Note: If your model is too large to move, you should not fix the iGyro SAT in
place at this stage; instead move the iGyro SAT alone in the following way:
The installed orientation of the iGyro SAT is detected by defined movements of the
model. The first step is to press three times on one of the two buttons to the right
of the Installed position point. The triple press ensures that you do not actuate the
process accidentally. Wait a moment until you see the message Tail up at Status.
Now move the tail of the model up and down smoothly two or three times, before
holding it still in the up position. The elevator outputs carry out the same move-
ments – but there is no need to check correct direction of servo rotation at this
point.
Once the iGyro has detected the movement, the elevator outputs quickly return to
neutral, and the transmitter screen will show the message Tail to the right.
If the elevators slowly return to the neutral position, this indicates that you did not
move the model a sufficient distance. If this should happen, repeat the procedure.
The next step is to move the tail of the model smoothly to left and right two or three
times, then hold the tail to the right. Just as described previously, the rudder will
also move in a random direction in parallel with the movement. Once the move-
ment has been detected, the rudder returns to the neutral position, and the screen
shows the message Finished.
Note: the process of establishing the installed orientation resets all gyro
settings. For this reason you should only carry out this procedure with new
models, or if you have to re-position the iGyro SAT in the model.
