O P E R A T I N G
M A N U A L
Compass
Refrigerant Leak Detector

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compass and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inficon Compass

  • Page 1 O P E R A T I N G M A N U A L Compass ™ Refrigerant Leak Detector...
  • Page 2: Declaration Of Conformity

    Equipment Description ....Compass Refrigerant Leak Detector Applicable Directives ....73/23/EEC as amended by 93/68/EEC...
  • Page 3 Power Cell Access Door To get the best performance from your Compass Leak Detector, please read this manual carefully before you start using the instrument. If you have any questions or need additional assistance, please call 1-800-344-3304. We'll be happy to help you.
  • Page 4 5. The nickel/metal hydride power stick is not yet charged. To charge it, connect the cord of the AC power adapter to the power jack and plug the adapter into the appropriate outlet. Allow 10 hours for a full charge. The Compass does NOT have a fast charge feature. NOTE: You should expect 5 hours of operation from a fully charged power stick.
  • Page 5: Finding Leaks

    3. When the instrument detects a leak, its yellow LEDs will illuminate and it will begin to beep rapidly. 4. When the Compass signals a leak, pull the probe away from the leak for a moment, then bring it back to pinpoint the location.
  • Page 6: Recharging The Power Stick

    Compass is operating, although more slowly than if the instrument is off. A 12 V(dc) power cord is also included, designed to charge and power the Compass from your vehicle's cigarette lighter.
  • Page 7: Changing The Sensor

    Compass. Additionally, ensure the two halves are connected correctly, as the connector is polarized and damage may result to either the battery or the Compass if attached incorrectly.
  • Page 8: Troubleshooting

    Troubleshooting NOTE: The internal parts of the Compass Leak Detector are not serviceable. Do not attempt to disassemble the instrument, except for replacing the filters, sensor or power stick. Opening the plastic housing for any reason will void the warranty.
  • Page 9: Replacement Parts And Accessories

    If you require additional assistance, please call 1-800-344-3304. Replacement Parts and Accessories Replacement parts and accessories for your Compass are available through the same dealer from whom you bought the instrument. Replacement Power Stick..........712-700-G1 Replacement Sensor .
  • Page 10: Warranty And Liability-Limitation

    INFICON warrants your Compass Refrigerant Leak Detector to be free from defects of materials or workmanship for two years from the date of purchase. INFICON does not warrant items that deteriorate under normal use, including power stick, sensor and filters. In addition, INFICON does not warrant any instrument that has been subjected to misuse, negligence, or accident, or has been repaired or altered by anyone other than INFICON.
  • Page 11 NOTES...
  • Page 12 TWO TECHNOLOGY PLACE EAST SYRACUSE, NY 13057-9714 USA Phone: +315.434.1100 Fax: +315.437.3803 E-Mail: service.tools@inficon.com www.inficon.com 074-458-P1E...
