  • Page 1 Balder Series User Manual Manual de utilizare UPCMCOP110HBAAZ01B UPCMCOP120HBAAZ01B PWUP-OL150BA-AZ01B PWUP-OL300BA-AZ01B UPCMCOP130HBAAZ01B 141.33.23.0 Before using this product, carefully read all product documentation and retain it for future reference.
  • Page 2 Thank you for purchasing our products! Please read this manual before using the product. nJoy is a brand of power and backup protection products that create solutions for multiple levels of environment complexity, residential to industrial. This UPS will protect your electronic equipment from physical damage and will provide emergency battery backup power to prevent data loss in the event of power problems.

  • Page 3: Product Overview

    Product overview INTELLIGENT PROGRAMMABLE SLOT OUTLETS (P1) Front View 1000/1500/2000/3000 LCD panel INPUT OUTPUT ON/MUTE SELECT OFF/ENTER Function buttons LCD Panel INPUT OUTPUT Battery info Mode operation info Load info Programmable outlet info Backup time info Input and battery voltage info Configuration and fault info Output info Mute operation...
  • Page 4 NOTE! Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Keep the original package in a safe place for future use. Back View Balder 1000&1500 Balder 2000 INTELLIGENT PROGRAMMABLE SLOT OUTLETS (P1) OUTPUT Balder 3000...
  • Page 5 Programable Output protection receptacles: connect to non- USB communication port critical mission loads (max 10A) RS-232 communication port General Output receptacles: SNMP intelligent slot connect to critical mission Emergency power off function loads (max 10A) connector (EPO) AC input Connector for battery pack Network/Fax/Modem surge Important Safety Warnings Please comply with all warnings and operating instructions in this manual...
  • Page 6 • The UPS can be operated by any individuals with no previous experience. • Connect the UPS system only to an earthed shockproof outlet which must be easily accessible and close to the UPS system. • Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your computer) to connect the UPS system to the building wiring outlet (shockproof outlet).
  • Page 7 hazardous voltage exists in the terminals of high capability capacitor such as BUS-capacitors. • Only persons are adequately familiar with batteries and with the required precautionary measures may replace batteries and supervise operations. Unauthorized persons must be kept well away from the batteries.

