Delta A: Assignment of the two pairs of control surfaces to Aileron-A and Elevator-A
Delta B: Assignment of the two pairs of control surfaces to Aileron-B and Elevator-B
V-tail A: Assignment of the two pairs of control surfaces to Elevator-A and Rudder-A
V-tail B: Assignment of the two pairs of control surfaces to Elevator-B and Rudder-B
Delta – thrust vector models: Delta A should be assigned as described above, while
Elevator-B can be used for thrust vector.
Differential travels present no problems; the 3D algorithm detects their presence,
and ensures that the control commands are separated correctly.
Note: If your model is fitted with four separate ailerons, it is sufficient to assign
iGyro control to the outboard ailerons only.
If your model is fitted with two ailerons actuated mechanically by four or six servos,
then they should not be controlled with individual gyro channels. In this case you
should also set up two gyro channels, and adjust the servos at the PowerBox using
the Servo Matching function.
