Part No. 906800, 906800DHL
Model CF325XPRO24
Cordless XPro
30° Framing Nailer
CLEANING PROCEDURE
www.paslode.com
Literature Part Number: 906868-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CF325XPRO24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Paslode CF325XPRO24

  • Page 1 Part No. 906800, 906800DHL Model CF325XPRO24 Cordless XPro 30° Framing Nailer CLEANING PROCEDURE www.paslode.com Literature Part Number: 906868-1...
  • Page 2 This procedure provides a simple but effec- may result in the tool being made inoperable. tive way to clean your Paslode Cordless Although "safety" cleaners generally provide Framing Nailer and maintain reliable opera- reduced risk of fire and are more stable than tion.
  • Page 3 Remove the cap by unscrewing the four #10-24 Socket Head Cap Screws. WARNING Never operate the Paslode Cordless Fram- ing nailer unless all four Socket Head Cap Screws are firmly tightened on the cylin- der head. Failure to do this could result in tool damage, fire and personal injury.
  • Page 4 DANGER Never operate the Paslode Cordless tool unless all four Socket Head Cap Screws are firmly tightened on the cylinder head. Failure to do this could result in...
  • Page 5: Cylinder Head

    Cylinder Head Step 1 Spray the Cylinder Head (make sure not to miss the spark plug and surrounding area) with cleaner/degreaser. Allow the dirt and debris to drip off. DO NOT LET OVER-SPRAY OR DIRTY CLEANER/DEGREASER RUN INTO THE HANDLE. Step 2 Using a clean, lint-free rag, wipe off any remaining cleaner or dirt.
  • Page 6 (facing away from each other). Note: Paslode Cordless Lubricating Oil is spe- cially formulated for use in the Paslode Cordless Framing Nailer. The use of other types of lubricants may cause rapid build-up of combustion residue or result in premature part failure.
  • Page 7 Step 5 Spray a liberal amount of Cordless Tool Cleaner into the inside of Sleeve and Com- bustion Chamber. Invert Motor Assembly, and let excess cleaner and dirt drain out. Step 6 Using a clean area of a lint-free rag, wipe off any remaining cleaner or dirt.
  • Page 8: Motor Assembly

    Motor Assembly Step 7 With open end of the Motor Assembly facing up, squeeze 4-5 drops of oil onto the inside of the Sleeve wall (Area “A”) and 5-6 drops onto lower lip of Combustion Chamber (Area "B"). Rotate Motor Assem- bly while oiling to ensure oil is evenly distributed around Sleeve and combustion chamber lip.
  • Page 9 Step 10 Tilt the Motor Assembly upright, and apply 3-4 drops of Paslode Cordless Lubri- cating Oil evenly spaced around the top of the Combustion Chamber (Area "C"). Spread the oil using your fingertip.
  • Page 10 After the tool is completely reassembled the cap assembly is securely attached to and all screws are tightened, test the tool the housing. Operating the Paslode for proper operation. Some smoke may be Cordless tool with a loose or missing cap...
  • Page 11: Operating Conditions

    30000 Paslode has developed this chart as a guideline to assist you in establishing the 20000 proper cleaning schedule for the type of use the tool is getting.
  • Page 12 30° Cordless Framing Nailer Cleaning Procedure Part No. 906800; 906800DHL Model CF325XPRO24 For Technical Support call: 1-800-222-6990 Go to: paslode.com to find Parts and Service Centers An Illinois Tool Works Company 155 Harlem Avenue Glenview, IL 60025 www.paslode.com ©2024, Illinois Tool Works Inc.
