Specifications
TORQUE SPECIFICATIONS
Oil Filter Adapter/Housing
Adapter/Housing Mounting Screw
Oil Filter Nipple
Oil Pickup Screen
Mounting Screw
Oil Pickup Tube
Mounting Screw
Oil Pump
Mounting Screw
Oil Sentry
TM
Pressure Switch
Reservoir (oil)
Mounting Screw
Solenoid (starter)
Mounting Hardware
Nut, Positive (+) Brush Lead
Starter Assembly
Thru Bolt
Mounting Screw
Brush Holder Mounting Screw
Stator
Mounting Screw
Throttle/Choke Control Bracket
Fastener
Valve Cover
Valve Cover Fastener

CLEARANCE SPECIFICATIONS

Camshaft
End Play
Running Clearance
Bore I.D.
New
Max. Wear Limit
Bearing Surface O.D.
New
Max. Wear Limit
Values are in Metric units. Values in parentheses are English equivalents.
3
Lubricate threads with engine oil prior to assembly.
5
16
All manuals and user guides at all-guides.com
3,5
3
KohlerEngines.com
CH940 CH960 CH980
23.7 N·m (210 in. lb.)
17.8 N·m (158 in. lb.)
9.3 N·m (82 in. lb.) into new holes
7.7 N·m (68 in. lb.) into used holes
11.3 N·m (100 in. lb.) into new holes
7.7 N·m (68 in. lb.) into used holes
9.9 N·m (88 in. lb.)
10.7 N·m (95 in. lb.)
25.6 N·m (227 in. lb.)
4.0-6.0 N·m (35-53 in. lb.)
8.0-11.0 N·m (71-97 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
16.0 N·m (142 in. lb.)
2.5-3.3 N·m (22-29 in. lb.)
9.3 N·m (82 in. lb.)
10.2 N·m (90 in. lb.)
13.6 N·m (120 in. lb.)
CH940 CH960 CH980
0.3/1.3 mm (0.011/0.051 in.)
0.025/0.063 mm (0.0010/0.0025 in.)
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
CH1000
CH1000
62 690 01 Rev. J