  • Page 8: Installation

    Installation 4.1 Operating principle The operating principle of the UPS is shown below: Output Input Dynamic Bypass EMI/RFI Rectifier Inverter Filters /PFC DC-to-DC converter Battery Battery Charger The UPS is composed of mains input, EMI/RFI filters, rectifier/PFC, inverter, battery charger, DC-to-DC converter, battery, dynamic bypass and UPS output.
  • Page 9 4.2 Connecting your equipment and first usage The UPS is simple to install and operate. Please read the following steps before connecting any equipments to this UPS: Step 1. Connecting the batteries: For safety consideration, the UPS is shipped out from factory without connecting the battery wires. To re- connect battery wires please follow below steps: I.
  • Page 10 UPS. Polarity mis-connection will cause UPS internal fault. Connect only compatible Balder battery cabinet provided by nJoy. Please read the manual of the UPS and battery cabinet and set the UPS battery total capacity in Ah and the charging current accordingly. The use of another battery cabinet may damage the UPS and void the warranty.
  • Page 11 Step 3. Mounting the UPS: Balder series UPS can be either displayed on the desk or mounted in the 19” rack chassis. Please choose your favourite way to position this UPS. A. Rack - mount installation First fix the holders of the rack on the UPS. Then fix the UPS on the rack through the holders B.
  • Page 12 Step 4. UPS input connection: Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. Step 5. UPS output connection: For socket-type outputs there two kinds of output: programmable outlets and general outlets. Please connect non- critical devices to the programmable outlets and critical devices to the general outlets.
  • Page 13 Step 7. Network connection: Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the UPS unit. Connect from “OUT” outlet to the equipment with another modem/fax/ phone line cable. Network/Fax/Phone surge port: Step 8. Disable and enable EPO function: Keep the pin 1 and pin 2 closed for UPS normal operation.
  • Page 14 Operations 5.1 Button operations ON/MUTE SELECT OFF/ENTER ON/Mute Button • Turn on the UPS: Press and hold ON/Mute button for at least 2 sec- onds to turn on the UPS. • Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 5 seconds to disable or enable the alarm system.
  • Page 15 ON/Mute + Select Button • Switch to bypass mode: When the main power is normal, press ON/ Mute and Select buttons simultaneously for 5 seconds. Then the UPS will enter to bypass mode. This action will be ineffective when the input voltage is out of acceptable range. 5.2 LCD Panel Indicators INPUT OUTPUT...
  • Page 16 Output & Load information Indicates the output voltage and output frequency. Vac: AC voltage, Vdc: DC voltage, Hz: frequency OUTPUT Load information Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%. Indicates overload. Indicates the load or the UPS output is short circuit. Programmable outlets information Indicates that programmable management outlets are working.
  • Page 17 Indicates the inverter circuit is working. Indicates the output is working. Battery information Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%. Indicates the battery is fault. Indicates low battery level and low battery voltage. Input & battery information Indicate the input voltage, input frequency and battery voltage.
  • Page 18 5.4 LCD display wordings index Abbreviation Display content Meaning E N A Enable d 1 5 Disable E S C Escape H L S High loss L L S Low loss b A T Battery b A H Battery AH C H A Charger current C b u...
  • Page 19 Shutdown Over input current Temperature Charger Bypass frequency unstable Battery Replacement EEPROM error Battery Low Over Load Battery No Connect Over Charge Site wiring fault Battery Fault Bypass Out Range...
  • Page 20 5.5 UPS settings 888 888 NOTE! Most parameters can be set only in bypass/standby mode; please set the UPS to bypass/standby mode (see section 5.1) and then change parameters. There are two parameters to set up the UPS. • Parameter 1: For program alternatives.
  • Page 21 03: Output frequency settings Parameter 2: You may set the initial frequency on battery mode: BAT 50: presents output frequency of 50Hz BAT 60: presents output frequency of 60Hz CF 5 00 If converter mode is enabled, you may choose OUTPUT the following output frequency: CF 50: present output frequency is 50Hz...
  • Page 22 07: Bypass voltage range setting Parameter 2: Set the acceptable high voltage point and acceptable low voltage point for Bypass mode by pressing the Down key or Up key. HLS: Bypass high voltage point 26 0 230-264: setting the high voltage point in INPUT parameter 3 from 230Vac to 264Vac.
  • Page 23 10: Programmable outlets setting Parameter 2: Set up backup time limits for programmable outlets. 0-999: setting the backup time limits in minutes from 0-999 for programmable outlets which connect to non-critical devices on battery mode. (Default: 999). 11: Autonomy limitation setting Parameter 2: Set up backup time on battery mode for general outlets.
  • Page 24 Total charging Battery capacity(AH) current (A) 7~20 20~40 40~60 60~80 80~100 100~150 NOTE: If you connect Battery Pack 2U for Balder 1500 to Balder 1500 you should set maximum charger current to 4A. If you connect Battery Pack 2U for Balder 3000 to Balder 3000 you should set maximum charger current to 4A.
  • Page 25 17: External output isolation transformer connection Parameter 2: Allow or disallow external output isolation transformer connection. ENA: If selected, it’s allowed to connect to dI S an external output isolation transformer. DIS: If selected, it’s not allowed to connect to external output isolation transformer. (Default) 18: Display setting for autonomy time Parameter 2: Set up the display setting for...

  • Page 26: Operating Mode Description

    5.6 Operating mode description Operating mode Description LCD display When the input voltage is within acceptable range, UPS will provide pure 23 0 23 0 Online mode and stable AC power to INPUT OUTPUT output. The UPS will also charge the battery in online mode.
  • Page 27 UPS is powered off and there is no output supply 23 0 Standby mode power, but the UPS still INPUT OUTPUT can charge batteries. When a fault has occurred, the ERROR icon Fault mode and the fault code will be INPUT OUTPUT displayed.
  • Page 28 5.8 Warning indicator Icon Warning Code Alarm (flashing) Sounding every 2 Low Battery seconds Sounding every Overload second Sounding 2 beep Over input current every 10 seconds Battery is not Sounding every 2 connected seconds Sounding every 2 Over Charge seconds Sounding every 2 Site wiring fault...

