IP Address. You can even run diagnostic tests from the LCD menu.
provides complete details for using the menu.
Control buttons are located directly under the LCD display area. Press the SELECT> button to
enter the LCD Menu then use the
SELECT> button chooses the menu item and the <BACK button navigates backward to the
previous menu.

V-Portal Bottom

The V-Portal's sleek design will inspire you to proudly display it in your home. The bottom of the
V-Portal has four protective nubs that allow you to place it on a flat surface, such as a desk or
shelf, without fear of scratching your furniture. If you would prefer, the V-Portal can be mounted
on a wall using the two wall-mount slots included on the bottom of the V-Portal. Simply follow the
wall mounting instructions below.

Wall Mounting the V-Portal

The bottom of the V-Portal includes two wall-mount slots. The distance between the two slots is
3.25 inches (82 mm). You'll need two #4 or #6 screws with two anchors sized appropriately to the
screws to mount your V-Portal to a sheetrock wall.
Here's how to mount the V-Portal on your wall:
1. Determine where you want to mount the V-Portal.
Mark the position of the V-Portal's wall-mount slots on your wall. The middle of the slots
are 3.25 inches (82 mm) apart.
2. Drill two holes into the wall at the marked wall-mount slot positions and insert an anchor
in each hole.
3. Insert a #4 or #6 screw into each anchor in your wall. Leave 0.25 inches (6.35 mm) of
each screw head exposed.
4. Maneuver the V-Portal so the wall-mount slots on the V-Portal line up with the two screws
in your wall.
5. Place the wall-mount slots over the screws and slide the V-Portal down until the screws
fit snugly into the wall-mount slots.
That's all there is to it!
View the Terms of Service by visiting the Vonage website at www.vonage.com/tos. Pay particular attention to
Section 11 which explains limitations on Warranty, Remedy and Liability.
Vonage V-Portal User Guide
and buttons to navigate through the menu items. The
Vonage V-Portal LCD Menu
