Kohler Command PRO Service Manual page 15

TORQUE SPECIFICATIONS
Control Panel
M6 screw
M5 screws
Crankcase
Breather Cover Fastener
Oil Drain Plug
Cylinder Head
Cylinder Head Fastener (torque in 2 increments)
Head Bolt
Pipe Plug (3/4 in.)
Rocker Arm Screw
Debris Screen
Fastener
Hex Stud
Mounting Screw - Hex Flange Screw
Mounting Screw - Button Head Cap Screw
Front Drive Shaft Screw (into flywheel)
Fan/Flywheel
Fan Fastener Screw - Truss Head
Fan Fastener Screw - Hex Head
Flywheel Retaining Screw
Governor
Governor Lever Nut
Governor Yoke Mounting Screw
Ignition
Spark Plug
Ignition Module Fastener
Rectifier-Regulator Fastener
Lifter Feed Chamber
Cover/Baffle Screw
Muffler
Retaining Nut
M6 Screw
M8 Screw
Oil Cooler
Mounting Screws
Values are in Metric units. Values in parentheses are English equivalents.
3
Lubricate threads with engine oil prior to assembly.
5
62 690 01 Rev. J
All manuals and user guides at all-guides.com
3,5
KohlerEngines.com
CH940 CH960 CH980
11.3 N·m (100 in. lb.) into new holes
7.7 N·m (69 in. lb.) into used holes
6.5 N·m (58 in. lb.) into new holes
4.1 N·m (37 in. lb.) into used holes
12.4 N·m (110 in. lb.)
21.4 N·m (16 ft. lb.)
first to 23.7 N·m (210 in. lb.)
finally to 46.9 N·m (415 in. lb.)
28.5 N·m (252 in. lb.)
15.5 N·m (137 in. lb.)
9.9 N·m (88 in. lb.)
21.5 N·m (190 in. lb.)
20.3 N·m (180 in. lb.)
9.9 N·m (88 in. lb.)
24.4 N·m (216 in. lb.)
10.4 N·m (92 in. lb.)
9.9 N·m (88 in. lb.)
69.8 N·m (51 ft. lb.)
7.1 N·m (63 in. lb.)
2.2 N·m (20 in. lb.)
27 N·m (20 ft. lb.)
9.7 N·m (86 in. lb.) into new holes
4.1 N·m (37 in. lb.) into used holes
2.5 N·m (22 in. lb.)
7.7 N·m (68 in. lb.)
24.4 N·m (216 in. lb.)
9.9 N·m (88 in. lb.)
24.4 N·m (216 in. lb.)
2.3 N·m (21 in. lb.)
Specifications
CH1000
15
