Osburn INSPIRE 2000-I INBUILT Installation And Operation Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

INSTALLATION AND OPERATION MANUAL

INSPIRE 2000-I INBUILT

YOUR OSBURN INSPIRE 2000 INBUILT HAS BEEN

TESTED WITH OUR ORIGINAL OSBURN INSPIRE 2000

ZERO CLEARANCE KIT. THE INSTALLATION OF ANY

(OB02040 Model)

OTHER ZERO CLEARANCE KIT WILL VOID YOUR

WARRANTY.

Distributed by

My Fireplace Australia PTY Ltd

20 Auto Way

Pakenham, Victoria 3810

AUSTRALIA

Phone: 03 59 415 008 Fax: 03 59 415 975

info@myfireplaceaustralia.com.au

Website

www.myfireplaceaustralia.com.au

This manual is available for free download on the manufacturer's web site. It is a copyrighted

document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to

time and cannot be responsible for problems, injuries, or damages arising out of the use of

information contained in any manual obtained from unauthorized sources.

READ AND KEEP THIS MANUAL FOR REFERENCE

45937A

Printed in Canada

09-04-2020

Table of Contents

Need help?

Do you have a question about the INSPIRE 2000-I INBUILT and is the answer not in the manual?

Questions and answers

Summary of Contents for Osburn INSPIRE 2000-I INBUILT

Page 1 INSTALLATION AND OPERATION MANUAL INSPIRE 2000-I INBUILT YOUR OSBURN INSPIRE 2000 INBUILT HAS BEEN TESTED WITH OUR ORIGINAL OSBURN INSPIRE 2000 ZERO CLEARANCE KIT. THE INSTALLATION OF ANY (OB02040 Model) OTHER ZERO CLEARANCE KIT WILL VOID YOUR WARRANTY. Distributed by...
Page 2 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual THANK YOU FOR CHOOSING THIS WOOD INBUILT We want to congratulate you on your purchase and wish to help you get maximum satisfaction from your wood inbuilt. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.
Page 3: Table Of Contents
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual TABLE OF CONTENTS PART A - OPERATION AND MAINTENANCE ..........6 Safety Information ................. 6 Summary of Operation and Maintenance Cautions and Warnings ........6 General Information ............... 7 OSBURN Inspire 2000-I Specifications ................... 7 Zone Heating and How to Make it Work for You ..............
Page 4 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Blower Operation ........................ 20 4.5.1 Building Different Fires for Different Needs ..............20 Maintaining Your Wood Heating System ........22 Wood Inbuilt Maintenance ....................22 5.1.1 Cleaning Door Glass ......................22 5.1.2 Door Adjustment ......................
Page 5 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Appendix 1: Fresh Air Intake Kit Installation (optional) ......40 Appendix 2: Faceplate Installation ............41 Appendix 3: Blower Removal .............. 42 Appendix 4: Installation of Secondary Air Tubes and Baffle ....46 Appendix 5: Wood Inbuilt Removal Instructions ........
Page 6: Part A - Operation And Maintenance
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual PART A - OPERATION AND MAINTENANCE Please see Part B for installation instructions. 1 SAFETY INFORMATION 1.1 SUMMARY OF OPERATION AND MAINTENANCE CAUTIONS AND WARNINGS HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT •...
Page 7: General Information
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual GENERAL INFORMATION 2.1 OSBURN INSPIRE 2000-I SPECIFICATIONS Combustible: Wood Heating capacity* 240 m Average peak power– hardwood (Australia): 10.1 kW Average efficiency – hardwood (Australia): 61 % Average emissions – hardwood (Australia): 0.8 g/kg...
Page 8 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 8 _______________________________________________________________________________...
Page 9: Zone Heating And How To Make It Work For You
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 2.2 ZONE HEATING AND HOW TO MAKE IT WORK FOR YOU Your new Inspire 2000 wood inbuilt is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. This is called zone heating and it is an increasingly popular way to heat homes or spaces within homes.
Page 10: Osburn's Commitment To You And The Environment
2.4 OSBURN’S COMMITMENT TO YOU AND THE ENVIRONMENT The Osburn team is committed to protecting the environment, so we do everything we can to use only materials in our products that will have no lasting negative impact on the environment.
Page 11: Fuel
