Inspiration AlphaCore5 Instructions For Use Manual page 43

19. Technical Description and Specification
Patient Probe
Connection
Thermistor Type
Construction Materials
AlphaCore Housing
5
AlphaCore Front Fascia
5
Connection Cable Outer Sheath
Mattress
Mattress Construction
Blanket
Blanket Construction
Physical Characteristics
AlphaCore Weight
5
AlphaCore Dimensions (W, H, D)
5
Clamp Properties
Mattress/Blanket Dimensions
Part Number Type
IHC-OTM1 Mattress
IHC-OTM1-N Mattress
IHC-OTM2 Mattress
IHC-OTM2-N Mattress
Inspiration Healthcare Limited
W inspiration-healthcare.com
ODU Medi-snap, Series 1, 2 pin, 0° key
Type R25: 2252 Ohms
PC–ABS
Polyester
PVC
Dartex
Inditherm
pressure relief pad under, and expanded polyester comfort
lining over. Encapsulated in a nylon fabric cover with
non-microporous polyurethane coating, fully sealed with
welded seams.
In-built temperature sensor and over-temperature thermal
cut-out.
Dartex
Inditherm
polyester and synthetic fibre thermal comfort lining.
Encapsulated in a nylon fabric cover with non-microporous
polyurethane coating, with sewn seams.
In-built temperature sensor and over-temperature thermal
cut-out.
Description
1.7 Kg
187mm x 183mm x 144mm (181mm with clamp fitted)
Up to 40mm rail or pole, vertical or horizontal orientation
Dimensions Part Number
1900mm x 585mm IHC-GTM1
1900mm x 535mm IHC-GTM1-N
1200mm x 585mm IHC-RB1
1200mm x 535mm
© 2021 Inspiration Healthcare Limited
Patient Warming System Instructions for Use
continued
Polyurethane Black
TM
® flexible polymer heating sheet with 18mm foam
Polyurethane Blue
TM
flexible polymer heating sheet, with expanded
®
Type Dimensions
Mattress 1070mm x 585mm
Mattress 1070mm x 535mm
Blanket 1660mm x 800mm
43
700-307 Revision: 10
