Us Back page...
  • Page 4: Product Overview

    Maximum Power Point Tracking (MPPT) solar regulator, which maximises power harvested from connected solar panels, thus increasing charging efficiency. Designed with high efficiency in mind, the iTECHDCDC60 charger is compact and suitable for installations with limited space. Additionally, it is engineered to isolate the auxiliary battery from the cranking battery, preventing over-discharge of the cranking battery.
  • Page 5: Display Panel

    DISPLAY PANEL: MODE STDG LiFeP04 Alternator SolarF ault 12V 60A BATTERY CHARGING PROFILE: To modify the battery charging profile, press the ‘Mode’ button for 1.5 seconds. As a result, the battery type indicator will move one LED to the right. Please be aware that following any changes, there might be a delay of up to 2 minutes before the charger starts the charging process.
  • Page 6: Unit Operation

    UNIT OPERATION: When the iTECHDCDC60 is connected, all LED indicators will light up, this is normal operation, the charger is initialising and will take up to 2 minutes to start charging. The iTECHDCDC60 will go into standby mode if the input voltages are below...
  • Page 7: Fault Resolution

    FAULT RESOLUTION: Battery Alternator Fault LED Explanation Resolution Solar LED Type LED Low voltage detected Check alternator input Quick flash Quick flash at alternator input voltage Low voltage detected Check solar input voltage Quick flash Quick flash at solar input Low voltage detected Check both alternator at alternator or solar...
  • Page 8: Installation

    INSTALLATION INSTALL LOCATION: The iTECHDCDC60 charger has been designed for installation in a variety of locations. If the charger is to be installed in the vehicle cabin, please ensure there is adequate ventilation around the charger, and that it is not installed in an enclosed space where airflow is restricted.
  • Page 9: Selection Of Cable Size

    0.5mm2 (20AWG) 0.5mm2 (20AWG) 0.5mm2 (20AWG) iTechworld strongly advises that a properly trained / qualified individual conducts this task. Failure to establish a secure connection could result in a short circuit, potentially leading to fire and property damage. For wire extensions, it is advisable to utilise soldered butt splice connectors.
  • Page 10: Wiring

    WIRING: Before any connections are made during installation, please disconnect the main cranking battery to prevent any short circuits, please note down any radio anti- theft codes before the battery is disconnected. Cranking Battery Solar Panel Auxiliary Battery Output: connects to the battery being charged (the auxiliary battery). Alternator Input: connects to the main cranking battery.
  • Page 11: Typical Setup

    TYPICAL SETUP:...
  • Page 12: Fuse Specifications

    FUSE SPECIFICATIONS: FUSE SPECIFICATIONS: It is essential to install all recommended fuses in series within the circuit. Bolt-down fuses are the preferred choice as they guarantee a low-resistance connection. In contrast, blade-type fuses are not recommended because they can lead to a high-resistance connection, potentially causing excessive heat and potential damage to the fuse holder and wiring.
  • Page 13: Specifications

    SPECIFICATIONS General Rating Vehicle input voltage 9-32V Solar input voltage 10-48V Max input current Input fuse rating Continuous output current Up to 60A Output fuse rating Minimum aux battery charge start voltage Standby current <18mA Battery type Standard lead acid, GEL, AGM, Calcium & LifePO4 Operating temperature -20°C to +80°C IP rating...
  • Page 14: Safety Precautions

    Disclaimer: While iTechworld has taken every precaution to ensure the accuracy of the contents of this user guide, iTechworld assumes no responsibility for any errors or omissions. Furthermore, all specifications and functionality may change at any time without notice.
  • Page 15 WARNING: Do not drop the iTECHDCDC60 WARNING: Do not use the iTECHDCDC60 and its accessories to connect equipment if there is a defect. DANGER: Do not disassemble or modify the charger; doing so may result in a risk of electrical shock, fire, death, or serious injury.
  • Page 16: Contact Us

    1300 483 249 service@itechworld.com.au www.itechworld.com.au When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