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 3 FUEL 3.1 MATERIALS THAT SHOULD NOT BE BURNED GARBAGE OF ANY KIND, • COAL OR CHARCOAL, • TREATED, PAINTED OR COATED WOOD, • PLYWOOD OR PARTICLE BOARD, • FINE PAPER, COLORED PAPER OR CARDBOARD, •...
Page 12: How To Dry Firewood
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Wood should be split to a range of sizes, from about 75 mm to 150 mm (3” to 6”) in cross section. Having a range of sizes makes starting and rekindling fires much easier. Often, the firewood purchased from commercial suppliers is not split finely enough for convenient stoking.
Page 13: Judging Firewood Moisture Content
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 3.2.6 JUDGING FIREWOOD MOISTURE CONTENT You can find out if some firewood is dry enough to burn by using these guidelines: Cracks form at the ends of logs as they dry; •...
Page 14: Operating Your Wood Inbuilt
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4 OPERATING YOUR WOOD INBUILT NEVER OVERFIRE YOUR WOOD INBUILT. IF ANY PART OF THE WOOD INBUILT STARTS TO • GLOW RED, OVER FIRING IS HAPPENING. READJUST THE AIR INTAKE CONTROL AT A LOWER SETTING.
Page 15: Cold Hand
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.1 COLD HAND The cold hand is a handle, supplied with the insert. It allows to open the door and avoid burns. To open, insert the cold hand into the opening on the right side of the insert. Pull on the cold hand to open the door.
Page 16: Lighting Fires
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.3 LIGHTING FIRES Each person who heats with wood develops their own favorite way to light fires. Whatever method you choose, your goal should be to get a hot fire burning quickly. A fire that starts fast produces less smoke and deposits less creosote in the flue system.
Page 17: Two Parallel Logs
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.3.3 TWO PARALLEL LOGS Place two spit logs in the firebox. Place a few sheets of twisted newspaper between the logs. Now place some fine kindling across the two logs and some larger kindling across those, log cabin style.
Page 18: Ash Removal
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.4.2 ASH REMOVAL Ash should be removed from the firebox every two or three days of full time heating. Do not let the ash build up in the firebox because it will interfere with proper fire management.
Page 19: Firing Each New Load Hot
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.4.4 FIRING EACH NEW LOAD HOT Place the new load of wood on and behind the charcoal and not too close to the glass. Close the door and open the air control fully. Leave the air control fully open until the firebox is full of flames, the wood has charred to black and its edges are glowing red.
Page 20: Blower Operation
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.5 BLOWER OPERATION Allow the wood inbuilt to reach operating temperature (approximately one hour), before turning on the blower, since increased airflow from the blower will remove heat and affect the start-up combustion efficiency.
Page 21 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4.5.1.2 Long Lasting Low Output Fires Sometimes you will want to build a fire to last up to eight hours, but don’t need intense heat. In this case use smaller pieces of hardwood and place the logs compactly in the firebox so the pieces are packed tightly together.
Page 22: Maintaining Your Wood Heating System
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 5 MAINTAINING YOUR WOOD HEATING SYSTEM 5.1 WOOD INBUILT MAINTENANCE Your new wood inbuilt will give many years of reliable service if you use and maintain it correctly. Some of the internal components of the firebox, such as firebricks, baffles and air tubes, will wear over time under intense heat.
Page 23: Door Adjustment
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 5.1.2 DOOR ADJUSTMENT For your wood inbuilt to burn at its best efficiency, the door must provide a perfect seal with the firebox. Therefore, the gasket should be inspected periodically making sure to obtain an air tight fit.
Page 24: Replacing The Door Gasket
