- Page 1 USER MANUAL UNI DISPOSABLE Disposable single gas detector we watch gas where you can't...
-
Page 2: Table Of Contents
CONTENTS READ BEFORE OPERATING DESCRIPTION WARNING PROPER PRODUCT DISPOSAL AT END OF LIFE 1. PRODUCT OVERVIEW 2. NORMAL MODE OPERATION 2.1 Turning the unit on 2.2 Warm-up sequence 2.3 Remaining time display 3. ALARMS 3.1 Daily alarm test (Flashing?) 3.2 Normal alarm function 3.3 Calibration fail alarm (for service use only) 3.4 Bump fail alarm (for service use only) 3.5 Bump due alarm (for service use only) -
Page 3: Read Before Operating
The detector has a large LCD providing maximum readability in the field. The display shows the reamining operating time. Six bright red LEDs allow for quick alarm notifica- tion. Constructed of strong and durable material, the UNI Disposable is designed to be comfortable, yet drop-resistant. -
Page 4: Proper Product Disposal At End Of Life
UNI DISPOSABLE Disposable single gas detector PROPER PRODUCT DISPOSAL AT THE END OF LIFE The Waste Electrical and Electronic Equipment (WEEE) direc- tive (2002/96/EC) is intended to promote recycling of electronic equipment and their components at end of life . This symbol (crossed-out wheeled bin) indicates separate collection of was- te electrical and electronic equipment in the EU countries. -
Page 5: Product Overview
1. PRODUCT OVERVIEW DETECTOR COMPONENTS 1. LED alarm window 2. Remaining operating time display 3. Left Key (Confirm/Number increasing) 4. Right Key (Power On-Off/ Cursor moving) 5. Alligator clip 6. Sensor Gas Inlet 7. Vibrator DISPLAY SYMBOLS Gas name, includes: CO and H2S Remaining time unit: Months, Days, Hours Question mark: Daily alarm test... -
Page 6: Normal Mode Operation
UNI DISPOSABLE Disposable single gas detector 2. NORMAL MODE OPERATION 2.1 TURNING THE UNIT ON NOTE: Once the unit is turned on it cannot be turned off and the battery life countdown timer begins. Press and hold the Right Key (... -
Page 7: Bump Fail Alarm (For Service Use Only)
In general, use the Left Key to increase the number or confirm, use the Right Key to move the cursor or move to the next programming item. Detailed configuration settings can be performed using the WatchGas Suite software through the UNI Mono / Multi Docking Station or (see UNI docking station manual). -
Page 8: Set High And Low Alarm Levels
Sheets of 5 “peel-and-stick” internal filters are available for this purpose: 1. Turn off the WatchGas UNI Disposable and place it face down on a soft surface. 2. Use a T10 Torx screwdriver to loosen (counterclockwise) each of the four screws. - Page 9 CAUTION • Change battery only in area known to be non-hazardous. • Use only WatchGas battery, PN: 1.17.02.0002 or PN ER14505 cell manufactured by EVE Energy Co., LTD. ATTENTION • Changez la batterie uniquement dans une zone connue pour être non dangereuse.
-
Page 10: Specifications
Battery & Life specifications Warranty 3 years for the UNI Disposable of 36-Months **WatchGas Suite is the PC software used to show and set more configuration parameters of UNI Disposable instrument through the UNI Mono or Multi Docking station. 10 10... -
Page 11: Sensor Specifications
(ppm) (ppm) (ppm) (ppm) Ring 0-500 0-100 CAUTION Use only WatchGas sensors 8. ALARM SIGNAL SUMMARY LCD Display Reason/Alarm Signals Low alarm: Buzzer 2 beeps per second LED 2 flashes per second 1 vibration per second “LOW” 2 flashes per second... -
Page 12: Troubleshooting
UNI DISPOSABLE Disposable single gas detector Daily Alarm Check needed or Bump Due alarm: 2 flashes per second Bump Fail alarm: Buzzer 1 beep per minute LED 1 flash per minute 1 vibration per minute “Bump” and “Remain Time” alternate display per... -
Page 13: Limited Warranty
For permission requests, contact WatchGas B.V.
