Kohler Command PRO Service Manual page 72

Reassembly
Breather/Closure Plate/Oil Reservoir Components
O
P
Q
A
B
U
V
A Closure Plate
E Relief Valve Baffle
I Pickup Screen
Crankshaft Thrust
M Bearing
(Flange PTO)
Q Breather Assembly
U Lifting Strap
72
All manuals and user guides at all-guides.com
T
R
E
D
S
C
G
H
M
F
H
J
B Gerotor Gears
F Pickup Tube
J Oil Reservoir
N Closure Plate Gasket
R Breather Gasket
V Oil Seal
KohlerEngines.com
W
N
K
L
I
K
C Oil Pump O-ring
G Clamp
K Drain Plug
O Dipstick
S Filter
Crankshaft
W Non-Thrust Bearing
(PTO)
N
D Oil Pump Housing
H Inlet Seal
L Gasket
P Dipstick Tube
T Breather Hose
62 690 01 Rev. J
