Summary of Contents for Midea FS45-20AR
- Page 1 维修手册 Service Manual, 2017 v1.0 Service Manual 维修手册 Applicable Models Model No. 适用机型 机型编码 22056011004618 FS45-20AR （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) 1 / 17...
-
Page 2: Important Safety Notice
Midea Environment Appliance Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales of Midea Environment Appliance. 2 / 17... - Page 3 维修手册 Service Manual, 2017 v1.0 3 / 17...
-
Page 4: Safety Warning Code
维修手册 Service Manual, 2017 v1.0 安全警示规范 Safety Warning Code WARNING Read these instructions. Keep these instructions. Follow all instructions. Do not use this appliance near water. This appliance is intended to be used in household and similar environments. Clean only with a damp cloth. Install in accordance with the manufacturer’s instructions. - Page 5 维修手册 Service Manual, 2017 v1.0 整机拆卸 Dismantling of appliance 前网罩拆卸 Dismantling of front mesh coer 依次用手向外掰前网罩上周圈凸起位置使卡 扣脱卡，取下前网罩 In turn, use your hands to pull out the protruding position of the front net cover loop to make the buckle slip, and remove the front mesh cover 风叶拆卸...
- Page 6 维修手册 Service Manual, 2017 v1.0 后网罩拆卸 Dismantling of rear mesh cover 逆时针拧下网罩索母，然后取下后网罩。 Unscrew the lock nut of grill and remove the rear mesh cover. 底盘的拆卸 Dismantling of chassis 用手拧开底部的“7 形”螺钉，即可取下底盘。 By hand unscrew the bottom "7" screw, then take down the chassis. 立柱的拆卸...
- Page 7 维修手册 Service Manual, 2017 v1.0 电机前后壳的拆卸。Dismantling of motor front and rear cover 用手拔下抽钮，用十字螺丝刀拧开电机后壳 的 1 颗螺钉， 即可拆开电机后壳； 然后用十字 螺丝刀拧开电机前壳的 2 颗螺钉， 即可拆开电 机前壳； Pull off the pull button by hand, unscrew one screw of the motor's rear housing with a cross screwdriver, and then open the motor's rear cover;...
- Page 8 维修手册 Service Manual, 2017 v1.0 Dismantling of 扇盒的拆卸 用十字螺丝刀先拧下螺栓，然后用十字 螺丝刀拧下电机后壳上 4 颗 M3 螺钉， 即可用手掰开扇盒前后壳。 First unscrew the bolt with a cross screwdriver, then unscrew 4pcs M3 screws on the rear cover of the motor with a cross screwdriver, and then break the front and rear cover of the box by hand.
- Page 9 维修手册 Service Manual, 2017 v1.0 Dismantling of connector 连接头的拆卸 用十字螺丝刀拧开螺钉，即可拆下连接 头。 unscrew the screw with a cross screwdriver and remove the connector. Dismantling 电路板的拆卸 of circuit board 用十字螺丝刀拧开防火盒上的 3 颗螺钉，然后 用手掰开卡扣，即可取下防火盒下盖即可取出 电路板 Use a cross screwdriver to open the three screws on the fire box, and then break the buckle by hand to remove the lower cover of the fire box and take out the circuit board...
-
Page 10: Function And Operation
维修手册 Service Manual, 2017 v1.0 整机的安装 Function and operation 定位套组件安装 Assembly of locating sleeve 将定位套穿过电机支撑轴， 连杆套入曲柄上， 加上垫片涂抹润滑脂后，用螺钉固定。 Pass the locating sleeve through the supporting shaft of the motor, insert the connecting rod into the crank, add gasket and grease, then fix with screws. - Page 11 维修手册 Service Manual, 2017 v1.0 机身电路板安装 Assembly of Circuit board 1、机头组件部分与扇盒前壳安装 2、将电机线、电源线插入电路板对应端子。 3、电路板放入防火盒上盖，盖上防火盒下盖 4、如图所示理线后压入电容 1. Installation of head assembly and fan box front shell 2. Insert the motor line and power line into the corresponding terminal of the circuit board. 3.
- Page 12 维修手册 Service Manual, 2017 v1.0 电机前后壳安装。Assembly of Motor front and rear cover 1、将电机前壳放到电机上对位锁 2 颗螺丝。 2、将电机后壳组到电机前壳，背部锁一颗螺 丝。 3、插入抽钮 1. Place the front housing of the motor on the motor to lock2 screws. 2. Put the motor rear cover into the motor front cover, and lock a screw on the back.
-
Page 13: Fault Code And Solutions
维修手册 Service Manual, 2017 v1.0 常见及解决方法 Fault code and solutions 故 障 代 代 码 可 故 障 内 容 维修方法步骤 Steps for 显示 码 见 Display Fault Fault Code maintenance methods content code visible 检查插座是否有电， 如出现 家 庭 的 电 源 插 座 故 障 故障更换。Check to see if Home power outlet failure... - Page 14 维修手册 Service Manual, 2017 v1.0 and slow, resulting in a rapid step. head 内 部 四 连 杆 机 构 异 常 ： The internal four-bar linkage mechanism abnormal: 1、不摇头： 同步电机损坏 需拆开电机后壳部分进行 曲 柄 断 。 Do not shake head: 检查，逐一排除，找到原因...
- Page 15 维修手册 Service Manual, 2017 v1.0 Appendix: 附录 Electrical Schematic Diagram 整机接线图 风扇维修常用工具、设备和材料 refrigerator maintenance tooling and equipment and material 工具 Tooling 名称 图片 主要用途 Name Photo Main Usage 十字螺丝刀 拆卸螺钉 Phillips screw assemble and screwdriver disassemble 平口螺丝刀/小铲刀 拆卸螺钉和铆钉 screw and slotted screwdriver/scraper rivet assemble and disassemble 15 / 17...
- Page 16 维修手册 Service Manual, 2017 v1.0 尖嘴钳 辅助工具 Nipper pliers assistive tool 电烙铁 辅助工具 assistive tool 16 / 17...
- Page 17 如需获得厂家详细技术咨询，请联系： xxx@midea.com 环境电器事业部 外销 地址：中国广东省中山市东凤镇东阜路和穗工业园东区 28 号 Midea Environment Appliance If you need to get detailed technical information from the manufacturer, please contact: xxx@midea.com Environment Appliance Division Overseas Sales Address: Eastern 28th, Hesui industrial Park, Dongfu Road, Dongfeng Town, Zhongshan City,...
