Capacitive (capacitor banks, electronic equipment, motor start capacitors)
Inductive (LED light drivers, transformers, fans, refrigerators, air-conditioners))

User interface

Inputs
One (Control) button
Press and hold for 5 seconds to enable Device access point and Bluetooth
connection.
Press and hold for 10 seconds to factory reset the Device.
Outputs
LED (monocolor) indication
AP (Access Point) enabled and Wi-Fi disabled:
1 second ON / 1 second OFF
Wi-Fi enabled, but not connected to a Wi-Fi network:
1 second ON / 3 seconds OFF
Connected to a Wi-Fi network:
Constantly ON
Cloud is enabled, but not connected:
1 second ON /5 seconds OFF
Connected to Shelly Cloud:
Constantly ON
OTA (Over the Air Update):
½ sec ON / ½ second OFF
Button pressed and held for 5 seconds:
½ second ON / ½ second OFF
Button presses and held for 10 seconds:
¼ second ON / ¼ second OFF
