7. TECHNICAL SPECIFICATIONS

7.1. SYMBOLS USED

Alternating current (AC)
Direct current (DC)
Device with protection class II according to
DIN EN 61140
Hertz
Short-term operation
Milliamperes
Milliamperes per hour
Amp
Volt
Disposal according to the EU Directive on Waste
Electrical and Electronic Equipment (WEEE)
Displays the manufacturer of the medical device
Displays the serial number as defined by the manufac-
turer to identify a specific device.
Medical-device
Unique-device-identification for medical products
Protection class of the application part: type BF
Temperature limit: Refers to the temperature limits to
which the medical device can be safely exposed.
Humidity limit
Atmospheric pressure limit
Refer to the instructions
Use inside only
General warning symbols
Intensität in 5 Stufen
UP
DOWN
Stand-by / ON / 100 Hz / 75 Hz / 50 Hz / OFF
Bluetooth
Battery full
Battery low
charging Battery
overheating protection active
7.2. TECHNICAL SPECIFICATIONS
· Operating conditions: 5 °C (41 °F) to 30 °C (86 °F); 15 % to
93 % relative humidity, non-condensing; 700 hPa to 1060
hPa air pressure
42
· Storage / transport: -5 °C (23 °F) to 40 °C (104 °F); 15 % to
93 % relative humidity, non-condensing; 500 hPa to 1060
hPa air pressure
· Operating mode: Short-term operation 20/15 min
· Operating noise: maximum 70 dBA
Operating temperature: maximum 50 °C (122 °F)
for maximum service life.
· Power plug Model 1180004-1P:
· Input power: AC 100–240 V, 50–60Hz, 300 mA
· Output power: DC 5 V, 2 A
· IP65 Protection class stating: Protected against dust in
harmful quantities. Protection against water jets (nozzle)
from any angle.
· LOT: Shows the date of manufacture of the power supply
· A type F (EU plug) power plug is included in the standard
scope of delivery. Additional mains adapters with different
power plugs are optionally available or already included in
the corresponding country sets.
· USB-A charging cable to spring contact pin, cable length:
approx. 1 m
· Battery: Built-in lithium-ion battery type 21700 with pro-
tection board, life span: 800 charging cycles. One charge
of a new battery guarantees at least 6, 20-minute treat-
ment sessions at medium intensity. Note that frequent use
at the highest intensity level can decrease battery life.
· Battery performance: Capacity 5000 mAh, voltage 3,6 V,
18 Wh
· Devices comply with IEC 60601-1-2:2014/AMD1:2020
and / or CISPR 11 Emission Class B and Group 1. Devices
have been tested for home use in accordance with inter-
ference immunity testing levels.
· Product category: Class IIa medical device pursuant to
the EU Regulation on Medical Devices (2017/745/EU),
conformity with 2015/863/EU is also declared.
· Bluetooth (BLE): frequency 2,4–2,483 GHz, Modulation
DSSS,modulation type GFSK 1000kbps, effective radiated
power <0.15 mW at 25 mm, Contains FCC ID: 2AC7Z-ESP-
MINI and IC: 21098-ESP32MINI1
· This device complies with part 15 of the FCC Rules.
