SETUP > Pedals
PARAMETER
Pedal 1 Type
Pedal 2 Type
Calibrate PEDAL 1
Calibrate PEDAL 2
Description
Set this according to whether you have connected a pedal or a certain type of footswitch:
EXPRESSION PEDAL - Choose this option when connecting an expression pedal such as the Fractal Audio EV-1 or EV-2. 3rd party
expression pedals should have a linear resistance taper and must have a maximum resistance in the range of 10–100kΩ. Expression
pedals must be used with Tip-Ring-Sleeve (TRS) cables.
Each pedal jack can also support one switch. The use of dual switches is not supported.
SWITCH (Any, Follow Hardware) Use this setting when you connect a latching switch, or when you connect a momentary switch and
want momentary action.
SWITCH (Momentary, Virtual Toggle) Use this setting to cause a connected momentary switch to behave like a latching/toggle
switch.
These options allow you to calibrate expression pedals connected to an onboard Pedal jack.
 Select the appropriate option and press ENTER.
 Move the pedal through its full range of motion several times. The meter will show the actual response of your pedal, which
does NOT need to fully reach the top or the bottom but should show motion across the majority of the range.
 Press ENTER again when finished.
 The mini-graph on the main Pedals page now shows the output of your calibrated pedal.
If it does not range from 0-100, calibrate again or check your cable, pedal, etc.
Remember: Switches, unlike pedals, do not need to be calibrated but should still display 0-100 on the mini-graph.
