Lumens CamConnect AI-Box1 User Manual

Hide thumbs Also See for CamConnect AI-Box1:
Table of Contents

Advertisement

Quick Links

Download this manual
CamConnect AI-Box1
User Manual - English
To download the latest Quick Start Guide,
multilingual user manual, firmware, drivers,
and control modules, please visit
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CamConnect AI-Box1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens CamConnect AI-Box1

Summary of Contents for Lumens CamConnect AI-Box1

  • Page 1 CamConnect AI-Box1 User Manual - English To download the latest Quick Start Guide, multilingual user manual, firmware, drivers, and control modules, please visit https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 System Connection ..............2 1.1 System Connection ..........................2 1.2 AI-Box1 IO Interface ........................... 2 Chapter 2 Operation Interface ............... 3 2.1 Device Setting............................3 2.2 Camera Control & Status ........................4 2.3 Device & Camera Mapping ....................... 6 2.4 System Settings ............................

  • Page 3: Chapter 1 System Connection

    Chapter 1 System Connection 1.1 System Connection 1.2 AI-Box1 IO Interface...

  • Page 4: Chapter 2 Operation Interface

    Chapter 2 Operation Interface 2.1 (A)Device Setting Item Function Descriptions Device Number Select the desired number of microphones to connect Device List Displays microphones in individual tabs Select Microphone Device Devices Please use a supported microphone (see Lumens website)

  • Page 5: Camera Control & Status

    Device IP Enter the IP address of the microphone Displays the microphone’s port  Shure: 2202 Shure: 2202  Sennheiser: 45  Sennheiser TCCM: 443 Port  Nureva: 8931  Yamaha: 49280  Audio-Technica : 17300 Only Nureva allows customized PORT Enable/Disable setting mode Connect When enabled, signals received by a microphone triggers camera preset...

  • Page 6: Ptz Control

    Please ensure that the camera and AI-Box1 are on the same network segment. Device Name Displays discovered cameras Connect Click to connect. Connected camera are highlighted in blue. Click to enable PTZ control PTZ Control Refer to 2.2.1 PTZ Control for function description Delete Delete a camera from the list.

  • Page 7: Device & Camera Mapping

    2.3 (D)Device & Camera Mapping When a microphone is connected, the camera will move to a preset position corresponding to the sound position detected by the microphone. Item Function Descriptions Select the number of locations to be mapped. Up-to 128 presets supported.

  • Page 8: System Settings

    Firmware Auto Check Automatically checks for firmware updates. Resets the CamConnect Pro AI-Box1. Reset Measure the reading from the SD card to check if it is working properly. Disk Check The reading data can be provided to Lumens personnel for further inspection.

  • Page 9: Video Output Settings

    Turns on/off error message and notifications. Error Notification Confirm and apply settings. Apply Network Choose either DHCP or Static. The address can be modified in Static mode. Click Apply to save. (F)Video Output Settings Item Function Descriptions...
  • Page 10 Set the Output Mode to either UVC, HDMI or UVC+HDMI Video Output Mode Configure the layout of the video output according to the provided reference in section 2.5.1 Video Output Layout  Cross: 4-split screen Video Output Layout  PBP: Picture by Picture screen ...

  • Page 11: Start Video Output

    (G)Start Video Output Click to output camera images via HDMI, UVC or HDMI+UVC. Extension Item Function Descriptions Scenario Application In a conference meeting, the microphone might pick up sound from the other side, accidentally triggering the camera and causing it to move to an unwanted preset position.

  • Page 12: Virtual Keyboard

    The camera may be triggered by any sound, whether it is caused by a human or just incidental noise. With the Lumens BC200 auxiliary camera, the system will no longer be triggered by sound alone. It will also use AI face recognition to detect people on site.
  • Page 13 Function Descriptions This window displays the software version information of AI-Box1. Click on to confirm the latest version and do apply updates. For technical support, please scan the QRcode on the right.

  • Page 14: Chapter 3 Web Interface

    Chapter 3 Web Interface 3.1 Device Settings Item Function Descriptions  Array Microphone Number：Select the desired number of microphones to connect  Devices: Select a Microphone  Device IP: Enter the IP address of the microphone  Displays the microphone’s port Shure: 2202 ...
  • Page 15  Audio Trigger Level > dB： Triggered when an audio source exceeds the specified dB value. Sennheiser:-90~0 (recommended -55)  Nureva:0~120 (recommended 40+)  Audio-Technica:0~60 (recommended 30)  Yamaha:0~126 (recommended 80+ for RM-CG / 70 up for RM-W)   Time To Trigger Preset: Audio Reception Delay Settings When a second sound trigger occurs, there will be a delay in triggering camera preset based on the configured duration in seconds.

