VP4 OWNER'S MANUAL

Specifications

INPUTS
Connectors: (2) 1/4" phone jack, unbalanced
Impedance: 1 MΩ (less, w. "Input Impedance" settings applied.)
Max. Input Level: +20dBu
A/D CONVERSION
Bit Depth: 24 bits
Sample Rate: 48 kHz
Dynamic Range: 114 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
ANALOG OUTPUTS
Connectors: (2) 1/4" phone jack unbalanced
Impedance: 600Ω
Max Output Level: +16dBu
D/A CONVERSION
Dynamic Range: 114 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
DIGITAL I/O
Connectors: RCA Coaxial Type for S/PDIF in and out
Format: Uncompressed PCM
Sample Rate: 48 kHz fixed
USB AUDIO
Format: USB 2.0 Class compliant, USB Type "C" connector
Channels: 4 (2 in, 2 out, each mapped to specific ports internally)
USB Audio Clock: 48 kHz fixed
MIDI INTERFACE
Input Connector: (1) TRS 3.5 mm Female - Type A
Output Connector: (1) TRS 3.5 mm Female - Type A
Thru: No dedicated connector, but incoming MIDI can be
merged to the output by enabling
Setup > MIDI/Remote > MIDI Thru to "ENABLED"
PEDAL INTERFACE
Connectors: (2) 1/4" TRS phone jack
Format: Pedal: 10–100 kΩ max
Switch: momentary or latching
SPECIFICATIONS
GENERAL
Finish:
Controls:
Display:
Dimensions:
Weight:
Power Requirement:
Power Connector:
Internal Battery:
ENVIRONMENTAL
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -22 to 167 °F (-30 to 70 °C)
Humidity:
Powder coated steel chassis.
6 buttons, 5 knobs, 4 footswitches.
480 × 272 high contrast color LCD.
10.0" W. × 2.6" H. × 6.31" D.
(254.0mm W. × 66.0mm H. × 160.3mm D.)
3 lbs 7 oz (1.56 kg)
9V DC 1.3A
2.1mm barrel connector, negative center
NONE
Max. 90% non-condensing