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual The door angle can also be adjusted by unscrewing the nuts (F) and sliding the bracket (G) towards the left or the right. 5.1.3 REPLACING THE DOOR GASKET It is important to maintain the gasket in good condition. After a year or more of use, the door gasket will compress and become hard, which may allow air to leak past it.
Page 25: Replacing The Glass Or The Glass Gasket
1400º F. If the glass breaks, it must be replaced with one having the same specification. Contact your Osburn dealer to obtain a genuine replacement part (see Exploded Diagram and Parts List, in appendix 6 to get the proper part number).
Page 26 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual To replace the glass gasket, center the gasket on the edge of the glass. To do this easily, peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side up.
Page 27: Cleaning And Painting The Wood Inbuilt
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Reinstall the glass, following the “Replace the glass” steps above. Do not abuse the glass door by striking or slamming shut. Do not use the wood inbuilt if the glass is broken. To change the glass, perform the same operation described above.
Page 28: Cleaning The Flue System
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Contact your local municipal or provincial fire authority for information on how to handle a flue system fire. Have a clearly understood plan to handle a flue system fire. 5.2.3 CLEANING THE FLUE SYSTEM Flue system cleaning can be a difficult and dangerous job.
Page 29: Part B - Installation
The Inspire 2000-I inbuilt can only be installed with the Inspire 2000 zero-clearance kit (sold separately). See installation instructions provided with the kit.
Page 30: Safety Information
FIREPLACE WHEN INSTALLING THE WOOD INBUILT. 7.1 REGULATIONS COVERING WOOD INBUILT INSTALLATION IT IS RECOMMENDED THAT THE INSTALLATION OF YOUR OSBURN WOOD INBUILT BE CARRIED OUT BY A QUALIFIED SPECIALIST INSTALLER. IF ANY ELECTRICAL WORK IS REQUIRED, IT MUST BE CARRIED OUT BY A LICENSED ELECTRICIAN.
Page 31: Clearances To Heat-Sensitive Materials
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual AUTHORITY, I.E. THE APPLIANCE SHALL BE IDENTIFIABLE BY A COMPLIANCE PLATE WITH THE MARKING “TESTED TO AS/NZS 4012/4013 (1999)”. ANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE TESTING AUTHORITY IS IN BREACH OF THE APPROVAL GRANTED FOR COMPLIANCE WITH AS/NZS 4012/4013 (1999).
Page 32 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Here is a sample calculation to determine the need to add a non-combustible materials floor protection. For someone whose wood inbuilt would protrude 76 mm into the room (C) the calculation would be:...
Page 33: Minimum Masonry Opening, Clearances To Combustibles, And Floor Protector
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Data for Floor Protection Calculation MINIMUM AIR JACKET EXTENDED (Note 1) Flush with Dimension of the MILLIMETRES 700 mm 0 mm D = B - (A - C) fireplace hearth extension facing 8.3 MINIMUM MASONRY OPENING, CLEARANCES TO COMBUSTIBLES, AND FLOOR...
Page 34: Maximum Protrusion
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Note 3: If used with zero clearance kit OA10371, the first internal wall stud must be 150 mm above the fireplace insert top and the front wall up to that first stud must be made of non-combustible material.
Page 35: The Flue System
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 9 THE FLUE SYSTEM 9.1 GENERAL The flue system, made up of the flue system and the flue between the wood inbuilt and the flue system, acts as the engine that drives your wood heating system. Even the best wood inbuilt will not function safely and efficiently as intended if it is not connected to a suitable flue system.
Page 36: Flue Liner Installation
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual ATTENTION INSTALLER: When positioning the unit in a fireplace opening prior to the flue installation, install the wood inbuilt into the opening until the top lip of air jacket is flush with fireplace facing.
Page 37: If The Flue Liner Does Not Align With The Wood Inbuilt's Flue Outlet
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual B) Your dealer may offer a liner fastening system, sold separately. Follow the installation instructions provided with the liner fastening system. 9.4.2 IF THE FLUE LINER DOES NOT ALIGN WITH THE WOOD INBUILT’S FLUE OUTLET You can install a liner offset adapter, sold separately.
