Vermeiren Timix SU User Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

User manual

M A N U E L D ' U T I L I S A T I O N

G E B R U I K S A A N W I J Z I N G

G E B R A U C H S A N W E I S U N G

M A N U A L E D I I S T R U Z I O N I

M A N U A L D E I N S T R U C C I O N E S

I N S T R U K C J A O B S Ł U G I

N Á V O D K O B S L U Z E

Timix SU

Table of Contents

Need help?

Do you have a question about the Timix SU and is the answer not in the manual?

Questions and answers

Summary of Contents for Vermeiren Timix SU

Page 1 M A N U A L D E I N S T R U C C I O N E S I N S T R U K C J A O B S Ł U G I N Á V O D K O B S L U Z E Timix SU...
Page 3: Table Of Contents
Comfort adjustments 3.7. Standing / upright function 3.8. Battery status and charging Maintenance 4.1. Points of maintenance 4.2. Maintenance instructions 4.3. Troubleshooting 4.4. Expected lifespan 4.5. Reuse 4.6. End of use 4.7. Warranty Technical specifications User manual | 2024-08 Timix SU...
Page 4: Preface
Vermeiren. Thank you for your trust in the products of Vermeiren. To support you on the use of this wheelchair and its operating functions, this manual is offered. Please read this manual carefully;...
Page 5 For user and specialist dealer User manuals of applied operating console and battery charger For user and specialist dealer Installation instructions For specialist dealer Service manual for wheelchairs For specialist dealer EC declaration of conformity User manual | 2024-08 Timix SU...
Page 6: Your Product
1. Your product Backrest Armrests Arm pads Operating console Seat Safety belt Chest belt Leg rest User manual | 2024-08 Timix SU...
Page 7: Options
• This wheelchair is designed and produced solely to transport/transfer one person with a maximum weight of 130kg. It is not designed for transportation of goods or objects, nor for any use other than previously described. User manual | 2024-08 Timix SU...
Page 8: General Safety Instructions
• Only use accessories and spare parts approved by Vermeiren. • Please read all technical details and limits of your wheelchair in chapter 5.. • The warranty on this product is based on normal use and maintenance as described in this manual.
Page 9: Symbols On The Wheelchair
2.3. Symbols on the wheelchair Maximum weight of the user in kg Maximum safe slope in ° (degrees). For indoor use only (battery charger) Maximum speed Type designation Catalogue number Serial number Medical device Manufacturer User manual | 2024-08 Timix SU...
Page 10: Transport
2.4.1. Moving out of the way Use the operating console to drive the wheelchair to its destination. Otherwise, put the wheelchair in free-wheel mode (see §3.4.) and use the push bar to move it. User manual | 2024-08 Timix SU...
Page 11 Fasten the wheelchair frame securely to the vehicle using the strap-tie-down system (see Figure 1). Place the wheelchair in drive mode (engaging the parking brakes) and check that the operating console is switched off. User manual | 2024-08 Timix SU...
Page 12: First Use And Storage
• Also read the instructions in the operator console manual and battery charger manual! • In case of doubts or questions, do not hesitate to contact your local specialist dealer, your care provider or technical adviser to help you with this. User manual | 2024-08 Timix SU...
Page 13: First Ride
If you feel confident enough, you can try to drive at higher speed. Now try to turn, in forward and backward direction. Repeat this a few times. Make sure that your wheelchair stands stable when ending the ride. Switch off your wheelchair. User manual | 2024-08 Timix SU...
Page 14: Driving Outdoors
• Do not use your wheelchair on an escalator or stairs. • Only use ramps approved by Vermeiren and do not exceed their maximum load. • To safely overcome obstacles or slopes, put the wheelchair in its most upright sitting position.
Page 15: Operating Console
If this manual is missing, contact your specialist dealer immediately. Put the joystick in the neutral (central) position before pressing the on/off button, otherwise the electronics will be blocked. To release this block, switch the operating console off and on again. User manual | 2024-08 Timix SU...
Page 16: Brake And Free-Wheel Lever
The EM brakes function automatically, only if free-wheel lever is in braking position. In this situation, the brakes start braking if: • the wheelchair is OFF; • the wheelchair is ON and the joystick is released. User manual | 2024-08 Timix SU...
Page 17: Transfer To/From The Wheelchair
Fold the footplates upwards to prevent standing on them. If necessary, turn one armrest back/up to make room, see § 3.6.3.. Transfer to/from the wheelchair using the strength of your arms or with the help of attendant(s) or lifting equipment. User manual | 2024-08 Timix SU...
