Page 1: 10" X 10" Embedded Compact Board
QBi-N97B (MADN9BH) 10” x 10” Embedded Compact Board www.gigaipc.com... -
Page 2: Copyright Notice
The material in this document is for product information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity QBi-N97B (MADN9BH) SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. 13. Watch out for high temperatures when the system is running. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
BATTERY (Battery connector) .......... 25 2.2.5 DC_IN2 (DC IN Connector) ..........26 2.2.6 SODIMM1 (DDR4 SO-DIMM Slot) ........27 2.2.7 SATA (SATA 6Gb/s connector) .......... 28 2.2.8 SATA_PWR (SATA power connector) ....... 29 2.2.9 M2M (M.2 Slot, 2280 M-Key) .......... 30 www.gigaipc.com... - Page 12 3.3.3 SATA Configuration ............50 3.3.4 Super IO Configuration ............ 51 3.3.5 Hardware Monitor ............52 3.3.6 S5 RTC Wake Settings ............53 3.3.7 Network Stack Configuration-1........54 3.3.7 Network Stack Configuration-2 ........55 3.3.8 NVMe Configuration ............56 www.gigaipc.com...
- Page 13 5E:64) (MAC address may varied based on different motherboard)..............59 3.3.12 Realtek PCIe GBE Family Controller (MAC:74:56:3C:BC: 5E:65) (MAC address may varied based on different motherboard)..............60 Chipset ................61 Security ................62 Boot .................. 65 Save & Exit ............... 66 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications:qbi-N97B (Madn9Bh)
Chapter 1 Chapter 1 - Product Specifications QBi-N97B (MADN9BH) www.gigaipc.com... - Page 15 113.8 1.6 Thickness 130.2 105.8 www.gigaipc.com...
-
Page 16: Specifications
1 x Speaker out header 2 x USB 2.0 headers 2 x USB 3.2 Gen 2x1 1 x Power button with LED Front IO 1 x COM Port (RS-232) 1 x Combo audio jack (Headphone & Headset) 1 x HDMI www.gigaipc.com... - Page 17 Non-operating humidity: 0%-95% (non-condensing) Carton size: 465 x 351 x 217 (mm) Packing Capacity: 10pcs Packaging Single Box size: 221 x 178 x 65 (mm) Content Including: SATA power cable 150mm x 1 (P/N: 25CRI-150621-K1R) Order 9MADN9BHMR-SI (Box Packing) Information www.gigaipc.com...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 20 Code Description Power Button header PWR_BT M.2 Slot, 2230 E-key F_USB2_1 USB 2.0 header F_USB2_2 BATTERY Battery connector DC_IN2 DC IN connector SODIMM1 DDR4 SO-DIMM Slot SATA 6Gb/s connector SATA SATA_PWR SATA power connector www.gigaipc.com...
- Page 21 Combo Audio Jack (Headphone & Headset) USB31_2 USB 3.2 Gen 2x1 port x 2 PWR_BUT Power button DC_IN1 Screw type DC Jack USB31_1 USB 3.2 Gen 2x1 port x 2 HDMI12_21 HDMI connector x 2 LAN1 LAN Connector x 2 LAN2 www.gigaipc.com...
