- Page 1 Quick Start Guide GFK-3297A Aug 2024 PACSystems™ 4G/Wi-Fi Kit QUICK START GUIDE...
-
Page 2: Table Of Contents
Contents Initial Checks ..............1 Front Panel Description ........... 2 Power-Input ..............3 Getting Started ..............4 Configuring PLC for Wireless Connectivity ...... 7 PACSystems™ 4G WiFi Kit Quick Start Guide GFK-3297A... -
Page 3: Initial Checks
As the consignee, it is your responsibility to register a claim with the carrier for damage incurred during shipment. Emerson will fully cooperate with you, however, should such action be necessary. After unpacking the equipment, record all serial numbers. Serial numbers are required if you should need to contact Customer Care during the warranty period. -
Page 4: Front Panel Description
Front Panel Description Figure 1: Antenna and Connector Views Connector Description Wi-Fi Wi-Fi antenna connector Mobile Two mobile antenna connectors Reset Recessed reset button Power Power input connector (Use supplied adapter cable) For SIM card use. To open, press the ejector button through the opening next to SIM card LAN Ethernet port Wide Area Network port. -
Page 5: Power-Input
Power-Input To power the system, a voltage of 9 V-30 V DC must be supplied to the power connector via a power adapter cable via screw terminals: pin 1 – VCC, pin 2 - GND. The IPC2010 power supply must meet the Safety Extra-Low Voltage/Limited Power Source (SELV/LPS) requirements or be Appropriately Rated for the Ambient and Altitude of the Application (ES1/PS2). -
Page 6: Getting Started
Getting Started Follow the steps below to start using the Teltonika RUT241 4G/Wi-Fi module. Once configured, the Teltonika RUT241 can be used as a 4G/Wifi gateway for any of your PACSystems controllers or Industrial PCs via either integrated Ethernet or optional Ethernet communications modules, such as the IC695ETM001. - Page 7 4. Attach two Mobile and one Wi-Fi antenna to the module. Figure 4: Connector Interface 5. Power up the RUT241 using the included power cable adapter. The allowed power voltage range is 9 V – 30 V 6. Connect an Ethernet cable between the RUT241 LAN port and one of the unused Ethernet ports on your computer.
- Page 8 9. Log in using the password as printed on the back of the device (Figure 3) 10. Follow the on-screen instructions to change your password. 11. A configuration wizard will appear. To set up the RUT241 as a Wi-Fi Access Point and LAN bridge to the internet using a cellular network, follow the default settings recommended by the configuration wizard.
-
Page 9: Configuring Plc For Wireless Connectivity
Configuring PLC for Wireless Connectivity This 4G/Wi-Fi module can also be used to enable Wi-Fi connectivity to the PLC. To do so, the PLC needs to be configured on the same IP subnet as the modem, which by default has IP: 192.168.1.1. To configure the PLC, please use PACs Machine Edition tool and configure LAN port used for modem connectivity to be on the same IP subnet as the modem, example: 192.168.1.100. - Page 10 Contact Information and Support Questions? We are here to help. Register for a Search our Open a Support Customer Knowledge Base Ticket Account pacsystems.co/ pacsystems.co/ pacsystems.co/support knowledge signup Customer Center Commercial Contact Home Page Website Information pacsystems.co/ pacsystems.co/ pacsystems.co/ customercenter commercial contactus...