Page 18: Comfort Adjustments
• Make sure that your fingers, clothes, buckles don’t get trapped during adjustment. 3.6.1. Safety belt Fasten the safety belt by clicking the buckle into the receiver. If necessary, adjust the length of the straps. To open the seat belt, press the red button. User manual | 2024-08 Timix SU...
Page 19 The arm rest is unlocked (in bottom position). Turn the armrest up/backwards to its end position. Pull lever up to close the toothed clamp. The armrest is locked in end position. User manual | 2024-08 Timix SU...
Page 20 Pull/push the arm pad lightly to adjust the height. Hold the arm pad at the desired angle. Turn the star knob clockwise until it is finger-tight. Repeat this for the second arm pad. Make sure that both arm pads are firmly secured. User manual | 2024-08 Timix SU...
Page 21: Chest Belt
Loosen the 4 star knobs (20). Slide the backrest up/down until the desired position. Retighten the star knobs. Make sure that the backrest is well secured. Optional side pelots are not compatible with the lower position of the backrest. User manual | 2024-08 Timix SU...
Page 22: Standing / Upright Function
• Driving should only take place in the seated position. The drive program should not be used during the standing / upright function. Reduced drive should be deployed only for altering position during the standing / upright function. User manual | 2024-08 Timix SU...
Page 23 Check whether the armrests are in a good position. Switch on the drive electronics and select the adjust function for the upright function. Pull the joystick backwards or push it forwards to carry out the relevant function. User manual | 2024-08 Timix SU...
Page 24: Battery Status And Charging
ɣ With little use or storage: Charge once a month. • Read the storage and maintenance instructions in §4. and technical details in §5.. • Only disconnect the battery charger when the battery is fully charged, see the following symbols on the charger. User manual | 2024-08 Timix SU...
Page 25: Maintenance
Remove the battery charger from the socket, let it cool down and store it in the charger pocket. 4. Maintenance Regular care ensures that your wheelchair is preserved in a perfectly functional condition. For the maintenance manual, refer to the Vermeiren website: www.vermeiren.com. User manual | 2024-08 Timix SU...
Page 26: Points Of Maintenance
Risk of injuries and damage • Repairs and replacements may only be undertaken by trained persons and only genuine replacement parts of Vermeiren should be used. The last page of this manual contains a registration form for the specialist dealer to record each service.
Page 27: Maintenance Instructions
• Keep the operating console clean and protect it from water and rain. Wipe all rigid parts of the wheelchair with a damp cloth (not drenched). If necessary, use a mild soap, suitable for varnishes and synthetics. User manual | 2024-08 Timix SU...
Page 28: Troubleshooting
The following symptoms may indicate a serious problem. Therefore always contact your specialist dealer if you spot any of the following deviations: • Strange sound; • Frayed/damaged wiring harnesses; • Cracked or broken connectors; • Uneven tread wear on one of the tyres; User manual | 2024-08 Timix SU...
Page 29: Overload Protection
At end of life, you need to dispose your wheelchair according to the local environmental legislation. The best way to do so, is to disassemble the wheelchair to facilitate the transport of recyclable parts. User manual | 2024-08 Timix SU...
Page 30: Warranty
(driving up/ down), type of surface and battery status. Brand Vermeiren Product group Powered wheelchair, Class B Type Timix SU Description Dimensions Maximum user weight 130 kg Overall length with footrest 1260 mm...
Page 31 Brand Vermeiren Product group Powered wheelchair, Class B Type Timix SU Description Dimensions Seat plane angle 3,5° - -84,5° Effective seat depth 395 mm - 470 mm Effective seat width 400 mm 450 mm Seat surface height at front edge...
Page 32 Brand Vermeiren Product group Powered wheelchair, Class B Type Timix SU Description Dimensions Degree of protection IPX4 Strength tests according to ISO 7176-8 Tests of power and control system ISO 7176-14 according to Ignitability of upholstery according to EN 1021-2:2006...
Page 33 By (stamp): Kind of work: I / S / R / D Kind of work: I / S / R / D Kind of work: I / S / R / D Date: Date: Date: User manual | 2024-08 Timix SU...
Page 34 User manual | 2024-08 Timix SU...
Page 35 User manual | 2024-08 Timix SU...

This manual is also suitable for:

Timix