-
Page 22: Pwr_Bt (Power Button Header)
2.2.1 PWR_BT (Power Button header) Pin 1 Power Button header Connector PN Vendor 50238-01041-001 ACES Connector type 2x5pin header, pitch 1.0mm Pin No. Definition PWRBTSW 5Vdual MPD- www.gigaipc.com... -
Page 23: M2E (M.2 Slot, 2230 E-Key)
PCIE Clock Dn Pin No. Definition Pin No. Definition SUSCLK 3.3V PCIE Clock PLTRST_BT 3.3V Request PCIE Wakeup BT_Disable WLAN_Disable 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor PCIE TX7p APCI0095-P002A LOTES PCIE TX7n 80152-8521 BELLWETHER www.gigaipc.com... -
Page 24: F_Usb2_1, F_Usb2_2 (Usb 2.0 Header)
2.2.3 F_USB2_1, F_USB2_2 (USB 2.0 header) Pin 1 USB 2.0 header Connector PN Vendor A1250WV-S- JOINT-TECH 04PNLBT1T00L 50273-0047N-001 ACES Connector type 1x4pin header, pitch 1.25mm F_USB2.0 Pin No. Definition www.gigaipc.com... -
Page 25: Battery (Battery Connector)
2.2.4 BATTERY (Battery connector) Pin 1 Battery Connector Pin No. Definition Connector type 1x2pin header, pitch 1.25mm www.gigaipc.com... -
Page 26: Dc_In2 (Dc In Connector)
2.2.5 DC_IN2 (DC IN Connector) Pin 1 ATX_IN Connector Connector PN Vendor 99-01740-B004-A TCONN Connector type 1x2pin header, pitch 3.0mm Pin No. Definition DC IN www.gigaipc.com... -
Page 27: Sodimm1 (Ddr4 So-Dimm Slot)
2.2.6 SODIMM1 (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 28: Sata (Sata 6Gb/S Connector)
2.2.7 SATA (SATA 6Gb/s connector) Pin 1 SATA 6 Gb/s connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 29: Sata_Pwr (Sata Power Connector)
2.2.8 SATA_PWR (SATA power connector) Pin 1 SATA power connector Connector PN Vendor 85205-0570N ACES Connector type 1x5pin header, pitch 1.25mm Pin No. Definition 3.3V www.gigaipc.com... -
Page 30: M2M (M.2 Slot, 2280 M-Key)
PCIE Clock Request PCIE Clock Dn PCIE Wake up M2 LED PCIE Clock Dp 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUS_CLK 3.3V M2 Detect 3.3V 3.3V 3.3V Connector PN Vendor 80159-8521 BELLWETHER 2E0BC21-S85BM-7H FOXCONN APCI0096-P002A LOTES www.gigaipc.com... -
Page 31: Spk_Out (Speaker Out Connector)
2.2.10 SPK_OUT (speaker out connector) Pin 1 Audio Amplifier Connector Connector PN Vendor A2001WV-04P146 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 32: Me (Me Enable Jumper)
2.2.11 ME (ME Enable jumper) Pin 1 ME Enable Connector Connector PN Vendor 220-96-02GBK1 PINREX Connector type 1x2pin header, pitch 2.0mm ME Disable jumper Enable (Default setting) Disable www.gigaipc.com... -
Page 33: Cpu Fan (Cpu Fan Connector)
2.2.12 CPU FAN (CPU Fan connector) Pin 1 CPU FAN connector Connector PN Vendor 85205-0570N ACES Connector type 1x5pin header, pitch 1.25mm Pin No. Definition CPUFANIN FAN1_PWM www.gigaipc.com... -
Page 34: Hdmi2_3 (Hdmi Connector)
2.2.13 HDMI2_3 (HDMI connector) HDMI 3 HDMI Connector Connector PN Vendor 1165-2CG04-24P TCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p DDC Clock TX1n DDC Data TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com... -
Page 35: Com1 (Serial Port Connector, Rs-232)
2.2.14 COM1 (Serial port connector, RS-232) Serial port Connector Connector PN Vendor SM41D1P1122N33NQ FENYING Pin No. Definition www.gigaipc.com... -
Page 36: Hp (Combo Audio Jack (Headphone & Headset))
2.2.15 HP (Combo Audio Jack (Headphone & Headset)) www.gigaipc.com... -
Page 37: Usb31_2 (Usb 3.2 Gen 2X1 Connector)
2.2.16 USB31_2 (USB 3.2 Gen 2x1 connector) USB 3.2 Gen 2x1 connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 38: Pwr_But (Power Button)
2.2.17 PWR_BUT (power button) www.gigaipc.com... -
Page 39: Dc_In1 (Screw Type Dc Jack Connector)
2.2.18 DC_IN1 (Screw type DC Jack connector) Screw Type DC Jack Connector Connector PN Vendor 655-360-000 SHEN-MING www.gigaipc.com... -
Page 40: Usb31_1 (Usb 3.2 Gen 2X1 Connector)
2.2.19 USB31_1 (USB 3.2 Gen 2x1 connector) USB 3.2 Gen 2x1 connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com... -
Page 41: Hdmi12_21 (Hdmi Connector)