  • Page 29: Replacing The Battery

    Replacing the battery NOTE! This UPS is equipped with internal batteries. When your battery lifetime is over you can replace them without shutting down the UPS or connected loads thanks to the hot-swappable battery design. Replacement is a safe procedure, isolated from electrical hazards.
  • Page 30 Step 5. After replacing the Step 6. Re-connect the battery batteries, put the battery box wires and put the front panel back to original location and back to the unit. screw it tightly.
  • Page 31 6.1 Battery kit assemly procedure Balder 1000 / 1500 Step 1. Remove adhesive tapes. Step 2. Connect all battery terminals by following below chart. Tapes Tapes Step 3. Put assembled battery Step 4. Cover the other side of packs on one side of plastic plastic shell as in the below shells.
  • Page 32 Balder 2000 / 3000 Step 1. Remove adhesive tapes. Step 2. Connect all battery terminals by following below chart. Step 3. Put assembled battery Step 4. Cover the other side of plastic packs on one side of plastic shell as in the below picture. shells.

  • Page 33: Troubleshooting

    Troubleshooting Problem Possible cause Solutions Check if input The AC input power cord is power is not firmly connected connected well. No indication and alarm even to the mains. though the main is normal. The AC input is Plug the AC input connected to the power cord to the UPS output.
  • Page 34 UPS is overloaded. UPS is overloaded. Remove excess Devices connected loads from UPS to the UPS are output. fed directly by the electrical network The icon via the Bypass. are flashing on LCD display. Alarm is sounding every second. After repetitive overloads, the Remove excess UPS is locked in...
  • Page 35 A UPS internal fault has occurred. There are two possible results: Fault code is shown as 01, 1. The load is 02, 03, 11, 12, 13 and 41 Contact service still supplied, but on LCD display and alarm is unit. directly from AC continuously sounding.
  • Page 36 Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
  • Page 37 Va rugam cititi cu atentie manualul de utilizare inainte de a pune in functiune acest produs. nJoy este un brand de solutii UPS dedicate protectiei si rezervei de energie din diferite medii de utilizare, de la rezidential la industrial UPS-ul va protejeaza echipamentele electronice de daune fizice si ofera o baterie de rezerva pentru a preveni pierderile de date in cazul intreruperilor accidentale ale energiei electrice.

