Kohler Command PRO Service Manual page 86

Reassembly
Install Control Panel (if equipped)
Control Panel Component
A
A
Control Panel
1. Install control panel to main control bracket and oil
filter housing. Torque M6 screw into oil filter housing
to 11.3 N·m (100 in. lb.) into a new hole, or 7.7 N·m
(69 in. lb.) into a used hole. Torque M5 screws to
6.5 N·m (58 in. lb.) into new holes, or 4.1 N·m
(37 in. lb.) into used holes.
2. Connect Oil Sentry indicator light wires.
™
3. Install knobs onto control levers.
86
All manuals and user guides at all-guides.com
Install Muffler
1. Install new exhaust gaskets onto exhaust studs.
2. Install port liners (if equipped). Attach muffler and
3. Install any attaching hardware and brackets. Torque
4. Install spark arrestor (if used).
Install Oil Filter and Add Oil to Crankcase
NOTE: Make sure both oil drain plugs are installed and
1. Install oil drain plugs. Torque plugs to 21.4 N·m
2. Place new filter in shallow pan with open end up. Fill
3. Apply a thin film of clean oil to rubber gasket on new
4. Refer to instructions on oil filter for proper
5. Fill crankcase with new oil. Level should be at top of
6. Reinstall oil fill cap/plug and dipstick and tighten
Connect Spark Plug Leads
Connect leads to spark plugs.
Prepare Engine for Operation
A
Engine is now completely reassembled. Before starting
or operating engine, follow proceeding steps.
1. Make sure all hardware is tightened securely.
2. Make sure oil drain plugs, Oil Sentry
3. Adjust carburetor, idle fuel needles, or idle speed
Testing Engine
It is recommended engine be operated on a test stand or
bench prior to installation in equipment.
1. Set engine up on a test stand. Install an oil pressure
2. Adjust governed idle and high speed (RPM) to
KohlerEngines.com
secure with nuts onto exhaust studs. Torque nuts to
24.4 N·m (216 in. lb.).
M6 screws to 9.9 N·m (88 in. lb.), and M8 screws to
24.4 N·m (216 in. lb.).
torqued to 21.4 N·m (16 ft. lb.) to prevent oil
leakage.
(16 ft. lb.).
with new oil until oil reaches bottom of threads. Allow
2 minutes for oil to be absorbed by filter material.
filter.
installation.
indicator on dipstick.
securely.
switch, and a new oil filter are installed.
adjusting screw as necessary.
gauge. Start engine and check to be certain oil
pressure (20 psi or more) is present. Run engine at
idle for 2-3 minutes, then 5-6 minutes more between
idle and midrange. Adjust carburetor mixture settings
as necessary (as available).
required settings. Make sure maximum engine
speed does not exceed 3900 RPM (no load).
pressure
™
62 690 01 Rev. J
