Ltech LM-240-24-G1M2 Manual

Intelligent Tunable White LED Driver
The housing is made from V0 flame retardant PC materials
from SAMSUNG/COVESTRO.
The clamshell design and screwless type for strain-relief.
The design of dismountable end cap allows you to adjust
the length of housing depending on your needs.
Change the dimming method, PWM frequency and other
parameters via the APP.
Support RDM protocol.
With soft-on and fade-in dimming function, enhancing your
visual comfort.
The whole dimming process is flicker-free with high frequency
exemption level.
Dimming from 0-100%, down to 0.01%.
Comply with the EU's ErP Directive, networked standby<0.5W.
Overheat, over voltage, overload, short circuit protection and
automatic recovery.
Suitable for ClassⅠ/Ⅱ/Ⅲ
indoor light fixtures.
Normal service life can reach 100,000 hours.
5-year warranty (Rubycon capacitor).
Technical Specs
Model
Output Type
Dimming Interface




Features
Output Feature




Protection Grade
Insulation Grade
Output Voltage
Output Voltage Range


Output
Current


Output Power
OUTPUT
Dimming Range
Ripple(maximum)
Voltage Accuracy
PWM Frequency
DC Voltage Range
AC Voltage Range
EoF
V
Input Voltage
Frequency
Input Current
INPUT Power Factor
THD
Efficiency (Typ.)
Inrush Current
Anti Surge
Leakage Current
Working Temperature
Working Humidity
ENVIRONMENT Storage Temperature/Humidity
Temperature Coefficient
Vibration
Overload Protection
Overheat Protection
PROTECTION
Overvoltage Protection
Short Circuit Protection
Withstand Voltage
Insulation Resistance
Safety
Standards
SAFETY
&
EMC
EMC Emission
EMC Immunity
Power Consumption
ErP
Flicker/Stroboscopic Effect
DF
Weight(N.W.)
OTHERS
Dimensions
The driver is suitable for connecting resistor current-limiting LED fixture (e.g. LED strip). The inrush current will be dozens of times increased if connecting built-in constant current IC current-limiting LED fixtures, the driver will activate the
overloaded protection (hiccups flickering). When you order, please remark controlling the constant current LED fixture (e.g. MR16 lamp, underground light, LED wall washer, constant current LED strip, etc.), so that we can prepare them with
special procedures.
(Constant Voltage)


Programmable
Overheat
Protection
LM-240-24-G1M2
Constant voltage
DMX512/RDM, PUSH
DIM
Isolation
IP20
Class II (Suitable for class I/ II /III light fixtures)
24Vdc
24Vdc±0.5Vdc
Max. 10A
Max. 240W
0~100%, down to 0.01%
200mVp-p
±5%
≤22000Hz (NFC setting range 300-20000Hz)
200-250Vdc
220-240Vac
EoF =99.6%
V
220-240Vac
0/50/60Hz
Max. 1.18A/230Vac
PF>0.99/230Vac, at
full
load
THD≤5%@230Vac, at
full
load
94%
Cold start 55A(Test twidth=1200us tested under 50% Ipeak)/230Vac
L-N: 2KV
Max. 0.5mA
ta: -20
~
45°C


tc: 86°C
20
~
95%RH,
non-condensing
-40
~
80°C/10~95%RH
±0.03%/°C(0-50°C)
10~500Hz, 2G 12min/1cycle, 72 min for X, Y and Z axes respectively
Shut down the output when rated power≥102%, auto recovers
Intelligently adjust or turn off the output current if the PCB temperature ≥110°C, and recover automatically
Shut down the output when voltage≥28V, and recover automatically
Enter hiccup mode if short circuit occurs, and recover automatically
I/P-O/P: 3750Vac
I/P-O/P: 100MΩ/500VDC/25°C/70%RH
CCC China GB19510.1, GB19510.14
TUV EN61347-1, EN61347-2-13, EN62493
Germany
CB IEC61347-1, IEC61347-2-13
CB Member States
CE European Union EN61347-1, EN61347-2-13, EN62384
KC KC61347-1, KC61347-2-13
Korea
EAC Russia IEC61347-1, IEC61347-2-13
Australia
RCM AS
61347-1, AS
61347-2-13
ENEC Europe EN61347-1, EN61347-2-13, EN62384
UKCA BS EN 61347-1, BS EN 61347-2-13, BS EN 62493
Britain
BIS IS
15885
(PART
2/SEC
13)
India
CCC China
GB/T17743, GB17625.1
CE European Union EN55015, EN61000-3-2, EN61000-3-3, EN61547
KC Korea KSC 9815, KSC 9547
EAC Russia IEC62493, IEC61547, EH55015
Australia EN55015, EN61000-3-2, EN61000-3-3, EN61547
RCM
UKCA
Britain BS EN IEC 55015, BS EN IEC 61000-3-2, BS EN 61000-3-3, BS EN 61547
EN61000-4-2,3,4,5,6,8,11, EN61547
Networked standby .
No-load power consumption .
Meet IEEE 1789 standard/High frequency exemption level
IEEE
1789
CIE SVM Pst LM≤1.0, SVM≤0.4
≤
Phase factor DF


0.9
555g±10g
380×49.5×30mm(L×W×H)
DIM
The certification icon represents undergoing certification applications only, and final certification qualification subject to actual product.
V
Overvoltage
Protection
1
DMX512/RDM
LM-240-24-G1M2
PUSH DIM
Overload
Protection
Short
Circuit
Protection
