Compaq Evo N600c Maintenance And Service Manual page 4

Contents
3 Illustrated Parts Catalog
3.1 Serial Number Location . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Notebook System Major Components . . . . . . . . . . . 3-2
3.3 Miscellaneous Plastics Kit Components . . . . . . . . 3-16
3.4 Mass Storage Devices . . . . . . . . . . . . . . . . . . . . . . 3-18
3.5 Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
4 Removal and Replacement Preliminaries
4.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Service Considerations. . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 Preventing Damage to Removable Drives . . . . . . . . 4-3
4.4 Preventing Electrostatic Damage . . . . . . . . . . . . . . . 4-4
4.5 Packaging and Transporting Precautions . . . . . . . . . 4-4
4.6 Workstation Precautions . . . . . . . . . . . . . . . . . . . . . 4-5
4.7 Grounding Equipment and Methods . . . . . . . . . . . . 4-6
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . 5-2
5.3 Preparing the Notebook for Disassembly . . . . . . . . 5-4
5.4 Notebook Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
5.5 Mini PCI Communications Board . . . . . . . . . . . . . 5-12
5.6 Disk Cell RTC Battery . . . . . . . . . . . . . . . . . . . . . . 5-15
5.7 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5.8 Memory Expansion . . . . . . . . . . . . . . . . . . . . . . . . 5-22
5.9 TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
iv
Plastic Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Cables and Connectors. . . . . . . . . . . . . . . . . . . . . . . 4-2
Maintenance and Service Guide
