Engine Dimensions - Mounting Surface View
I
H
G
A 232.0 mm (9.13 in.)
E 106.0 mm (4.17 in.)
I 16.0 mm (0.63 in.)
62 690 01 Rev. J
All manuals and user guides at all-guides.com
8 X 10.3 mm (0.40 in.)
B
Thru Mounting Holes
PTO Mounting
F
Surface
KohlerEngines.com
A
F
E
C Mounting Hole "A"
G 135.0 mm (5.32 in.)
Specifications
B
C
D
D 239.5 mm (9.43 in.)
H 119.0 mm (4.69 in.)
