Paslode CT200S24 Operating Manual

Paslode CT200S24 Operating Manual

Cordless 18ga straight brad finish nailer
Hide thumbs Also See for CT200S24:
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT!
DO NOT DESTROY
It is the customer's responsibility to have
all operators and service personnel read
and understand this manual.
Printed in U.S.A.
©2024 Illinois Tool Works Inc.
918230-1
06/24
Model CT200S24
CORDLESS 18GA STRAIGHT
BRAD FINISH NAILER
OPERATING MANUAL
Part No. 918200
www.paslode.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT200S24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paslode CT200S24

Summary of Contents for Paslode CT200S24

  • Page 1 Part No. 918200 Model CT200S24 CORDLESS 18GA STRAIGHT IMPORTANT! BRAD FINISH NAILER DO NOT DESTROY It is the customer’s responsibility to have all operators and service personnel read and understand this manual. OPERATING MANUAL Printed in U.S.A. www.paslode.com ©2024 Illinois Tool Works Inc.

  • Page 2: Table Of Contents

    Preparing the Paslode Cordless 18GA Straight Brad Finish Nailer for Use ......

  • Page 3: Introduction And Warranty

    United States, refer to the Service Center listing that was provided the original user. with your tool. Paslode’s sole liability hereunder will be to replace any part or accessory ONE-YEAR LIMITED WARRANTY which proves to be defective within the specific time period. Any...

  • Page 4: An Overview Of The Paslode Cordless 18Ga Straight Brad Finish Nailer

    The Handle Assembly contains the fuel cell, By using the Paslode Cordless Brad Nailer at its battery, indicator light, and trigger. recommended cycle rate, you will be able to drive several thousand nails in a typical workday.
  • Page 5 Overview of the Paslode Cordless 18GA Straight Brad Finish Nailer QUICK RELEASE- NOSE PLATE ASSEMBLY SOFT RUBBER TRIGGER SOFT GRIP HANDLE EASY-OPEN MAGAZINE NO MAR PROBE TOOL REST FIXTURE FLASHING GREEN = CHARGED FLASHING = NEEDS CHARGING DEPTH OF DRIVE ADJUSTMENT...

  • Page 6: Safety Instructions

    The following safety instructions have been includ- ed in this booklet to provide you with basic informa- UNTIL YOU HAVE READ AND UNDERSTAND tion necessary for safe operation of the Paslode ALL SAFETY PRECAUTIONS AND MANUAL Cordless 18GA Straight Brad Finish Nailer.
  • Page 7 Safety Instructions DANGER WARNING The Cordless Finish Do not expose the tool 120º 49º Nailer is an internal to temperatures in combustion device. It excess of 120ºF (49º C). produces hot exhaust Fuel and/or the battery gases that may ignite may burst, releasing flammable materials.
  • Page 8 SAVE THESE INSTRUCTIONS! Battery Disposal: DANGER The Paslode batteries contain lithium and should be recycled or disposed of properly. It is illegal in some TO REDUCE THE RISK OF FIRE OR areas to place a lithium battery into the trash or solid waste stream.

  • Page 9: Battery And Charging System

    This charging system is the on a stable surface. A green light will come on to only one that will work with the Paslode indicate the power is on and the charger circuit is lithium-ion batteries. The first step in preparing a ready.
  • Page 10 Battery and Charging System Battery Indicator Light On the right side of the handle is a small plastic lens. This is the battery indicator light. When you insert a fully-charged battery into the tool, you will see a blinking green light. If the indicator light blinks red, Standby recharge the battery.

  • Page 11: Fuel Cell

    filter for optimum tool operation. NOTE: Altitude Restriction WARNING Paslode Cordless technology is powered by an internal combustion engine, which is a ected by Sunlight can raise the inside temperature of an altitude. The tool may lose power or become unventilated car or van to above 140ºF (60ºC).
  • Page 12 Fuel Cell Note: Paslode Fuel Cells are marked with a “Best Used Before” date on the bottom of the can. For maximum performance use fuel before the “Best Used Before” date. DANGER Paslode Cordless Fuel Cells are flammable. Do not remove fuel cartridge cap or install on...
  • Page 13 Fuel Cell CORRECT FUEL CELL LOADING PROCEDURE To open - Push forward, lift Open fuel door assembly Open fuel door fully then back Raise fuel tube block assembly, Load fuel cell Carefully align fuel adaptor and it will lock in up position cell stem To close - Push forward, then Note: Fuel cell Dosing Lever must...

  • Page 14: Preparing The Paslode Cordless 18Ga Straight Brad Finish Nailer For Use

    The Paslode Cordless 18GA Straight Brad Finish Nailer drives Paslode 18 gauge straight brads designed to be used with the tool. The use of fasteners that do not meet Paslode standards could Do NOT use Use only cause tool damage and will void all warranty claims.

  • Page 15: Paslode Cordless 18Ga Straight Brad Finish Nailer Operation

    The Cordless Nailer should not be used in the rain or where excessive moisture is present. The use of the Paslode Cordless Technology under these conditions may result in damage to the tool components and cause the tool to malfunction.

  • Page 16: Fasterners And Applications

    The Paslode Cordless 18GA Straight Brad Finish Nailer drive Paslode 18GA Straight Brads. Fasteners are collated into strips of 50 for easy loading. Paslode fasteners are designed to be used in Paslode tools. Use of other fasteners may cause damage to the tool or injury to the tool operator.

  • Page 17: Servicing

    Periodically check the battery indicator light in the service procedures in this manual, contact Paslode. handle of the Cordless Nailer. When encountering a problem, the first step should always be to make sure DANGER the battery has enough charge to operate the tool.
  • Page 18 End-of-Workday Routine Paslode Cordless Tool Accessories These simple steps are based on maintaining the A variety of accessories are available for the Paslode safety and operational e ciency of the Cordless Nailer. Cordless 18GA Straight Brad Finish Nailer: Before you leave the work site: No-Mar Replacement Tip Single Tip - Part No.

  • Page 19: Tool Schematic

    Tool Schematic Parts Legend CT200S24 CORDLESS 18GA STRAIGHT BRAD FINISH NAILER 918200 901064 Shoulder Screw 901097 Shoulder Screw, 8-32 SHCS P30 904601 Grille 918919 Paslode Logo 900648 Filter 901066 Plastite Screw 904557 Cap Screw 918903 Battery Foam Pad 902446 918215...
  • Page 20 Tool Schematic CT200S24 CORDLESS 18GA STRAIGHT BRAD FINISH NAILER 918200...

  • Page 21: Troubleshooting

    Spark plug is dirty. Clean tool cylinder head. Return tool to authorized Paslode dealer No spark is generated. for service. If tool will not operate after following the above service directions, return the tool to an authorized Paslode representative for service.
  • Page 22 Still not working? Here are more options: • Your nailer may qualify for our Cordless 2 Year Service Promise. Visit paslode.com for more information, or call us at 1-800-222-6990. • Keep you Cordless Nailer in top form. Visit paslode.com and watch our Cleaning and Maintenance videos...
