Memoq SR-600 User Manual

SR-600 User's Manual
Wristwatch Type Voice Recorder
* We are not responsible for the loss of recordings caused by wrong usage, A/S, other reasons.
* We are not responsible for the damage or third party's claims caused by the usage of this product.
* Disassembly, remodeling, impact, the usage in place of low temperature, high temperature, high humidity
Cautions in use
can be the cause of failure.
* Please save the important recordings into PC frequently.
* This product supports water resistance.
* For normal use of water resistance, read the following carefully.
* Failure to comply with the following may result in damage to the product or no performance guarantees.
* Avoid exposure to contaminated water, chemicals etc.
* Do not use products when diving or water sports.
Water resistance
* Don't put excessive water pressure on the product. (For example, water from a faucet)
* If the product is damaged or damaged by an external impact, the water resistance may deteriorate.
* Don't take it apart yourself. Damage to the water resistance may occur.
* If the product is submerged or the microphone is wet, smooth operation may be difficult.
Dry the product completely before using it.
ⓐ ⓑ
Recording sign
ⓔ
Microphone ⓕ
Battery Indicator
ⓔ
ⓐ
Name of each part
&
ⓑ
components
ⓒ
<Product components>
①
Watch strap
Main body
Installing and
separating
the watch strap
※Install the main body to watch strap.
1. Install the directions of body USB terminal(ⓓ)
and watch strap(ⓗ) to be exactly the same.
2. Push the front of the main body from bottom to top.
Caution : Do not overextend the watch strap ⓗ. It may be deformed or damaged.
R-R-ESO-SR-180
ⓒ ⓓ
Time display Day and date display USB terminal
ⓖ ⓗ ⓘ
Recording button Watch strap Microphone hole
ⓕ
ⓖ
ⓗ
ⓓ
<Watch strap>
①
Watch strap
②
Main
body
②
※Separate the main body from watch strap.
1. Bend the watch strap(ⓗ) back.
2. Push the front of the main body
outwards the watch strap(ⓗ)
* The product has a built-in battery and can be used after charging.
* Charging starts when the product's USB terminal(ⓓ) is connected to the PC's USB port or a charging adapter (optional).
Charging
* During recording, you can check the remaining battery status according to the Battery indicator(ⓕ) displayed on the watch screen.
* When charging is complete, the screen turns off, and you can turn it on again by pressing the recording button.
* When this device is connected into the USB port of PC, it is recognized as a "Removable disk (MEMOQ)",
ⓘ
* For playback, please use the music playback software of PC.
Connecting
PC USB
How to use time setting program
1. After connecting the product's USB terminal(ⓓ) to the PC's USB port, run the "TIME SETUP" program stored in the product.
Setting the
recording
function
2. After checking the settings according to the usage environment, click the "START" button.
3. If the "DATE_TIME.CFG" file is normally created in the product, disconnect the product from
Instructions for use
Caution : Be sure to use a certified charging adapter (rated output DC5V/500mA or higher).
Damage to the product due to a defective charging adapter may result in paid repair.
Caution :Charging will not start if the USB terminal(ⓓ) is connected in the wrong direction.
Battery remains indication.
Low battery under 20% 20~50% 50~80%
and copy, movement, deletion, playback of file is possible.
Caution : Do not connect to the PC USB port or charing adapter(option) when the USB terminal(ⓓ) is wet.
Caution : When you separate product from PC, please be sure to perform "hardware safety removal".
When you remove product from PC by force, fatal error on product can occur.
The time setting program only works on Window OS. (not for Mac).
V002
VOS ON/OFF
(Basic setting : VOS OFF) Mode (Record Quality) VOS On/Off VOS Level REC Display
PCM VOS Off +2 LCD On
(Basic setting)
(Basic setting) (Basic setting)
XHQ (Basic setting) +1
VOS On LCD Off
Recording sound quality
HQ 0
SP -1
(Basic setting : XHQ)
LP -2
Schedule Recording Themes
Off (Basic setting) A - Theme
(Basic setting)
Scheduled Recording B - Theme
On
C - Theme
(Basic setting : OFF)
12h 24h
(Basic setting)
2023-01-01 13:00:00
DATE_TIME.CFG
Creation button
the USB port to complete the setting.
Caution : The date and time set on the PC are displayed.
If the date and time are displayed differently, please check the PC settings.
Caution : If the product is not separated immediately after clicking the START button,
a time error will occur as much as the delayed time.
Caution : If the product is not separated from the PC after clicking the START button, the setting will not be completed.
※ first method
Flip the watch strap(ⓗ)
backwards to connect the USB.
※ second method
Separate the watch strap(ⓗ)
and connect the USB.
80~100%
VOS Level
(Basic setting : +2)
REC Display
MIC Sense
High (Basic setting : LCD On)
Middle
Microphone sensitivity
(Basic setting)
Low
(Basic setting : Middle)
Watch screen theme
(12/24-hour system)
(Basic setting : A Theme / 24-hour-system)
Current date and time
