Drill / driver

Advertisement

Quick Links

Manual
Drill / Driver
Applies for:
Code
103170
TALA-3/8N
CAUTION
Model
TALA-3/8N
Read this manual thoroughly
before using the tool.
400 W 3/8"
Power
Chuck

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TALA-3/8N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Truper TALA-3/8N

  • Page 1 Manual Drill / Driver 400 W 3/8” Power Chuck Applies for: Code Model 103170 TALA-3/8N TALA-3/8N Read this manual thoroughly CAUTION before using the tool.
  • Page 2: Table Of Contents

    Preparation Keep this manual for future references. Start up The illustrations in this manual are for reference Practical tips only. They might be different from the real tool. Maintenance Notes Authorized service centers Warranty policy TALA-3/8N ENGLISH...
  • Page 3: Technical Data

    Technical data TALA-3/8N Code 103170 Description Drill / Driver Chuck 3/8” Voltage 127 V Frequency 60 Hz Current 3.5 A Power 400 W Speed 0 RPM – 500 RPM 0 RPM – 1 800 RPM Drilling Capacity Steel 3/8" | Wood Level 1: 1 9/16" Level 2: 1"...
  • Page 4: General Safety Warnings For Power Tools

    General Safety Warnings for Power Tools WARNING! Read all safety warnings and all instructions listed below carefully. Failure to follow any of them may result in electric shock, fire, and/or serious injury. Keep the warnings and instructions for future reference. Work area Remove any wrenches or adjusting tools before starting the Keep your work area clean, organized, and well-lit.
  • Page 5: Safety Warnings

    Safety warnings for the use of drills Choose the Appropriate Drill Bit While Operating the Drill CAUTION • Select the appropriate drill bit for the • Hold the tool by the insulated surfaces, especially material you are working with; this reduces the risk of when working where the cutting part of the drill bit serious injury and speeds up the work.
  • Page 6: Parts

    Parts 2-speed selector Function and torque selector Tool holder Forward/Reverse button Lock-on button Variable speed switch Handle Cable protector Power cord ENGLISH...
  • Page 7: Preparation

    Preparation Drill Bit Installation Place the direction button in the locked position (center) • Hold the base of the chuck firmly with one hand and with the other, turn the chuck counterclockwise to loosen the jaws (A). • Insert the drill bit all the way or remove it as needed. •...
  • Page 8 Start up Screwdriver-Drill-Driver Brake Stop • Drilling: Set the torque selection ring (E) to the When releasing the on/off switch (D), the chuck "drilling" symbol. decelerates, preventing the application tool from • Screwdriving: Set the torque selection ring (E) to continuing to rotate.
  • Page 9: Practical Tips

    Practical tips After working at low speed for an extended period, run the power tool at maximum speed for about three minutes without a load to cool it down. When drilling metal, only use sharp HSS (High-Speed Steel) bits that are in perfect condition. Before screwing larger or longer screws into hard materials, it is advisable to make a pilot hole with the thread core diameter to approximately 2/3 of the screw length.
  • Page 10 Notes ENGLISH...
  • Page 11: Authorized Service Centers

    Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center.
  • Page 12: Warranty Policy

    It includes transportation expenses for the product that result from its service network compliance. TRUPER will not request any proof of purchase to activate the warranty. Tel. 800-018-7873. Made in China. Importer: Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo.
