- Page 1 Owner's Manual Before connecting, operating or adjusting this product, please read this owner's manual carefully and completely. Designs and specifications are subject to change without notice for provement.
-
Page 2: Table Of Contents
8. Play Back Mode Selection ........8 16-2. EQ setting the EQ ........16 16-10. Formatting ..........20 Table of Contents 9. Recording ............. 9 (playing characteristics) 16-11. Exiting from the mode setting ....20 10. Adjustment of Mike Sensitivity ......10 16-3. -
Page 3: Safety Note
1. Safety Note • This manual is for preventing the user and his/her property from being damaged, so please read it thoroughly before using. • We are not responsible for the loss from using this product and the claim by the third party. •... -
Page 4: Denomination Of Each Part
2. Denomination of Each Part... -
Page 5: Explanation Of Lcd Screens
3. Explanation of LCD Screens Folder Name Music File Name File Name... -
Page 6: Preferation Before Using(Charging)
4. Preferation before Using(Charging) • This unit include a battery • Perchased product should be charged by connection with USB terminal and PC USB port (or USB PC adabter) • Charged condition can be verified by LED power on made as below •... -
Page 7: Usage Of Dc Power
6. Usage of DC Power • This unit can be charged and operated by using a external DC adapter. 6-1. PC USB Port Power Usage • Connect this unit to PC USB terminal • LED screen will show when USB is connected. •... -
Page 8: Power On/Off
7. Power On/Off • If you press more than 3 seconds LED screen MemoQ will appear and disappear than the contact will be on stand by in the last recorded folder. 8. Play Back Mode Selection • At stand by mode, push jog button " - " direction about 3 seconds, Music mode will change to Voice mode and then Voice mode to Music Mode. -
Page 9: Recording
9. Recording • When power off connection, press REC button for more than 3 seconds. Power will come on and recording will start. • When power on connection, press REC button. Briefly recording will start. • Recorded file types are mp3 or PCM file, interchanger abillity is excellent and recorded in th selected folder. -
Page 10: Adjustment Of Mike Sensitivity
10. Adjustment of Mike Sensitivity • It is possible to adjust Microphone Sensitivity during Recording or Mode selection. • During recording Mic Sensitivity adjustment will happen when the(+ button) is pressed for more than 3 second (Normal High) happend, the(- button) is pressed for more than 3 seconds High Normal will happend NORMAL HIGH... -
Page 11: Playing The Recorded File
11. Playing the Recorded File • The play mode should be set as VOICE for playing the recorded file. • At the ready state, pressing the PLAY button starts playing. Pressing the PLAY button toggles between pausing and playing. • While pausing or playing, pushing the jog button to Previous (<) or Next (>) direction moves to the previous or next file within the selected folder. -
Page 12: Controlling The Play Speed
13. Controlling the Play Speed • Whenever you push and hold the jog button to the (+) direction for 3 seconds or longer while playing, the play speed can be sequentially selected within the playing file by the order of -20%, -10%, NORMAL, +10% and +20%. •... -
Page 13: Uploading / Downloading Files
• If the voice file is saved at A, B, C or D folder within the “VOICE” folder and the music file is saved at the “MUSIC” folder, the files can be played with the best quality. Saved Music File Saved Voice File <Screen showing connection to the PC <Folder tree> as MemoQ (F:) portable disk>... -
Page 14: Browsing Folder And File
15. Browsing Folder and File • The browsing function searches for the file, which can search for the file to play immediately even while playing. • Pressing the MODE(PLAY) button while pausing or playing for more than 3 seconds, then switches to the BROWSE mode •... -
Page 15: Setting The Mode
16. Setting the Mode • The mode setup sets erasing files, EQ (playing characteristics), repeated playing, microphone sensitivity, recording characteristics, LCD screen display, automatic sensitivity control, setting the ready-to-record, selecting the recording folder and setting the VOS(Voice Operation System). • At the ready (stop) state, pushing the Jog button to the volume (+) direction for 3 seconds or longer switches to the mode selection •... -
Page 16: Erase (Deleting The File)
16-1. Erase (Deleting the file) 16-2. EQ setting the EQ (playing characteristics) • Play the file to delete, and check its contents. • At the EQ mode screen, Use Previous (<) or Next (>) jog button • Press the PLAY button again to pause. to select the playing characteristics (EQ). -
Page 17: Rep(Repeated Playing) Setting
16-3. REP(repeated playing) Setting 16-4. Setting the MIC (microphone) Sensitivity • The repeated playing can be set to OFF, 1, ALL or FOLDER. • The microphone sensitivity can be selected as normal(4m) or • At the REP screen, use Previous (<) or Next (>) jog button to high(8m). -
Page 18: Setting The (Recording) Mode
16-5. Setting the (recording) Mode 16-6. Setting the LOW CUT Mode • The recording mode can be set to long-playing (LP), high quality • At screen, use Previous (<) or Next (>) jog button to select ON/ (HQ), extra high quality (XHQ) or CD quality(PCM) depending OFF. -
Page 19: Selecting The Lcd
16-7. Selecting the LCD 16-8. Setting the Voice Operation System (VOS) • At screen, use Previous (<) or Next (>) jog • At screen, use Previous (<) or button to select ON, 3, 10, 30, 60 seconds Next (>) jog button to select ON or OFF. •... -
Page 20: Selecting The Recording Folder
• At screen,push the jug button to Next (>) direction 16-9. Selecting the Recording Folder to select ‘FORMAT YES’. And when you press the MODE key at the selected screen, the screen for confirming whether to format is displayed. • The folder selection function saves the recording file at the selected When you select ‘YES’... -
Page 21: Using Ball-Point Pen
17. Using Ball-point Pen • With catching main product and after combine turning ④(holder case) to right side, you can use it as ball-point pen. >> Using as ball-point pen Catching ④(Holder case) if turn ③(front case) to right and left, and then ball-point pen lead out or comes >>... -
Page 22: Using Gender
18. Using Gender • Listening and recording outside input by earphone combining Gender in main product • Be careful when combine ⑦(USB terminal) and ⑥(USB jack) direction . 18-1 Listening by Earphone • Connect earphone to ⑤(earphone/microphone of Gender terminal) and can listen the recording contents and music. 18-2. -
Page 23: By Using Land Line Phone Adaptor And Eecording Phone Call (Option)
18-3. By Using Land Line Phone Adaptor and Eecording Phone Call (option) • Connect Audio cable to ⑤(earphone/microphone terminal), and other one to land line phone adaptor. Line cable of telephone connects as follows. Caution • Keyphone telephone can not become recording according to kinds of telephone. -
Page 24: Warranty Card Specifications
WARRANTY CARD SPECIFICATIONS...
