- Page 1 452（英） APV series intelligent photovoltaic combiner (DC1500V) Installation and Operation Instruction V1.0 ACREL CO.,LTD...
- Page 2 No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form by nay means,electronic, mechanical photocopying, recording,or otherwise without prior permission of Acrel. All rights reserved. This company reserve power of revision of product specification described in this manual,...
-
Page 3: Table Of Contents
CONTENTS 1 Safety signs, instructions..........................1 1.1In order to use the product better, please read the following symbols carefully........1 1.2Please read this manual carefully before installation and use..............1 2 General................................3 3 Product Naming............................... 3 4 Characteristics..............................4 5 Technical Parameters............................4 6 Basic structure..............................5 6.1Outline dimension.......................... -
Page 4: Safety Signs, Instructions
Note: This manual is a comprehensive introduction to the APV series intelligent photovoltaic combiner box. Users should read it carefully before using it, and fully understand the functions of the device for correct and standardized operation. 1 Safety signs, instructions 1.1 In order to use the product better, please read the following symbols carefully... - Page 5 Warning： Installation and use should comply with the relevant national or local standards； Warning： The fuse is subjected to high voltage from the inverter and photovoltaic array, and it is strictly forbidden to touch the fuse during operation. Before checking and replacing the fuse, the DC circuit breaker must be disconnected, but note that all terminals of the DC fuse will still have high voltage at this time, and the fuse core of the same level as the original model...
-
Page 6: General
The main function of the APV series intelligent photovoltaic combiner box (DC1500V) is to perform first-level confluence on the input of the DC1500V voltage level photovoltaic cell array, which is used to reduce the connection between the photovoltaic cell array and the inverter, optimize the system structure, and improve reliability and reliability. -
Page 7: Characteristics
4 Characteristics Meet the technical requirements of "GBT34936-2017" photovoltaic power station combiner box； The protection level is IP65, which meets indoor and outdoor installation requirements； Using Hall sensor, isolated measurement, maximum 24 inputs； Adopt photovoltaic special fuse, withstand voltage DC 1.5KV, fuse current can be selected； ... -
Page 8: Basic Structure
Temperature Working temperature: -25~+60℃, humidity ≤95%, no /Humidity condensation, no corrosive gas place Altitude ≤2000m Insulation resistance ≥100MΩ Auxiliary power DC1500V(±10%) Enclosure protection IP65 level Weight About 60kg (24 channel with anti-reverse) Volume (W×H×D) 950*750*200mm（24 channel） 6 Basic structure 6.1 Outline dimension The size of the 24 channel box of this product is 950mm×750mm×200mm(width×height×depth), and the specific installation size is 1000×495mm. -
Page 9: Perforation Type Pv Combiner Box
6.2 Perforation type PV combiner box The combiner box adopts the perforated installation collector collecting device, and the typical structure is shown in Figure 3. Figure 2 Internal physical map (perforated external radiator with anti-reverse function) (Typical case, please refer to the actual product for details) Number Part Name Note... -
Page 10: Wiring Schematic
7 Wiring Schematic 24 in 1 out intelligent photovoltaic combiner box circuit schematic 8 Installation and use 8.1 Unpacking and inspection Check for transportation damage: Although we have monitored the product before it leaves the factory, it may be damaged during transportation, so please check it before installation. If any damage is detected, please contact the transportation company or directly contact Ankerui Electric Co., Ltd. -
Page 11: Installation Tool
whether there are damaged parts, and whether the wiring is loose; 2. One key; 3. One certificate of conformity; 4. One product manual; 5. Factory inspection record one copy; 8.2 Installation tools Installation tools include: Phillips screwdriver, torque wrench, Allen wrench, diagonal pliers, electric drill, wrench, wire stripper, etc. -
Page 12: Incoming And Outgoing Specifications
8.4 incoming and outgoing wires specifications The user can choose the appropriate cable for different waterproof terminals according to the table below (can be adjusted according to the actual cable size on the customer site). Wiring type Waterproof Terminal Cable outer diameter Specifications range（mm）... - Page 13 *Note: 1. All incoming and outgoing wires are copper wires. 2. Please make wiring according to the above current range. If the above range is exceeded, our company will not be responsible for any accidents caused. 8.5.2 Before wiring: The circuit breaker is tripped and all fuse boxes must be pulled out. fusible core 8.5.3 Wiring attention ...
- Page 14 ① Operation and wiring should only be performed by a professional electrical or mechanical engineer. ② All operations and wiring must comply with the relevant national and local standards. ③ When installing, please do not touch other parts inside the case except the terminals. ④...
- Page 15 other hand, it is conducive to the maintenance of the line in the future. All wire connections, make sure the screws are tightened to ensure the normal operation of the equipment. ⑩ The following must be done before closing the fuse box and before closing the circuit breaker： Step 1：...
-
Page 16: Opening And Closing The Chassis
Step 3： The output line of the circuit breaker must be checked to eliminate equipment damage caused by reverse connection of positive and negative poles after confluence. 8.5.5 Closing circuit breaker steps： Step1:Push the handle down to make the circuit breaker in "OFF" state. Step2:Push the circuit breaker handle up to make the circuit breaker in the "ON"... -
Page 17: Input Wiring
Chassis shape Our photovoltaic converters are provided with keys to open and close the chassis. Note that both top and bottom locks must be opened and closed to effectively open and close the chassis. 8.7 Input Wiring The positive photovoltaic bus input terminal is located on the lower side of the bottom of the casing, and the negative photovoltaic bus input terminal is located on the upper side of the bottom of the casing. - Page 18 9.4 The PV combiner box does not need special maintenance. In order to prevent the failure of the lightning protection module, its working status should be checked regularly. Especially after the lightning, it should be checked in time. 9.5 The fuse of the same rating as the original model must be replaced! When installing the fuse, make sure the fuse holder is clamped! 9.6 The electrical components installed in the box are specially customized products of the photovoltaic combiner box, and cannot be mixed with ordinary products.
-
Page 19: Warranty And After-Sales Service
10 Warranty and after-sales service 10.1 Warranty Description Under the premise of keeping and using, the products produced by our company shall be within 12 months from the date of production (subject to the date marked on the product certificate or the product) or within 12 months from the date of purchase , When the product is seriously damaged or cannot work normally due to manufacturing quality problems, the company is responsible for free repair or replacement. - Page 20 •Converter operation in very harsh environments beyond those described in this manual •Any installation and use beyond the limits specified in the relevant national standards •Damage caused by abnormal natural environment...
- Page 21 Special Notice: We reserve the right to make changes to the product information described in this manual without notice. Before ordering, please contact your local distributor for the latest information on this product. Field wiring is subject to national standards.
- Page 22 Headquarters: Acrel Electric Co., LTD. Address: No. 253, Yulv Road, Jiading District, Shanghai,China TEL：0086-21-69158338 0086-21-69156052 0086-21-59156392 0086-21-69156971 Fax：0086-21-69158303 Web-site：www.acrel.cn E-mail：ACREL001@vip.163.com Postcode：201801 Production base: Jiangsu Ankerui Electric Appliance Manufacturing Co., Ltd. Address: No. 5 Dongmeng Road, Dongmeng Industrial Park, Nanzha Street, Jiangyin City, Jiangsu...
