IMPORTANT!
DO NOT DESTROY
It is the customer's responsibility to have
all operators and service personnel read
and understand this manual.
Printed in U.S.A.
©2024 Illinois Tool Works Inc.
906867-1
08/24
Part No. 906800; 906800DHL
Model CF325XPRO24
CORDLESS XPRO 30°
FRAMING NAILER
OPERATING MANUAL
www.paslode.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF325XPRO24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paslode CF325XPRO24

  • Page 1 Part No. 906800; 906800DHL Model CF325XPRO24 CORDLESS XPRO 30° IMPORTANT! FRAMING NAILER DO NOT DESTROY It is the customer’s responsibility to have all operators and service personnel read and understand this manual. OPERATING MANUAL Printed in U.S.A. www.paslode.com ©2024 Illinois Tool Works Inc.
  • Page 2: Table Of Contents

    The battery charger system meets all safety requirements for power tools. is a registered trademark of Illinois Tool Works Inc. © 2024 An Illinois Tool Works Company 155 Harlem Avenue Glenview, IL 60025 www.paslode.com Power Nailers are designed and assembled in the U.S.A. Paslode® is a member of: Li-ion...
  • Page 3: Introduction And Warranty

    United States, refer to the Service Center listing that was provided the original user. with your tool. Paslode’s sole liability hereunder will be to replace any part or accessory ONE-YEAR LIMITED WARRANTY which proves to be defective within the specific time period. Any...
  • Page 4: An Overview Of The Paslode Cordless Framing Nailer

    Framing Nailer Specifications Description Dimensions: The Paslode Cordless Framing Nailer is a self-con- tained, fully portable nailer that uses liquid hydro- Weight (with battery) 7.9 pounds (3.6 Kg) carbon fuel to power a unique linear drive internal Length 12 inches (305mm) combustion motor.
  • Page 5: Depth Of Drive Adjustment

    Overview of the Paslode Cordless Framing Nailer TOOL REST FIXTURE QUICK RELEASE- NOSE PLATE ASSEMBLY BYPASS FOLLOWER SOFT GRIP HANDLE EASY-LOAD MAGAZINE DEPTH OF DRIVE ADJUSTMENT LED PANEL SHOWING BATTERY STATUS AND WORK CONTACTING ELEMENT FIRING MODE WITH AGGRESIVE TIP FOR...
  • Page 6: Safety Instructions

    DO NOT ATTEMPT TO OPERATE THIS TOOL ed in this booklet to provide you with basic informa- UNTIL YOU HAVE READ AND UNDERSTAND tion necessary for safe operation of the Paslode ALL SAFETY PRECAUTIONS AND MANUAL Cordless XPro 30º Framing Nailer.
  • Page 7 Safety Instructions DANGER WARNING The Cordless Framing Do not expose the tool 120º 49º Nailer is an internal to temperatures in combustion device. It excess of 120ºF (49º C). produces hot exhaust Fuel and/or the battery gases that may ignite may burst, releasing flammable materials.
  • Page 8 SAVE THESE INSTRUCTIONS! Battery Disposal: DANGER The Paslode batteries contain lithium and should be recycled or disposed of properly. It is illegal in some TO REDUCE THE RISK OF FIRE OR areas to place a lithium battery into the trash or solid waste stream.
  • Page 9: Battery And Charging System

    Battery and Charging System Battery and Charging System Charging Instructions The Paslode Cordless tool comes with a recharge- 1. Remove the charger unit from the tool case and able Lithium Ion (Li-ion) battery and its own charging plug it into a 120V AC outlet. Set the charger base system.
  • Page 10: Sequential Mode Operation

    Battery and Charging System Inserting Battery Battery Indicator LEDs 1. Load the battery, contacts first, into the Cordless When using the Cordless XPro Framing Nailer, the Framing Nailer. LED lights on the handle of your tool will provide you with important operational information. 2.
  • Page 11: Explosion / Fire Hazard

    Keep out of the reach of children. DANGER Store fuel cell(s) in well-ventilated areas only. 1. Do not attempt to remove or reuse the Paslode Framing Fuel Cell. 2. Do not attempt to install the fuel cell cap on other fuel cells. This may result in damage to...
  • Page 12 Fuel Cell Note: Paslode Fuel Cells are marked with a “Best Used Before” date on the bottom of the can. For maximum performance use fuel before the “Best Used Before” date. DANGER Paslode Cordless Fuel Cells are flammable. Do not remove fuel cartridge cap or install on...
  • Page 13 Fuel Cell CORRECT FUEL CELL LOADING PROCEDURE To open - Push forward, lift Raise fuel tube block assembly, Load fuel cell then back it will lock in up position Carefully align fuel adaptor and To close - Push forward, then down to lock fuel door cell stem...
  • Page 14: Preparing The Paslode Cordless Framing Nailer For Use

    The Paslode Cordless Nailer drives Paslode RounDrive® and D/Head nails, which have been collated into strips. The use of nails that do not meet Paslode standards could cause tool damage and void your warranty. Paslode nail sizes and types are illustrated in the Fasteners and Applications section.
  • Page 15: Paslode Cordless Framing Nailer Operation

    Paslode Cordless Framing Nailer Operation Cold Weather Operation (Continued) DANGER It will be necessary to repeat this procedure several The work contacting element and nose will times until the temperature of the tool warms up become hot after prolonged or rapid use. If it enough to operate in its normal mode.
  • Page 16: Fasterners And Applications

    Recommended for use in natural wood siding, such as cedar, redwood, cypress and preservative treated lumber. (Not for use in all-weather wood foundations.) The Paslode Cordless Framing Nailer is not recommended for use with 3" (75mm) and longer Ring Shank nails in pressure treated lumber.
  • Page 17: Servicing

    Hardened Steel - For attaching wooden plates to green concrete foundations; 2X furring strips to cinder block. CHECKING THE CHARGE LEVEL OF THE The Paslode Cordless Framing Nailer is not recommended for use with 3" (75m Wear safety glasses when performing this test. BATTERY...
  • Page 18 Tool Cleaning and Oiling Periodic cleaning and oiling are necessary to keep the Paslode Cordless Nailer operating properly. The tool Cleaning the Air Filter should be cleaned and lubricated at least every Open the grille by pressing slightly above the adapter, 50,000 cycles.
  • Page 19: Tool Schematic

    Tool Schematic Parts Legend CF325XPRO24 CORDLESS XPRO 30º FRAMING NAILER 906800; 906800DHL 901063 Shoulder Screw 906858 Retaining Ring Mod 906305 Grille 900593 Screw, SEMS SHCS 10-24 x 5/8 900315 Filter 906606 XPRO Nail Claw 906805 XPRO Cap 502020 Compression Spring .240 x .813...
  • Page 20 Tool Schematic...
  • Page 21: Troubleshooting

    Troubleshooting Troubleshooting LED Diagnostic Codes The LED above the low battery icon will flash if the tool is having any of the below errors. Error Code Diagnostics Table Number of Flashes Error Fan Short Magnet Short Fan Open / Stall Magnet Open Bumpfire LED Bumpfire Switch...
  • Page 22 Tool operates, but no fastener is driven. Wrong fasteners being used. Use only fasteners meeting Paslode ® specifications. Check Fasteners and Applications section for fastener types and sizes recommended for use in Cordless tool.
  • Page 23 Follow Paslode Cordless Framing Nailer no nail comes out of the tool Cleaning Instructions. If tool will not operate after following the above service directions, return the tool to an authorized Paslode ® representative for service. Still not working? Here are more options: •...