  • Page 38: Prezentarea Produsului

    Prezentarea produsului INTELLIGENT PROGRAMMABLE SLOT OUTLETS (P1) Vedere din fata 1000/1500/2000/3000 Ecran LCD INPUT OUTPUT ON/MUTE SELECT OFF/ENTER Butoane Ecran LCD INPUT OUTPUT Informatii si nivel baterie Informatii mod operare Informatii si nivel incarcare Informatii prize programabile Informatii timp de backup Informatii tensiune de intrare Erori si configuratii si stare baterie...
  • Page 39 NOTA! Portul HID USB este disponibil doar pentru modelele Balder 1000, Balder 1500, Balder 2000 and Balder 3000. Vedere din spate Balder 1000&1500 Balder 2000 INTELLIGENT PROGRAMMABLE SLOT OUTLETS (P1) OUTPUT Balder 3000...
  • Page 40 Prize de iesire programabile pentru Retea / Fax / Modem destinate echipamentelor non- Port comunicare USB critice (max 10A) Port comunicare RS-232 Prize de iesire programabile Slot pentru cardul SNMP destinate echipamentelor Conector pentru functia EPO critice (max 10A) (oprire de urgenta) Alimentare AC Conector pentru cabinetul de Priza protectie supratensiune...
  • Page 41 • UPS-ul poate fi folosit de orice persoana, fara a necesita nicio experienta anterioara. • Conectati sistemul UPS numai la o priza cu impamantare, care trebuie sa fie usor accesibila si aproape de sistemul UPS. • Va rugam sa folositi numai cabluri de alimentare testate VDE si cu marcaj CE (de exemplu: cablul de alimentare de la computer) pentru a conecta sistemul UPS la reteaua electrica a cladirii.
  • Page 42 ar fi condensatorul BUS. • Numai persoanele care sunt familiarizate in mod adecvat cu baterii si cu masurile de precautie necesare pot inlocui bateriile si supraveghea operatiunile. Persoane neautorizate trebuie sa fie tinute departe de baterii sistemului UPS. • Atentie - risc de soc electric. Circuitul bateriei nu este izolat de tensiunea de intrare.
  • Page 43 Instalare 4.1 Principiu de functionare Principiul de functionare a acestui UPS este urmatorul: Output Input Dynamic Bypass EMI/RFI Rectifier Inverter Filters /PFC DC-to-DC converter Battery Battery Charger Sursa neintreruptibila de tensiune are in componenta sa: intrarea de la retea, filtrele pentru EMI / RFI (interferente electromagnetice / interferente radio-frecventa), redresorul si PFC (corectia factorului de putere), incarcatorul bateriilor, bateriile, convertorul DC-DC (tensiune continua la tensiune continua), invertorul, bypassul dinamic si iesirea...
  • Page 44 4.2 Conectarea echipamentelor si prima folosire UPS-ul este simplu de folosit si de instalat. Urmati pasii de mai jos inainte de a conecta echipamentul la UPS: Pasul 1. Conectati bateriile: Pentru masuri de siguranta, UPS-ul este livrat fara sa aiba conectate cablurile bateriei. Pentru a reconecta aceste cabluri va rugam sa urmati pasi de mai jos: I.
  • Page 45 UPS). Polaritatea inversata va aduce daune UPS-ului. Folositi doar cabinete de baterii nJoy compatibile cu seria Balder. Va rugam sa cititi manualul de utilizare al UPS-ului si al cabinetelor de baterii si sa setati valoarea capacitatii totale a bateriilor in Ah si curentul de incarcare in consecinta.
  • Page 46 la deteriorarea UPS-ului si la pierderea garantiei. Pasul 3. Montarea UPS-ului: Acest model de UPS poate sa fie pozitionat fie vertical fie orizontal - montat intr-o carcasa rack de 19”. Va rugam sa alegeti pozitia in care doriti sa pozitionati UPS. A.
  • Page 47 Pasul 4. Conexiune de intrare UPS: Conectati UPS-ul la priza tripolara, impamantata. Nu utilizati prelungitoare. Pasul 5. Conexiune de iesire UPS: Pentru iesirile de tip priza exista doua variante: prize programabile si prize generale. Conectati dispozitivele non-critice la prizele programabile si dispozitivele critice la prizele generale.
  • Page 48 Pasul 7. Conexiunea in retea: Conectati o linie de modem/telefon/fax in priza protejata IN ce se afla in spatele UPS-ului. Conectati in priza OUT echipamentul cu o alta linie de modem/telefon/fax. Port Retea/Fax/Telefon: Pasul 8. Activati si dezactivati functia EPO: Tineti pin-ul 1 si 2 inchisi pentru modul de operare normal al UPS-ului.
