Cordless 18 ga straight brad finish nailer
Hide thumbs Also See for 918200:

Advertisement

Quick Links

Part No. 918200
Model CT200S24
Cordless 18 Ga
Straight Brad Finish Nailer
CLEANING PROCEDURE
www.paslode.com
Literature Part Number: 918234

Advertisement

loading
Need help?

Need help?

Do you have a question about the 918200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paslode 918200

  • Page 1 Part No. 918200 Model CT200S24 Cordless 18 Ga Straight Brad Finish Nailer CLEANING PROCEDURE www.paslode.com Literature Part Number: 918234...
  • Page 2 This procedure provides a simple but To begin, you will need the effective way to clean your Paslode following items: Cordless tool and maintain reliable 1. Flat Head Screwdriver operation. Regular cleaning and 2. Hex Key Wrench (provided with tool) lubrication will also extend part life and 3.
  • Page 3 Step 3 Remove filter by hand and clean with mild soap or replace if necessary. Set the grill, filter, and cap aside.
  • Page 4 DANGER Never operate the Paslode Cordless tool unless all six Socket Head Cap Screws are firmly tightened on the cylinder head. Failure to do this could result in tool damage, fire and personal injury.
  • Page 5 Step 7 Spray the Cylinder Head with Cordless Tool Cleaner. Allow the dirt and debris to drip off. Step 8 Using a clean, lint free rag, wipe off any remaining cleaner or dirt. Make sure the Seal Rings and Spark Plug are completely clean and clear of debris.
  • Page 6 Seal Rings. Set the Cylinder Head Assembly aside. Note: Paslode Lubricating Oil is specially formulated for use in the Paslode Cordless Tool. The use of other types of lubricants may cause rapid build-up of combustion residue or result in premature part failure.
  • Page 7 Step 11 Spray a liberal amount of tool cleaner into the inside of the Sleeve and Combustion Chamber. Invert the Motor Assembly, and let excess cleaner and dirt drain out. Step 12 Using a clean area of a lint-free rag, wipe off any remaining cleaner or dirt.
  • Page 8 Step 13 With Motor Assembly tilted up, squeeze 4-5 drops of Paslode Lubricating Oil into Sleeve (Area “A”) and 3-4 drops onto lower lip of Combustion Chamber (Area “B”) and apply 4-5 drops around the top of the Combustion Chamber (area C). Rotate...
  • Page 9 Step 15 Manually push the Driver Blade up and down to distribute the oil in the Sleeve evenly. Reassemble the Paslode Cordless tool following disassembly Steps 1-4, pages 2-3 in Reverse order. Reassembly Note: Before tightening Cap Screws, depress the nose of the tool down on its work contact- ing element to close Combustion Chamber.
  • Page 10 After the tool is completely reassembled the cap assembly is securely attached to and all screws are tightened, test the tool the housing. Operating the Paslode for proper operation. Some smoke may be Cordless tool with a loose or missing cap...
  • Page 11 If it is appar- ent that the Paslode Cordless Tool is not When the Paslode Cordless Nailer is used in need of cleaning at the scheduled time,...
  • Page 12: Cleaning Procedure

    Paslode Cordless 18 Ga Straight Brad Finish Nailer CLEANING PROCEDURE Part No. 918200 Model CT200S24 For Technical Support call: 1-800-222-6990 Go to: paslode.com to find Parts and Service Centers An Illinois Tool Works Company 155 Harlem Avenue Glenview, IL 60025 www.paslode.com...
