Amphenol PL18X-301-G97 Series Assembly Manual

1 pos 180d plug

Advertisement

Quick Links

Manual P/N:8P1219
Rev.02 2024/10/09
PL18X-301-XX-G97 单芯直头组装规范
PL18X-301-XX-G97 1 POS 180D Plug
键位
X 键
Y 键
U 键
V 键
W 键
T键
Assembly Manual
PL18(X)-30(X)-70-G97
高压互锁
Key
0:无
X
1:有
Y
U
V
HVIL
W
0:No
T
1:Yes
线缆大小
Cable Size
mm2
线缆类型
Cable type
50
70
www.amphenol-gec.com
LV 216

Advertisement

loading
Need help?

Need help?

Do you have a question about the PL18X-301-G97 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amphenol PL18X-301-G97 Series

  • Page 1 Manual P/N:8P1219 Rev.02 2024/10/09 PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual PL18(X)-30(X)-70-G97 高压互锁 线缆大小 键位 0:无 X 键 Cable Size 1:有 线缆类型 Y 键 Cable type U 键 V 键 HVIL W 键 0:No LV 216 T键 1:Yes www.amphenol-gec.com...
  • Page 2: Part 1: Package Contents

    PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual 第一部分:包装清单 Part 1: Package contents ④ ② ③ ① ⑤ ⑥ ⑦ ⑧ ① 屏蔽壳组件 Shielding shell assembly ×1 ② 带高压互锁弹片的绝缘筒 Insulation sleeve with HVIL contact spring ×1 (300系列无高压互锁弹片 No HVIL contact spring for 300 series) ③...
  • Page 3 PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual 安装步骤 Assembly Instruction 步骤1:取出连接器, 如上页图示拆开零件 Step1:Take out the connector and take it apart as the picture shown on the previous page. 步骤2:选取合适线缆(参考手册最后的附录),按照表1尺寸剥离绝缘皮和外皮 Step2:Select the right cable(refer to the appendix), prepare the cable according to the sketch and Table 1 below 导体...
  • Page 4 PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual 步骤5: 调试好免换模压接机BZW-6C,将端子压接在线材上(详细规格参照手册最后的附录) Step5: Set up the Hexagon crimp machine BZW-6C, Then crimp the terminal on the wire. (please refer to the appendix at the end of this manual for more crimping information) 横截面...
  • Page 5 PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual 将密封圈推到底 ① 屏蔽壳组件 Push the Seal to the bottom Shielding shell assembly HVIL 弹片 位置 HVIL contact spring position 步骤9:建议客户参考下面的测试参数,对线束进行绝缘电阻测试和耐压测试 Step9:Insulation resistance and dielectric withstand voltage tests are obligated to be done according to below test parameters to guarantee the good electric performance of the whole harness 9-1 绝缘电阻测试...
  • Page 6 PL18X-301-XX-G97 单芯直头组装规范 PL18X-301-XX-G97 1 POS 180D Plug Assembly Manual 附录APPENDIX 线缆压接的参考规范 Reference specification for cable crimping 压接高度H(mm) 压接宽度 参考保持力 电线外径 线缆型号 电线尺寸 (mm) Crimping W(mm) Retention Cable Type Cable Size Wire OD height Crimping Width Force LV 216 50mm² 15.5±0.3 11.4±0.3 13.0±0.3 2800N...
  • Page 7 Specifications are subject to change without notice. Contact your nearest Amphenol Corporation Sales Office for the latest specifications. All statements, information and data given herein are believed to be accurate and reliable but are presented without guarantee, warranty, or responsibility of any kind, expressed or implied.