2.2.20 HDMI12_21 (HDMI connector) HDMI 1 HDMI 2 HDMI Connector Connector PN Vendor QJ11191-DFB1-4F FOXCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p DDC Clock TX1n DDC Data TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com... -
Page 42: Lan1, Lan2 (Lan Connector)
LAN Connector State Description Orange On 2.5Gbps data rate Green On 1Gbps data rate 100M&10Mbps data rate Link / Connection/ Activity LED Speed LED Pin No. Definition Connector PN Vendor TX1+ RT7-GB-0003 TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- www.gigaipc.com... -
Page 43: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 44: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 45: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 46: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 47: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or Selection having TPM chip on MB)(Default setting) www.gigaipc.com... - Page 48 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 49: Cpu Configuration
Turbo Mode Disabled : Disables Turbo Mode Command CPU to enter into low power consumption mode when CPU is under idle mode. C states Enabled : Enables CPU C states function (Default setting) Disabled : Disables CPU C states function www.gigaipc.com... -
Page 50: Sata Configuration
3.3.3 SATA Configuration Item Description Serial ATA Port shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 51: Super Io Configuration
Press [Enter] to configure advanced items : Enable or Disable Serial Port Serial Port 1 Enabled : Enables Serial Port function (Default setting) Configuration Disabled : Disables Serial Port function Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com... -
Page 52: Hardware Monitor
CPU Fan Speed Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Temperature Shows current system temperature Fan Speed Shows current fan Speed www.gigaipc.com... -
Page 53: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 54: Network Stack Configuration-1
IPv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support (Default setting) When Network stack is enabled : IPv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support (Default setting) www.gigaipc.com... -
Page 55: Network Stack Configuration-2
IPv4 HTTP Support Disabled : Disables Ipv4 HTTP Support Enabled : Enables Ipv4 HTTP Support (Default setting) When Network stack is enabled : IPv6 HTTP Support Disabled : Disables Ipv6 HTTP Support Enabled : Enables Ipv6 HTTP Support (Default setting) www.gigaipc.com... -
Page 56: Nvme Configuration
3.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 57: Offboard Sata Controller Configuration
3.3.9 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 58: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : Enroll Cert 1. Enroll Cert Using File 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 59: Realtek Pcie Gbe Family Controller (Mac:74:56:3C:bc:5E:64) (Mac Address May Varied Based On Different Motherboard)
3.3.11 Realtek PCIe GBE Family Controller (MAC:74:56:3C:BC:5E:64) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 60: Realtek Pcie Gbe Family Controller (Mac:74:56:3C:bc:5E:65) (Mac Address May Varied Based On Different Motherboard)
3.3.12 Realtek PCIe GBE Family Controller (MAC:74:56:3C:BC:5E:65) (MAC address may varied based on different motherboard) Shows Realtek Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 61: Chipset
Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 62: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 63 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 64 Copy NVRAM content of Secure OsRecovery Secure Boot Boot variables to files in a root Signatures variables folder on a file system device (dbr) Enabled : Enables MS UEFI MS UEFI CA CA Key (Default setting) Disabled : Disables MS UEFI CA Key www.gigaipc.com...
-
Page 65: Boot
Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Enabled : Enables Built-in EFI Shell Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option Priorities Choose/set the boot priority www.gigaipc.com... -
Page 66: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
