- Page 1 Arms for Triple Monitors with VESA Mounts Assembly Guide tooltip IMPORTANT: Different regions may have different models. Please ensure the part number below matches that on your product's box. TR80-TMARM6 Published 2024-6-26...
- Page 2 TABLE OF CONTENTS Symbol Legend Part List Assembly Notes Assembly Instructions...
- Page 3 IMPORTANT: Since there are different versions of each product based on your region, please make sure you are using the correct set of instructions. The part number below should match the one on your box. IMPORTANT: Due to the nature of cut aluminum profiles, some metal shavings may remain despite our thorough QA cleaning process.
-
Page 4: Part Lists
PART LISTS tooltip tooltip tooltip tooltip 880mm Aluminum Profile Bracket (Plate) BM-TA 40x80 End Cap TR-8040-880 BM-TA BP-IS EC-80 tooltip tooltip Vesa Mount Washer (Flat), M8x20 Nut, M8 Washer (Lock), M8 VB-03 M8-LW WF-M8 WL-M8 tooltip tooltip M6X16mm M8X20mm Screw (Flat), M6x16mm Ball Bearing Nut Hex Screw SH-M6-16... - Page 5 NOTE tooltip BACK SIDE TOP SIDE FRONTSIDE OUTSIDE INSTALLATAION ORDER FOR SCREWS & WASHERS HOW TO MEASURE SCREWS ① SCREW ② LOCK WASHER ③ WASHER (IF APPLICABLE) FLAT SCREW HEX SCREW BUTTON SCREW...
- Page 6 NOTE NS-M8 & NS-M6 Slide T-Nuts into the ends of the profiles. Some must be added early, so follow the steps in this manual carefully. If you miss one, tilt it in from the outer edge. Use the Allen key to push it into place, ensuring the hole lines up.
- Page 7 BM-TA SH-M8-20 NS-M8 WF-M8-20 TR-8040-880 tooltip tooltip 880mm M8x20mm M8x20mm tooltip tooltip TR-80B SF-M8-16 M8-LW tooltip tooltip M8x16mm tooltip...
- Page 8 SH-M8-20 NS-M8 WL-M8 WF-M8-20 M8x20mm M8x20mm tooltip tooltip EC-80 tooltip tooltip...
- Page 9 FINISHED Share your build online and tag us to be featured! @trakracer @trakracer @trak_racer...