Page 38: Minimum Flue System Height
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 9.5 MINIMUM FLUE SYSTEM HEIGHT Flue heights and lengths from AS/NZS 2918:2001 The top of the flue system should be tall enough to be above the air turbulence caused when wind blows against the house and its roof.
Page 39: The Relationship Between The Flue System And The House
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 9.6 THE RELATIONSHIP BETWEEN THE FLUE SYSTEM AND THE HOUSE Because the flue system is the engine that drives the wood heating system, it must have the right characteristics. The signs of bad system design are cold back drafting when there is no fire in the wood inbuilt, slow kindling of new fires, and smoke roll-out when the door is opened for loading.
Page 40: Appendix 1: Fresh Air Intake Kit Installation (Optional)
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 1: FRESH AIR INTAKE KIT INSTALLATION (OPTIONAL) Note: Only remove the knock-out that will be connected to the fresh air inlet. To install a fresh air intake kit to the wood inbuilt, the purchase of accessory is required.
Page 41: Appendix 2: Faceplate Installation
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 2: FACEPLATE INSTALLATION Two faceplates are available with this wood inbuilt. For more details about the installation, consult the faceplate installation manual ______________________________________________________________________________ 41...
Page 42: Appendix 3: Blower Removal
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 3: BLOWER REMOVAL 1. Unplug the blower and remove all electrical sources on the wood inbuilt. 2. Remove the bottom faceplate by removing the four screws holding it in place. 3. Locate the cover under the wood inbuilt...
Page 43 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 4. Push and rotate counter clock wise to remove the cover. 5. Remove both wing nuts (A) holding the blower mounting plate. ______________________________________________________________________________ 43...
Page 44 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual 6. Rotate the blower counter clock wise and gently pull on the blower. 7. Remove both screws (B) and gently pull on plate (A). Unplug the blower wires (C). Once the blower is unplugged, pull gently for removal.
Page 45 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual ______________________________________________________________________________ 45...
Page 46: Appendix 4: Installation Of Secondary Air Tubes And Baffle
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 4: INSTALLATION OF SECONDARY AIR TUBES AND BAFFLE 1. Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel.
Page 47 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Note that secondary air tubes (B) can be replaced without removing the baffle board (A). ______________________________________________________________________________ 47...
Page 48: Appendix 5: Wood Inbuilt Removal Instructions
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 5: WOOD INBUILT REMOVAL INSTRUCTIONS For the purpose of inspecting the wood inbuilt itself or the fireplace, your wood inbuilt may need to be removed. To remove your wood inbuilt follow these instructions: •...
Page 49: Appendix 6: Exploded Diagram And Parts List
Osburn Inspire 2000-I Inbuilt Installation and Operation Manual APPENDIX 6: EXPLODED DIAGRAM AND PARTS LIST ______________________________________________________________________________ 49...
Page 50 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your wood inbuilt, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
Page 51 Osburn Inspire 2000-I Inbuilt Installation and Operation Manual Item Description 37 PL65913 BLOWER MOUNTING PLATE 38 44208 240V DOBLE CAGE BLOWER (Class H - 150C) 39 SE65913 BLOWER ASSEMBLY 40 22022 MOULDED LOGO/PLUG STONE 41 22021 MOULDED BOTTOM STONE 42 22020...
Page 52 Manufactured by: STOVE BUILDER INTERNATIONAL INC. 250, De Copenhague, Saint-Augustin-de-Desmaures (Quebec) Canada G3A 2H3 www.osburn-australia.com Distributed by: My Fireplace Australia PTY Ltd 20 Auto Way, Pakenham, Victoria 3810 AUSTRALIA Phone: 03 59 415 008 Fax: 03 59 415 975 info@myfireplaceaustralia.com.au Email www.myfireplaceaustralia.com.au...

This manual is also suitable for:

Ob02040
