- Page 1 ADVANCED SAFETY VISION SYSTEMS AVK51 5" HEAVY DUTY AHD MONITOR 1080P CAMERA KIT USER MANUAL USER MANUAL USER MANUAL DUAL 12 24V COMPATIBLE CAMERA INPUTS 07-08-2024...
-
Page 2: Product Overview
ADVANCED SAFETY VISION SYSTEMS Product overview Bracket installation 1. Fix the U-bracket into position. Insert and lock the monitor into the bracket using the mounting screw knobs. 2. Adjust to your desired angle. -
Page 3: Menu Structure
ADVANCED SAFETY VISION SYSTEMS - Volume / Menu down function Menu - Volume / Menu up function Input select PowerVolume Menu structure Press the Menu button to scroll through the main menu structure. Each press of the menu button will advance the user though the 4 menus as listed below. Press the AV button to toggle through sub menus. - Page 4 ADVANCED SAFETY VISION SYSTEMS Menu descriptions 1.Monitor: • Brightness - Adjusts the brightness of the screen. Be careful not to adjust this setting to high as this will reduce the contrast (blacks will eventually become greys reducing the contrast to whites).
-
Page 5: Camera Installation
Note: When purchasing Additional cameras, the resolutions must be matching 720P 720P 1080P 1080P 720P 1080P Note: Additional cameras and wiring may be required depending on your application, compatible products are available on our website. For more information Scan the QR code below. Product AERPRO.COM information and user manual. - Page 6 ADVANCED SAFETY VISION SYSTEMS How to find reversing wires to trigger or power camera systems. We recommend that you wire up the triggers as the last part of your installation (after the systems monitor has been wired) this is so that you can use the system as a safe way to test for a reversing wire.
- Page 7 ADVANCED SAFETY VISION SYSTEMS carefully strip both wires sheaths back to expose the wires core making sure you keep them separate and away from the cars chassis to avoid any shorts). You should also make sure the globe it self is not resting on something that could be harmed by extreme heat as the globe when on can get very hot).
-
Page 8: Specifications
ADVANCED SAFETY VISION SYSTEMS Specifications • Display: 5" LCD Display • Resolution: ° Monitor: 800x480 ° Camera: 1080P • Lens Angle: 110 Degrees • Wired or Wireless: Wired • Compatibility: Suits Standard Definition and AHD (720p and 1080p) • DVR Recording: No •... -
Page 9: Technical Assistance
ADVANCED SAFETY VISION SYSTEMS Technical assistance If you need assistance setting up or using your Aerpro product now or in the future, call Aerpro Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST or EMAIL: service@tdj.com.au If you would like to download a digital copy of this manual, or other Aerpro manuals/software, please visit the Aerpro.com website and search for the product...
