Scroll and Pan
The procedures in this section explain how to scroll and pan the Picture application screen when
the image does not fi t within the screen area.
■ To scroll an image
Use the scroll bar(s) to scroll the image.
■ To pan an image
1.
On the toolbar, click V.
2.
Drag the mouse pointer within the drawing area.
• The image will pan in the direction you drag.
Note
The image will not pan if there are no scroll bars displayed.
Drawing Operations
This section explains the various fi gure and text operations you can perform with the Picture
application.

■ Drawing Figures

Based on the type of image you want to draw, select the applicable drawing tool from the tool bar,
fl oating toolbar or [Draw] menu. Next, drag and click in the drawing area to draw the fi gure. The
following explains which drawing tool you need to use draw each type of fi gure.
To draw this Click this
type of fi gure: button:
point or curve
line
arrow
rectangle line
square
rectangle
circle
And perform this
operation in the drawing
area:
M
Click or drag.
i
Click one point and then
another point.
o
(You could also drag from
one point to the next.)
N
a
Z
c
Which will do this in the drawing
area:
Draw a point where you click or a curve
where you drag.
Draw a line connecting the two points.
Draw a vector connecting the two
points.
Draw a rectangle line starting from the
fi rst point and ending near the second
point.
Draw a square starting from the fi rst
point with the angle opposite the fi rst
point near the second point.
Draw a rectangle with opposite angles
at the two points.
Draw a circle whose center point is at
the fi rst point and whose radius is the
distance between the two points.