  • Page 16: Device - Camera List

    3.2 Device - Camera List 項目 功能說明 Resolution/ FPS： Must match the camera's resolution settings  Refresh : search the cameras in this network segment.  Add：Manually type the IP address, then click AI-Box1 Please ensure that cameras and are in the same network segment。...
  • Page 17 Cruise Mode Not available for now. Customize Create and fully customize your own 2 unique scripts. Edit Edit the contents of the script Run / Stop Start or stop the script running. Execution Log Display the log activity of AI Director. Example of script creation Script Edition: Conversation Mode Example Camera: Assign commands for connected cameras to move to a preset position or return to their home...
  • Page 18 Control 1. Script Start: a.This block must be placed at the beginning of any valid script. b.Set the priority to determine which script takes precedence when multiple scripts are active. 2. Script End: This block must be placed at the end of any valid script 3.
  • Page 19 Mode 2: Assign two preset positions for each camera. Each camera move to their preset positions in order. Configurable value: 1. Movement speed (degrees per second) for the camera when the preset position is triggered. 2. Delay time(seconds) 2. Camera settings a.
  • Page 20 Leave: Exit the page Save: Save the settings Run: Start executing the script Bin: Drag unwanted blocks to the bin icon to discard them. Execution Log: Display the activity log of AI Director.

  • Page 21: Video Output Settings

    3.4 Video Output Settings Item Function Descriptions Video Output Mode HDMI,UVC or HDMI+UVC The system is set up for single screen output, and the camera switching is Seamless Switching triggered by the microphone signal. Configure the layout of the video output according to the provided reference in section 2.5.1 Video Output Layout ...

  • Page 22: System- Network

    3.5 System- Network Function Descriptions Ethernet Settings. When it is set to Static IP, settings can be modified. Once the settings are complete, click Apply. 3.6 System- Profile Item Function Descriptions Save as New Profile Save the current settings as a new profile / layout template. Load Profile Load a saved profile / layout template.

  • Page 23: System- Settings-Device

    3.6.1 System- Settings-Device Item Function Descriptions Language English Device Name CamConnect_Processor Location Default_XXXX (The last four characters of the MAC address) Max Microphone Qty. 4 / 8 / 16 / 24 3.6.2 System- Settings- Auto Connection Item Function Descriptions The microphone, camera and Video output can reconnect automatically Auto Connection after restarting the AI Box.

  • Page 24: Extension Setup

    The camera may be triggered by any sound, whether it is caused by a human or just incidental noise. With the Lumens BC200 auxiliary camera, the system will no longer be triggered by sound alone. It will also use AI face recognition to detect people on site.

  • Page 25: System Settings: Web User

    Connection: Converge the audio signals from CamConnect Pro and the speaker (B), so they can be sent to a computer (A). Please refer to the connection method below to create the cable and make the connection. Audio Trigger(dB): Set the audio detection threshold (-100~0 dB). The microphone will only trigger detection when the volume exceeds the set threshold.

  • Page 26: About

    Item Function Descriptions Firmware Version Displays the current firmware version of the device. Auto Check Automatically checks if new firmware is available. Firmware Update Allows you to select and update a firmware file from your computer. Event Log The log file records activity over time and can be exported. Reboot Restarts the device.

  • Page 27: Chapter 4 Connect To Video Conferencing Software

    Chapter 4 Connect to video conferencing software Set the output mode of AI-Box1 to UVC or HDMI+UVC, then click the Video output button Launch software (such as Skype, Zoom or Microsoft Teams) Select CamConnect as the video source  Video Source Name: Lumens CamConnect Processor...

  • Page 28: Chatper 5 Microphone Settings

    Chatper 5 Microphone Settings Please check the latest list of supported microphones on the Lumens website. Below are examples. Compatibility is not limited to these microphones. Before installing AI-Box1, third-party microphone systems may require configuration. Sennheiser When using TCC2 with CamConnect, set and configure the channels on the Sennheiser Control Cockpit software first.

  • Page 29: Chapter 6 Troubleshooting

    Unable to search camera devices 2. Make sure the cameras are on the same network as the CamConnect AI-Box1. 3. Replace the cables and make sure they are not faulty The microphone fails to detect the Please confirm that the microphone device is in Connected status position of a sound 1.

  • Page 30: Chapter7 System Message

    Chapter7 System Message Warning message Action Ensure that the microphone's port has been typed correctly and check if the IP address is on the same network as the AI-Box. Microphone cannot be found. Please check Microphone You can also refer to the link below from for more information about the connection status and try to setup method with compatible ceiling microphones.

  • Page 31: Copyright Information

    Lumens is a trademark registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not permitted unless a license has been provided by Lumens Digital Optics Inc. or unless copying this file is for the purpose of backup after purchasing this product.
