Summary of Contents for iTechworld GOFURTHER
- Page 1 USER GUIDE GOFURTHER/25/40 PREMIUM BATTERY BOX...
-
Page 3: Table Of Contents
CONTENTS Product Overview Overview Key Features Package Contents Unit Diagram Display Panel Optional Accessories Operation Battery Installation Battery Monitor & Setup Master Isolation Switch Connecting Chargers Typical Setup Warranty Back Page... -
Page 4: Product Overview
Designed to get you up and running without the need for electrical expertise, the GoFurther Premium Battery Box is everything you need to begin your adventure! battery box yet. -
Page 5: Unit Diagram
UNIT DIAGRAM OPTIONAL DCDC CHARGER MASTER ISOLATION SWITCH USB/USB-C OUTPUTS ADVANCED BATTERY MONITOR CIGARETTE LIGHTER OUTPUTS... - Page 6 IN/OUT 175A ANDERSON IN/OUT 50A ANDERSONS DCDC ALTERNATOR INPUT CARRY HANDLES MOUNTING BRACKETS DCDC SOLAR INPUT DCDC MODELS ONLY GOFURTHER TRAY SOLD SEPARATELY...
-
Page 7: Display Panel
STATE OF CHARGE VOLTAGE PERCENTAGE AMPERAGE TIME REMAINING WATTAGE Ah REMAINING GoFurther Inverter Cable GoFurther Tray... -
Page 8: Operation
OPERATION BATTERY CONFIGURATIONS Depending on the size of your battery, you' r e able to use your GoFurther • 256 x 164 x 234mm (LxWxH) For Smaller Batteries • For Larger Batteries... -
Page 9: Battery Installation
BATTERY INSTALLATION Lower your battery into the battery box base carefully, locating it as centrally as possible on the non-slip pads. Secure the battery in place by tightening the velcro strap over the battery. Install the battery cables onto the terminal posts of the battery. Ensure the red cable is connected to the positive terminal (+) and the black to the negative... - Page 10 Tuck cables in under the battery box lid, lowering the lid carefully onto the box, ensuring the lid is oriented correctly. Install the 4 provided screws to fasten the lid to the base, being sure not to over-tighten with the supplied Allen key. for a lithium battery by holding the MODE button for 1.5 seconds until you’...
-
Page 11: Battery Monitor & Setup
BATTERY MONITOR & SETUP Enter the settings screen by pressing and holding the SET button. Enter the SET1 interface to set the overvoltage value and adjust through the up and down arrows. This value should be 0.5V above the battery’ s stated After setting the overvoltage value, short press the SET button to enter the SET2 interface for the undervoltage settings. -
Page 12: Master Isolation Switch
MASTER ISOLATION SWITCH The master isolation switch instantaneously disconnects any connected devices (except DCDC chargers). Turning the master isolation switch off is a quick way to ensure your battery does not drain. Note: The DCDC charger can still charge the battery whilst the master isolation switch is in the OFF position. -
Page 13: Typical Setup
TYPICAL SETUP... -
Page 14: Specifications
SPECIFICATIONS GoFurther Battery Box External 441 x 240 x 340mm Dimensions External with 441 x 240 x 355mm (LxWxH) DCDC Internal 360 x 174.3 x 234mm 2 x 12V 15A cigarette lighter outputs Outputs USB-C Output 3 x fast charge USB Outputs... - Page 15 DCDC Chargers General Rating Model iTECHDCDC25 iTECHDCDC40 Vehicle Input Voltage 9V – 32V Solar Input Voltage 10V – 32V Max Input Current Input Fuse Rating Continuous Output Current Up to 25A Up to 40A Output Fuse Rating Minimum Auxiliary Battery Charge Start Voltage Standby Current <10mA...
-
Page 16: Safety Precautions
SAFETY PRECAUTIONS The GoFurther Battery Box must be installed and operated correctly for safe operation and optimal performance. Please carefully read, understand and follow all instructions and guidelines in this user guide. Failure to follow these instructions may result in damage to the unit or property, death or serious injury. - Page 17 Failure to do so may lead to permanent damage to the internal electronics and will void the warranty. WARNING: Do not use your GoFurther battery box to connect equipment if there is a defect. WARNING: your battery’ s manufacturer. WARNING: the battery’...
- Page 20 1300 483 249 service@itechworld.com.au www.itechworld.com.au When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to Whether you’re an avid camper, 4WD enthusiast , freedom seeker or...