  • Page 49 Operatii 5.1 Butoane ON/MUTE SELECT OFF/ENTER Butonul ON/Mute • Pornirea UPS-ului: Apasati si tineti apasat butonul ON / Mute pent- ru cel putin 2 secunde pentru a porni UPS-ul. • Oprirea alarmei: Cand UPS-ul este in modul de baterie, tineti apasat acest buton timp de cel putin 5 secunde pentru a activa sau dezactiva sistemul de alarma.
  • Page 50 ON/Mute + Butonul de Selectare • Comutarea la modul de bypass: Atunci cand tensiunea la retea este normala, apasati butoanele ON / Mute si Select simultan pentru 5 secunde. In acest fel, UPS-ul va intra in modul de bypass. Aceasta actiune va fi ineficienta atunci cand tensiunea de intrare este in afara intervalului acceptabil.
  • Page 51 Informatii despre tensiunea de iesire, nivel baterie si nivel incarcare Indica voltajul la intrare, frecventa la intrare, curentul electric la intrare, voltajul bateriei, curentul electric al bateriei, nivel baterie, temperatura ambientala, voltajul la iesire, frecventa la iesire, incarcare curent electric si nivel OUTPUT de incarcare in procente.
  • Page 52 Indica faptul ca circuitul invertorului functioneaza. Indica faptul ca este tensiune la iesire. Battery information Indica nivelul de incarcare astfel: 0-24%, 25-49%, 50- 74%, si 75-100%. Indica eroare baterie. Indica baterie slaba. Informatii despre tensiunea de intrare, nivel baterie si nivel incarcare Indica tensiunea la intrare, frecventa si tensiunea bateriei.
  • Page 53 5.4 Index Afisaj LCD Abreviere Cod ecran Semnificatie E N A Activat d 1 5 Dezactivat E S C Renunta H L S Prag superior L L S Prag inferior b A T Baterie b A H Amperaj baterie C H A Curent de incarcare C b u Incarcare rapida...
  • Page 54 Pornit Inchidere Supra-curent la intrare Temperatura Incarcator Frecventa de bypass instabila Inlocuieste bateriile Eroare EEPROM Baterie slaba Supra-incarcare Bateriile nu se conecteaza Supra-incarcare Eroare la cablurile de conectare Eroare baterie Bypass in afara ariei acceptate...
  • Page 55 5.5 Setari UPS 888 888 NOTA! Majoritatea paremetrilor pot fi setati doar in mod standby sau bypass. Setati prima oara UPS-ul in mod standby sau bypass (vezi sectiunea 5.1) si apoi setati parametrii. Exista doi parametrii de setari. • Parametrul 1: Pentru alternative de program.
  • Page 56 03: Setarea frecventei la iesire Parametrul 2: Setare frecventa iesire. Puteti seta frecventa initiala in modul baterie: BAT 50: frecventa de iesire este 50Hz BAT 60: frecventa de iesire esteHz CF 5 00 Daca modul de conversie este activat, atunci OUTPUT puteti selecta urmatoarele frecvente de iesire: CF 50: frecventa de iesire este 50Hz...
  • Page 57 07: Setarile plajei tensiunii de bypass Parametrul 2: Stabiliti valoarea maxima, respectiv minima acceptata a tensiunii pentru modurile Bypass prin apasarea butoanelor Down si Up. HLS: Pragul superior de tensiune pentru Bypass. 230-264: setarea valorii de sus a pragului de 26 0 tensiune este in parametrului 3 de la 230V la INPUT...
  • Page 58 10: Setari pentru prizele programabile Parametrul 2: Seteaza limita timpului de backup al prizelor de iesire programabile. 0-999: puteti seta limita timpului de backup de la 0-999 pentru prizele programabile care sunt conectate la dispozitive necritice in mod baterie. (implicit: 999) 11: Setari privind limitele de autonomie Parametrul 2: Stabileste timpul de backup pentru prizele generale in modul baterie.
  • Page 59 Curent de incarcare Capacitate baterie (AH) total (A) 7~20 20~40 40~60 60~80 80~100 100~150 NOTA: Daca la modelele Balder 1500 si 3000 este conectat cabinetul de baterii 2U atunci valoarea maxima a curentului de incarcare va fi 4A. 14: Setari tensiune de incarcare rapida a bateriei Parametrul 2: Seteaza valoarea tensiunii de incarcare.
  • Page 60 17: Conectarea unui transformator de izolare extern Parametrul 2: Permite sau nu conectarea unui transformator de izolare extern. ENA: Daca este selectata aceasta optiune, este permisa conectarea unui transformator dI S de izolare extern. DIS: Daca este selectata aceasta optiune, nu este permisa conectarea unui transformator de izolare extern.
  • Page 61 5.6 Descrierea modului de operare Mod de operare Descriere Afisaj ecran Atunci cand tensiunea de intrare este in intervalul acceptabil, UPS-ul va 23 0 23 0 Mod Online asigura curentul pur si INPUT OUTPUT stabil catre iesire. UPS-ul va incarca in acelasi timp si bateria in modul online.
