- Page 1 VERMEIREN Trigo INSTALLATION MANUAL...
-
Page 3: Table Of Contents
Trigo 2019-02 Content Content Preface ......................2 This product ..................3 Scope of delivery ................. 4 Assembly and adjustments ..............5 3.1 Tools ....................... 5 3.2 Adjusting the wheelchair to the user ............6 3.2.1 Seat height ..................6 3.2.2 Seat depth ..................7 3.2.3 Seat inclination ................ -
Page 4: Preface
To support you on the installation and repairs of this manual wheelchair, we provide you with this installation manual. Please read it carefully. If you still have questions after reading this manual, do not hesitate to contact Vermeiren. The information in this manual applies to the following wheelchair(s): •... -
Page 5: This Product
Trigo 2019-02 This product This product 1. Backrest 2. Side plate (with optional armrest) 3. Seat 4. Frame 5. Fixed footplate 1x (S-line) 6. Removable footplate 2x (T-line) 7. Front wheel 8. Rear wheel 9. Fixed footrest (S-line) 10. Removable footrest (T-line) 11. -
Page 6: Scope Of Delivery
Trigo 2019-02 Scope of delivery Scope of delivery The following items are part of the delivery: • Framework • Sideplates • Rear and front wheels • Seat and back cushion • Footrests (*) • Tools • User manual of wheelchair •... -
Page 7: Assembly And Adjustments
Read the user manual of this wheelchair. • Be aware of the technical details and limits of intended use; see the user manual. • For more information, contact your nearest Vermeiren facility. Tools To (dis)assemble and adjust the wheelchair, the following tools are needed: •... -
Page 8: Adjusting The Wheelchair To The User
Trigo 2019-02 Assembly and adjustments Adjusting the wheelchair to the user Risk of injuries CAUTION • Take the possible rear wheel-front wheel configurations into account regarding seat height, as mentioned in Table 1. • Make sure that both front wheels and both rear wheels are mounted in the same position. -
Page 9: Seat Depth
Trigo 2019-02 Assembly and adjustments Table 1: Wheel configurations regarding seat height SEAT HEIGHT FRONT (in mm) 3" 4" ... -
Page 10: Backrest Inclination
Trigo 2019-02 Assembly and adjustments 3.2.4 Backrest inclination The backrest can be adjusted into 5 angle positions: 1. Gently pull the back strap (11) until the backrest is unlocked. 2. Remove the outer screw (12) of the hinging point (13). 3. -
Page 11: Fixed Side Plate
Trigo 2019-02 Assembly and adjustments 3.2.6 Fixed side plate Depth of side plate (22) Loosen socket screws (19+20+21). Slide side plate forward/backward and retighten the socket screws. Height of side plate (22) Remove socket screws (19+20+21). Move the side plate up/down to the desired height and retighten it with socket screws (19+20) in one of its openings. -
Page 12: Footplate Height
Trigo 2019-02 Assembly and adjustments 3.2.8 Footplate height S-line (steps of 10 mm) Remove the M6 screw from the back of the footrest (26). Slide the footplate (27) up/down in the front-frame tube (28) until the desired height. Make sure the holes of the inner and outer tube align. -
Page 13: Footplate Depth (Only For Trigo S-Line, Folding Footplate)
Trigo 2019-02 Assembly and adjustments For the opening footplate: 1. On the main tube (31), loosen the M6 screws (32) on both sides of the footplate. 2. Turn the footplate until the desired angle is reached. 3. Firmly retighten both screws (32). 3.2.10 Footplate depth (only for Trigo S-line, folding footplate) 1. -
Page 14: Changing Pneumatic Tyres
Inflate the tyre using inflating equipment which complies to regulations and with a pressure indication in “bar”. • Only use replacement parts approved by Vermeiren. To change the tyre or inner tube, proceed as follows: 1. Let all the air out of the inner tube. - Page 16 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © Vermeiren Group 2019...
