DG
II Series
OPERATING MANUAL
1
Introduction .......................................... 2
2
Preparation ........................................... 3
3
Introduction .......................................... 4
4
Precautions for use .............................. 6
5
6
Check before installation ................. 10
7
Installing the product ....................... 11
Thank you for purchasing an Oriental Motor product.
This Manual describes product handling procedures and safety precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
Hollow Rotary Gearhead
8
9
10
11
..... 7
12
13
Installing a load .................................. 13
Connection .......................................... 15
Maintenance ....................................... 18
Regulations and standards .............. 19
Specifications...................................... 20
Accessories .......................................... 21
HL-80024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGII Series and is the answer not in the manual?

Questions and answers

Related Manuals for Oriental motor DGII Series

Summary of Contents for Oriental motor DGII Series

  • Page 1: Table Of Contents

    Check before installation ....10 Accessories .......... 21 Installing the product ....... 11 Thank you for purchasing an Oriental Motor product. This Manual describes product handling procedures and safety precautions. • Please read it thoroughly to ensure safe operation. • Always keep the manual where it is readily available.

  • Page 2: Introduction

    The product described in this manual is designed and manufactured to be incorporated in general industrial equipment. Do not use for any other purpose. Oriental Motor Co., Ltd. is not responsible for any compensation for damage caused through failure to observe this warning.

  • Page 3: Preparation

    This chapter explains the items you should check, as well as the name of each part. Checking the product Verify that the items listed below are included. Report any missing or damaged items to the Oriental Motor sales office from which you purchased the product.

  • Page 4: Safety Precautions

    Safety precautions Safety precautions The precautions described below are intended to ensure the safe and correct use of the product, and to prevent the customer and others from exposure to the risk of injury. Use the product only after carefully reading and fully understanding these instructions.
  • Page 5 Safety precautions • Do not use the product in explosive or corrosive environments, in the presence of flammable gases, in places subjected to splashing water, or near combustibles. Doing so may result in fire, electric shock, or injury. • Do not transport, install, connect or inspect the product while the power is supplied. Doing so may result in electric shock.

  • Page 6: Precautions For Use

    Precautions for use Precautions for use This chapter covers restrictions and requirements the user should consider when using the product. „ General z Do not make an impact on the product. Do not drop the product. Also, do not hit the motor or gear-reduction mechanism on something hard. Doing so may cause the positioning accuracy decrease, the product damage or the product service life reduction.

  • Page 7: Mounting Or Dismounting The Motor

    Mounting or dismounting the motor Mounting or dismounting the motor • When changing the motor cable outlet direction, remove the load. Doing so in a condition where a load is installed may result in injury or damage to equipment. • Set the home again after mounting a motor. If the product is operated without setting the home, the moving part may move to unexpected directions or run at unexpected speeds, leading to injury or mechanical damage.
  • Page 8 Mounting or dismounting the motor • Do not touch the coupling with bare hands. This may cause rust. • Do not use the ball-end hex key. • Do not change the direction of the motor while it is fixed in the coupling. •...
  • Page 9 Mounting or dismounting the motor Dismounting the motor 1. Remove the cap and loosen the coupling fixing screw by three turns. Three turns or less Coupling xing screw DGN130:M4 DGN200:M5 Do not remove (4 places) • To prevent the coupling fixing screw from falling off, keep three turns or less when turning the screw.

  • Page 10: Check Before Installation

    Check before installation Check before installation Location for installation The gearhead is designed and manufactured to be incorporated in general industrial equipment. Install it in a well ventilated location that provides easy access for inspection. The location must also satisfy the following conditions: •...

  • Page 11: Installing The Product

    Installing the product Installing the product Specifications for mounting holes and positioning pin holes The mounting holes are through holes. Provide screw hole machining in the mounting plate. Values of the tightening torque are recommended. Tighten the screws with a suitable torque according to the design conditions of the mounting plate.

  • Page 12: Installation Method

    Installing the product Installation method z Design for mounting plate [reference] [unit: mm (in.)] DGN130 120 (4.72) ø5 ( ) × deep 5 +0.012 110 (4.33) [ø0.1969 ( +0.0005 ) × deep 0.20] 72 (2.83) Details of section A (2:1) 4×M8 DGN200 170 (6.69)

  • Page 13: Installing A Load

    Installing a load Installing a load Specifications about installation Install a load with screws using the load-mounting screw holes (six places) onto the output table. Use the load-mounting pin holes (two places) of the output table when positioning a load. Values of the tightening torque are recommended.
  • Page 14 Installing a load Permissible moment, permissible axial load Use the product so as not to exceed the permissible moment and the permissible axial load shown in the table. Permissible Model Output table supporting bearing Permissible axial load (N) moment (N·m) Cross-roller bearing 2,000 DGN130...

  • Page 15: Connection

    Connection Connection Connecting a home sensor Installation method of our home-sensor set. „ Home-sensor set description The following parts are used for the home-sensor set. Home-sensor set model Sensor output Photomicrosensor model PADG-SB EE-SX673A (OMRON Corporation) EE-SX673R (OMRON Corporation) PADG-SBY •...
  • Page 16 Connection 2. Secure the mounting bracket with the sensor attached as shown in the illustration using the included hexagonal socket head screws (M2.5×2). Tightening torque: 0.5 N·m (71 oz-in) Hexagonal socket head screws (M2.5) Do not use the screw holes (M2.5) for the home sensor of the gearhead for any other purpose. 3.

  • Page 17: Maintenance

    Inspection This chapter explains the maintenance items in order to operate the product safely and efficiently. If an abnormal condition is noted on the product, discontinue any use and contact your nearest Oriental Motor sales office. „ Inspection interval If the product is operated eight hours a day, perform maintenance according to the applicable period specified in the table.

  • Page 18: Regulations And Standards

    Regulations and standards 11 Regulations and standards z EU RoHS Directive / UK RoHS Regulation This product does not contain the substances exceeding the restriction values.

  • Page 19: Specifications

    Specifications 12 Specifications 12-1 General specifications „ Environmental conditions Ambient temperature 0 to +40 °C (+32 to +104 °F) (Non-freezing) Operating Ambient humidity 85 % or less (Non-condensing) environment Altitude Up to 1,000 m (3,300 ft.) above sea level Degree of protection IP40...

  • Page 20: Accessories

    Accessories 13 Accessories „ Home-sensor set Home-sensor set model Sensor output PADG-SB PADG-SBY...
  • Page 22 If a new copy is required to replace an original manual that has been damaged or lost, please contact your nearest Oriental Motor sales office. • Oriental Motor shall not be liable whatsoever for any problems relating to industrial property rights arising from use of any information, circuit, equipment or device provided or referenced in this manual.

This manual is also suitable for:

Dgn130Dgn200
