Remove Oil Cooler
NOTE: New clamps are recommended any time
disassembly is performed, or if clamps have
been loosened (expanded) several times.
1. Remove oil cooler mounting screws. Do not lose any
washers (if used).
2. Loosen clamps and disconnect hoses from oil
cooler.
Remove Oil Filter Housing and Oil Filter Adapter
NOTE: Further disassembly of oil filter housing
assembly is not required unless being serviced
individually. Follow substeps a, b, and c.
62 690 01 Rev. J
All manuals and user guides at all-guides.com
KohlerEngines.com
Disassembly/Inspection and Service
1. Remove screw securing oil filter housing and
individual O-rings to adapter. Carefully separate
parts.
Perform following only if oil filter housing assembly
requires individual servicing.
a. Remove nipple from cup and oil filter housing.
b. Remove oil filter cup and spring from housing.
c. Remove rubber valve and spring from cup.
2. Remove screw securing oil filter adapter and
individual O-rings to crankcase, then carefully
separate parts.
55