  • Page 62 UPS-ul este oprit si nu exista tensiune de iesire, 23 0 Mod Standby dar acumulatorii se INPUT OUTPUT incarca. UPS-ul trece in mod eroare, caz in care nu va Mod Eroare furniza tensiune de iesire INPUT OUTPUT iar iconita de eroare va clipi pe ecran.
  • Page 63 5.8 Indicatori de atentionare Icoana Avertizare Alarma (palpaie) Suna la fiecare 2 Baterie descarcata secunde Suna la fiecare Suprasarcina secunda Supra sarcina la iesire Suna de 2 ori la fiecare 10 secunde Bateria nu este Suna la fiecare 2 conectata secunde Suna la fiecare 2 Supraincarcare...
  • Page 64 Inlocuirea bateriei NOTA! Acest UPS este echipat cu baterii interne si utilizatorul poate sa inlocuiasca bateriile fara sa opreasca UPSul sau sarcinile conectate. Inlocuirea bateriei este o procedura sigura, lipsita de pericole electrice. ATENTIE Luati in considerare toate avertismentele, atentionarile si notele inainte de inlocuirea bateriilor.
  • Page 65 Pasul 5. Dupa ce ati inlocuit Pasul 6. Reconectati cablurile bateriile, puneti cutia bateriei bateriei si puneti panoul frontal inapoi in locatia originala si inapoi. insurubati strans.
  • Page 66 6.1 Procedura de asamblare a kit-ului de baterii Balder 1000 / 1500 Pasul 1. Indepartati benzile Pasul 2. Conectati toate bornele adezive. bateriei urmarind graficul de mai jos. Tapes Tapes Pasul 3. Puneti acumulatorii pe Pasul 4. Acoperiti cealalta parte o parte a capacului de plastic.
  • Page 67 Balder 2000 / 3000 Pasul 1. Indepartati benzile Pasul 2. Conectati toate bornele adezive. bateriei urmarind grafica de mai jos. Pasul 3. Puneti acumulatorii pe o Pasul 4. Acoperiti cealalta parte parte a capacului de plastic. a carcasei de plastic conform graficii de mai jos.
  • Page 68 Probleme si Solutii Problema Cauza posibila Solutie Verificati daca Cablul de curent cablul de curent nu este conectat este conectat la corespunzator. Indicatoarele nu se aprind si reteaua electrica. alarma nu functioneaza, chiar Conectati daca curentul este normal. Reteaua electrica cablul de curent este conectata la corespunzator, la...
  • Page 69 UPS-ul se afla in suprasarcina. UPS-ul se afla in suprasarcina. Inlaturati sarcinile Dispozitivele in exces din iesirile conectate la UPS UPS-ului. sunt alimentate direct din reteaua Icoanele palpaie electrica prin pe ecranul LCD. Bypass. Alarma suna la fiecare Dupa suprasarcini secunda.
  • Page 70 O eroare interna a avut loc. Exista doua posible rezultate: Codul de eroare este afisat ca 1. Sarcina este Contactati 01, 02, 03, 04, 11, 12, 13 sau inca furnizata, dar unitatea de 41 pe panoul LCD si alarma direct de la sursa service.
  • Page 71 Dezafectarea echipamentelor electrice si electronice vechi (Se aplica pentru ţarile membre ale Uniunii Europene si pentru alte tari europene cu sisteme de colectare separata). Acest simbol aplicat pe produs sau pe ambalajul acestuia indica faptul ca acest produs nu trebuie tratat ca pe un deseu menajer. El trebuie predat punctelor de reciclare a echipamentelor electrice si electronice.
  • Page 72 Memo...
  • Page 73 Memo...

  • Page 74: Eu Declaration Of Conformity

    EU Declaration of Conformity We, manufacturer / importer DAI-TECH SA Str. Berlin, Nr 6, C.P. 307160, Dumbrăvița, Timiș, România declare that the products UPS BALDER SERIES: UPCMCOP110HBAAZ01B UPCMCOP120HBAAZ01B PWUP-OL150BA-AZ01B PWUP-OL300BA-AZ01B UPCMCOP130HBAAZ01B are in conformity with (EC conformity marking) Tested with the listed standards, the above mentioned products were found in compliance with 2004/108/EC EMC Directive and with...
  • Page 75 Declaratie UE de conformitate Noi, in calitate de producator / importator DAI-TECH SA Str. Berlin, Nr 6, C.P. 307160, Dumbrăvița, Timiș, România declaram ca urmatoarele produse UPS BALDER SERIES: UPCMCOP110HBAAZ01B UPCMCOP120HBAAZ01B PWUP-OL150BA-AZ01B PWUP-OL300BA-AZ01B UPCMCOP130HBAAZ01B sunt conforme cu (simbolul de conformitate europeana) Testate in standardele acceptate, produsele mentionate sunt conforme cu directiva 2004/108/EC EMC...
